▶ EnginePTO Power — 30.2 hp Alternator — 70 A, 12 V Air Cleaner — Dual dry Engine Type — 4-cycle diesel, water-cooled (natural aspiration) Fuel System — CRDI Displacement — 100.2 in³ Engine Model — 3TNV88C-DKTF No. of Cylinders — 3 Rated Engine Speed — 3000 rpm Cooling System Type — Water-cooled Engine Manufacturer — Yanmar Engine Power (Gross) — 37 hp Engine Emissions Constraints — Tier 4 ▶ WeightWeight with ROPS and Loader — Not Applicable Weight with Cab and Loader — 4,469 lb ▶ HydraulicsPump Type — Dual Gear Pump Steering Flow — 4.6 gpm Implement Flow — 6.3 gpm Total Hydraulic Flow — 10.9 gpm Hydraulic System Type — Separate reservoir, independent fully live Rear Remote Hydraulic Flow — Not Published Overall Hydraulic Pump Flow — 10.9 gpm No. of Optional Remote Valves — 1 No. of Standard Remote Valves — 1 ▶ PTO & HitchPTO Rear — 540 rpm PTO Type — Independent Lift Control Type — Position Hitch Lift Capacity — 2,646 lb Mid-PTO Availability — 2000 (option) Category, 3-Point Hitch — Category I Hitch Lift Capacity (at 24”) — 1,764 lb ▶ Tire OptionsR3 Turf - Rear — 41x14-20 R3 Turf - Front — 27X10.5-15 Tire Size & Options — R1 Agricultural, R3 Turf, R4 Industrial R4 Industrial - Rear — 12.5X20 R4 Industrial - Front — 27X10.5-15 R1 Agricultural - Rear — 12.4-24 R1 Agricultural - Front — 8.0-16 ▶ Fluid CapacityCoolant Capacity — 7.4 qt Crankcase Capacity — 6.0 qt Fuel Tank Capacity — 9.0 gal Front Axle Fluid Capacity — 8.7 qt Transmission / Hydraulic System Capacity — 9.25 gal ▶ Loader & AttachmentsLoader Model — L102 Loader Lift Height — 102 in Loader Breakout Force — 3,435 lb Quick Attach Loader System — L102: Skid-steer compatible quick-attach Loader Lift Capacity (Full Height) — 2,116 lb ▶ Transmission & DrivetrainClutch — single plate dry clutch (8.86" diameter) No. of Speeds — 12F/12R Transmission Type — Partial synchromesh shuttle shift (high/low selector) Max Travel Speed (Forward) — 21.8 mph Max Travel Speed (Reverse) — Not Published Differential Lock & Limited Slip Options — 4WD, Differential Lock ▶ Chassis, Steering & ControlsBrakes — Wet Disc Steering — Hydrostatic Frame Type — Not Published Front Axle Type — 4WD front axle, center-pivot, reverse Eliot type Drawbar Capacity — Not Published Front Axle Rating — Not Published Seat Suspension & Adjustability — Not Published ▶ Dimensions & ManeuverabilityWheelbase — 66.1 in Overall Width — 58.0 in Ground Clearance — 12.8 in Height to Top of ROPS — Not Applicable Height to Top of Cab Model — Not Published Height to Top of ROPS (folded) — Not Applicable Min. Turn Radius without Brakes — 116 in Overall Length with 3-Point Hitch — 128 in ▶ WarrantyWarranty Length & Coverage — Full-machine: 24 months/2,000 hours; Powertrain: 96 months/3,000 hours (whichever comes first) ▶ ITC Company AccessoriesAccessories that fit
