▶ EngineEngine Manufacturer Yanmar Kubota Engine Model 4TNV86T-CR V3307-DI Engine Type 4-cycle, inline, water-cooled, turbocharged diesel 4-cylinder inline, direct injected diesel No. of Cylinders 4 4 Displacement 127.6 in³ 203 in³ Rated Engine Speed 2800 rpm 2600 rpm Engine Power (Gross) 55.1 hp Not Published PTO Power 44.9 hp 55 hp Engine Emissions Constraints Tier 4 Tier 2 Cooling System Type Water-cooled, forced circulation with fan Liquid-cooled Air Cleaner Dry dual element 8 in dry, dual element Fuel System Common Rail Direct Injection Direct injection Alternator 70 A, 12 V ROPS: 45 A, 12 V; Cab: 60 A, 12 V ▶ HydraulicsPump Type Not Published Not Published Implement Flow 9.5 gpm 11.0 gpm Steering Flow 5.0 gpm 6.1 gpm Total Hydraulic Flow 14.5 gpm 17.1 gpm (11.0 + 6.1, computed) Overall Hydraulic Pump Flow 9.5 gpm 17 gpm Hydraulic System Type Independent, fully live hydraulic pump with separate reservoir; position control with isolating and response control Open center Rear Remote Hydraulic Flow 9.5 gpm 11.0 gpm No. of Standard Remote Valves 2 1 No. of Optional Remote Valves Not Published 2nd and 3rd optional ▶ Fluid CapacityFuel Tank Capacity 15.85 gal ROPS: 18.5 gal; Cab: 29.1 gal Coolant Capacity 2.5 gal 8.5 qt Crankcase Capacity 5.6 qt 11.6 qt Transmission / Hydraulic System Capacity 9.24 gal 10.6 gal Front Axle Fluid Capacity 2.64 gal 8.5 qt ▶ PTO & HitchPTO Type Independent Live, independent PTO, hydraulically operated wet clutch with PTO brake PTO Rear 540 rpm 540 rpm Mid-PTO Availability No mid-PTO offered Not Published Category, 3-Point Hitch Category I Category II Hitch Lift Capacity 3,314 lb 4,189 lb Hitch Lift Capacity (at 24”) 2,945 lb 3,307 lb Lift Control Type Position and draft control Position, draft (top link sensing) and mix control ▶ Transmission & DrivetrainTransmission Type 16F/16R Syncro Shuttle w/creeper Synchro shuttle, 8F/8R (4-speed synchronized main, 2-speed Hi/Lo range); hydraulic shuttle optional on cab models No. of Speeds 16 forward, 16 reverse 8F/8R (12F/12R with optional creep) Max Travel Speed (Forward) Not Published 18 mph Max Travel Speed (Reverse) 16.1 mph 18.0 mph Clutch Main: dry single disc, mechanical (10.24 in diameter); PTO: multiple wet disc Dry single plate (synchro shuttle); multiple wet discs (hydraulic shuttle) Differential Lock & Limited Slip Options 4WD (MFWD) standard; bevel-gear rear differential lock Rear differential lock (bevel gears) ▶ Chassis, Steering & ControlsFrame Type Unit frame: engine, clutch housing, transmission and front axle support bolted into one rigid assembly Two-post foldable ROPS (canopy optional); Ultra Grand Cab optional Steering Hydrostatic power steering Hydrostatic power steering Brakes Wet disc, mechanical, foot operated Multiple wet disc, mechanical Seat Suspension & Adjustability Suspension seat with armrests and retractable seat belt, standard Reclining, fully adjustable seat (height, weight, fore-aft, armrests) with retractable seat belt; optional air-suspension seat (cab) Front Axle Type Center-pivot, reverse Elliot type (4WD) 4WD: bevel-gear type, on-the-go engagement Front Axle Rating Not Published Not Published Drawbar Capacity Not Published 2,200 lb ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 141.3 in 2WD: 140.4 in; 4WD: 135.6 in Overall Width 63.8 in 73.2 in Wheelbase 76.2 in 2WD ROPS: 82.1 in; 2WD cab: 84.4 in; 4WD ROPS: 80.7 in; 4WD cab: 83.1 in Ground Clearance 13.8 in 15.4 in Min. Turn Radius without Brakes Not Published 2WD: 11.2 ft; 4WD: 11.8 ft Height to Top of ROPS Not Published 96.9 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 99.6 in 99.8 in ▶ WeightTractor Weight (Base) 4,233 lb 2WD ROPS: 4,650 lb; 4WD ROPS: 4,785 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Titan (USA): R4 Industrial (Std), R1 Agricultural (Opt), R3 Turf (Opt) Standard: 7.50-16 (2WD) or 9.5-24 (4WD) front, 16.9-28 rear R1 Agricultural - Front 9.5x16 2WD: 7.50-16; 4WD: 9.5-24 R1 Agricultural - Rear 14.9x24 16.9-28 R3 Turf - Front Not Published 2WD: 29x12.5-15 or 27x9.5-15 R3 Turf - Rear Not Published 2WD: 21.5L-16.1 or 16.9-24 R4 Industrial - Front 12x16.5 12.5/80-18 (4WD) R4 Industrial - Rear 16.9x24 16.9-24 (4WD) ▶ Loader & AttachmentsQuick Attach Loader System L110: Skid-steer compatible quick-attach LA1153: two-lever quick coupler Loader Model L110 LA1153 Loader Lift Height L110: 110 in LA1153 height position: 132.7 in; LA1153 power position: 117.2 in Loader Lift Capacity (Full Height) L110: 2,478 lb at pivot pin to full height Not Published Loader Breakout Force L110: 4,938 lb at pivot pin Not Published ▶ WarrantyWarranty Length & Coverage Basic 2 years; powertrain 8 years or 3,000 hours, no deductible, parts and labor Not Published ▶ ITC Company AccessoriesAccessories that fit None tagged yet
