Solis S24 Shuttle XL vs TYM T264 | Side-by-side comparison | ITC Resource Center
ITC Resource Center
Tractor Comparison
Pick up to 4tractors and we'll lay every spec sheet out side by side. Same data we publish on the individual model pages, stacked in columns so you can compare numbers at a glance.
No photo
—
SolisS24ShuttleXL
No photo
—
TYMT264
Comparison loaded for 2 tractors.
Spec
SolisS24 Shuttle XL
TYMT264
PTO Power
Not Published
18.3 hp (13.6 kW)
Alternator
Not Published
12 V, 50 A
Air Cleaner
Not Published
Single dry
Engine Type
3‑Cylinder, Naturally Aspirated Diesel
3-cylinder, naturally aspirated diesel
Fuel System
Not Published
IDI
Displacement
80.42 in³ (1318 cc)
71.7 in³ (1,175 cc)
No. of Cylinders
3
3
Rated Engine Speed
2500 rpm
2,800 rpm
Cooling System Type
Not Published
Not Published
Engine Manufacturer
Mitsubishi
TYM
Engine Emissions Constraints
Not Published
Not Published
Engine Power (Gross vs. Net HP)
24 hp (17.9 kW)
Gross: 24 hp (18 kW)
Tractor Weight with Loader
Not Published
2,564 lb (1,163 kg)
Weight with Cab and Loader
Not Applicable
Not Applicable
Weight with ROPS and Loader
Not Published
2,564 lb (1,163 kg)
Pump Type
Not Published
Dual gear pump
Steering Flow
Not Published
10.4 L/min (2.7 gpm)
Implement Flow
Not Published
16.6 L/min (4.4 gpm)
Total Hydraulic Flow
24.6 L/min (6.5 gpm)
26.9 L/min (7.1 gpm)
Hydraulic System Type
Not Published
Open center
Rear Remote Hydraulic Flow
Not Published
Not Published
Overall Hydraulic Pump Flow
Not Published
26.9 L/min (7.1 gpm)
No. of Optional Remote Valves
Not Published
1
No. of Standard Remote Valves
1
0
R3 Turf - Rear
33x15.5-16.5; 13.6x16
Multi-Trac CS 33x12.50-16.5 NHS TL 4PR
R3 Turf - Front
23x8.50-12; 25x8.50-14
Turf Master 23x8.50-12 NHS TL 4PR
Tire Size & Options
R1 Agricultural, R3 Turf, R4 Industrial
R3 Turf, R4 Industrial
R4 Industrial - Rear
33x15.5-16.5
Trac Chief 12-16.5 NHS TL 6PR
R4 Industrial - Front
23x8.50-12
Trac Chief 23x8.50-12 NHS TL 4PR
R1 Agricultural - Rear
8.3x20; 8.3x24; 280/70 R18
Not Published
R1 Agricultural - Front
6x12; 7x14; 6.5/80-12
Not Published
PTO Rear
540/540E rpm
540 rpm
PTO Type
Mechanical
Independent
Lift Control Type
Not Published
Position control
Hitch Lift Capacity
1,323 lb (600 kg)
1,534 lb (696 kg)
Mid-PTO Availability
Not Published
Available
Category, 3-Point Hitch
CAT-1N
Category I
Hitch Lift Capacity (at 24”)
Not Published
1,102 lb (500 kg)
Rear 3-Point Hitch Lift Capacity
1,323 lb (600 kg)
1,534 lb (696 kg)
Coolant Capacity
Not Published
5.9 qt (5.5 L)
Crankcase Capacity
Not Published
4.5 qt (4.3 L)
Fuel Tank Capacity
5.8 gal (22.0 L)
6.6 gal (25 L)
Front Axle Fluid Capacity
Not Published
4.7 qt (4.4 L)
Transmission / Hydraulic System Capacity
Not Published
4.7 gal (17.8 L)
Loader Lift Height
85 in (2159 mm)
86.9 in (2,207 mm)
Loader Breakout Force
1,146 lb (520 kg)
2,059 lb (934 kg)
Price for Backhoe Option
Not Published
TB65
Price for Mid-Mount Mower
Not Published
MM60R-1
Quick Attach Loader System
XB24 (MSL)
TX2000: Quick attachment assembly
Loader Lift Capacity (Full Height)
1,411 lb (640 kg)
1,380 lb (626 kg)
Clutch
Not Published
Dry single plate
No. of Speeds
9F+9R
Infinite 2-Range
Transmission Type
Constant Mesh with Synchromesh Shuttle
HST
Max Travel Speed (Forward)
Not Published
12.9 mph (20.8 km/h)
Max Travel Speed (Reverse)
Not Published
Not Published
Differential Lock & Limited Slip Options
Differential lock: Standard
Not Published
Brakes
Oil immersed brakes; mechanical, foot operated
Wet disc
Steering
Power steering
Hydrostatic
Frame Type
Not Published
Not Published
Front Axle Type
4WD
Not Published
Drawbar Capacity
Not Published
Not Published
Front Axle Rating
Not Published
Not Published
Seat Suspension & Adjustability
Not Published
Not Published
Wheelbase
61.8 in (1570 mm)
58.3 in (1,480 mm)
Overall Width
47.83 in (1215 mm)
52.8 in (1,342 mm)
Ground Clearance
9.44 in (240 mm)
7.7 in (196 mm)
Height to Top of ROPS
91.53 in (2325 mm)
89.8 in (2,280 mm)
Height to Top of Cab Model
Not Applicable
Not Applicable
Height to Top of ROPS (folded)
Not Published
Not Published
Min. Turn Radius without Brakes
Not Published
105.5 in (2,682 mm)
Overall Length with 3-Point Hitch
113.98 in (2895 mm)
107.8 in (2,740 mm)
Financing Options
$0 down financing available for up to 84 months
0% financing for up to 72 months and instant cash rebates. Contact dealer for more information.
Base Price with Loader
Not Published
Not Published
Warranty Length & Coverage
3-year warranty; 7-year limited powertrain
Up to 2 years or until the 2,000 hours mark, bumper-to-bumper warranty; 3000 hours maximum coverage period for parts and labour on drivetrains or powertrains; 12-months warranty period for implements, including loaders and backhoes.
