▶ EngineEngine Manufacturer Yanmar Yanmar Engine Model 4TNV86T-CR 3TNV80F Engine Type 4-cycle, inline, water-cooled, turbocharged diesel 3-cylinder, liquid-cooled diesel (natural aspiration) No. of Cylinders 4 3 Displacement 127.6 in³ 77.3 in³ Rated Engine Speed 2800 rpm 3000 rpm Engine Power (Gross) 55.1 hp 24.7 hp PTO Power 44.9 hp 18.3 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Water-cooled, forced circulation with fan Liquid-cooled Air Cleaner Dry dual element Dry Fuel System Common Rail Direct Injection Direct fuel injection Alternator 70 A, 12 V 40 A, 12 V ▶ HydraulicsPump Type Not Published Single gear pump with flow divider Implement Flow 9.5 gpm 4.18 gpm Steering Flow 5.0 gpm 2.77 gpm Total Hydraulic Flow 14.5 gpm 6.95 gpm Overall Hydraulic Pump Flow 9.5 gpm 6.95 gpm Hydraulic System Type Independent fully live hydraulic pump with separate reservoir; position control with isolating and response control Live, independent, open centre Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 1 No. of Optional Remote Valves Not Published Not Published ▶ Fluid CapacityFuel Tank Capacity 15.85 gal 6.6 gal Coolant Capacity 2.5 gal 3.8 qt Crankcase Capacity 5.6 qt 2.9 qt Transmission / Hydraulic System Capacity 9.24 gal 5.8 gal Front Axle Fluid Capacity 2.64 gal 4.7 qt ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540 rpm 540 rpm Mid-PTO Availability No mid-PTO offered Optional (2,000 rpm) Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 3,314 lb 1,534 lb Hitch Lift Capacity (at 24”) 2,945 lb 1,102 lb Lift Control Type Position and draft control Position ▶ Transmission & DrivetrainTransmission Type 16F/16R Syncro Shuttle w/creeper 2-range hydrostatic No. of Speeds 16 forward, 16 reverse 2 Range Max Travel Speed (Forward) 18.4 mph 13.7 mph Max Travel Speed (Reverse) 16.1 mph Not Published Clutch Main: dry single disc, mechanical (10.24 in diameter); PTO: multiple wet disc Not Published Differential Lock & Limited Slip Options 4WD (MFWD) standard; bevel-gear rear differential lock 4WD with mechanical rear differential lock ▶ Chassis, Steering & ControlsFrame Type Transmission case, clutch housing, engine and front axle support bolted together to form a rigid unit Rigid unit: transmission case, engine and front axle support bolted together Steering Hydrostatic power steering Hydrostatic power steering Brakes Wet disc, mechanical, foot operated Wet disc Seat Suspension & Adjustability Suspension seat with armrests and retractable seat belt, standard Suspension seat with armrests & retractable seat belt Front Axle Type Center-pivot, reverse Elliot type (4WD) 4WD, center-pivot reverse Eliot type Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 141.3 in 107.8 in Overall Width 63.8 in 52.8 in Wheelbase 76.2 in 61 in Ground Clearance 13.8 in 7.71 in Min. Turn Radius without Brakes Not Published 109.5 in Height to Top of ROPS 102.1 in 89.8 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published ▶ WeightTractor Weight (Base) 3,814 lb 1,881 lb Weight with ROPS and Loader Not Published 2,560 lb Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Titan (USA): R4 Industrial (Std), R1 Agricultural (Opt), R3 Turf (Opt) R1 Agricultural, R3 Turf, R4 Industrial, R14 R1 Agricultural - Front 9.5x16 6-12 R1 Agricultural - Rear 14.9x24 9.5-20 R3 Turf - Front 12x16.5 25x8.5-14 R3 Turf - Rear 16.9x24 36x13.5-15 R4 Industrial - Front 12x16.5 23x8.5-12 (with 12-16.5 rear); 25x8.5-14 (with 14-17.5 rear) R4 Industrial - Rear 16.9x24 12-16.5 (with 23x8.5-12 front); 14-17.5 (with 25x8.5-14 front) ▶ Loader & AttachmentsQuick Attach Loader System L110: Skid-steer compatible quick-attach L85: skid-steer compatible quick-attach Loader Model L110 L85 Loader Lift Height L110: 110 in L85: 87.2 in (maximum lift height to pivot pin) Loader Lift Capacity (Full Height) L110: 2,478 lb at pivot pin to full height L85: 1,380 lb (at pivot pin, to full height) Loader Breakout Force L110: 4,938 lb at pivot pin L85: 2,059 lb (at ground level, pivot pin) ▶ WarrantyWarranty Length & Coverage 2-year full machine warranty; 8-year, 3,000-hour powertrain warranty (no deductible, parts and labor) Full machine: 2 years or 2,000 hours; Powertrain: 8 years or 3,000 hours (no deductible, parts and labor) ▶ ITC Company AccessoriesAccessories that fit
