▶ EngineEngine Manufacturer Yanmar TYM Engine Model 3TNV74F T1100N2 Engine Type Diesel, swirl chamber combustion, naturally aspirated 3-cylinder, naturally aspirated diesel No. of Cylinders 3 3 Displacement 60.6 in³ 71.7 in³ Rated Engine Speed 3000 rpm 2850 rpm Engine Power (Gross) 19 hp 24 hp PTO Power 13.4 hp 21 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Not Published Air Cleaner Dry, single filter element Dry element Fuel System Indirect injection (swirl chamber) IDI Alternator 40 A, 12 V 60 A, 12 V ▶ HydraulicsPump Type Single gear pump with flow divider Dual gear pump Implement Flow 4.17 gpm 4.7 gpm Steering Flow 2.11 gpm 3.3 gpm Total Hydraulic Flow 6.28 gpm (4.17 + 2.11, computed) 7.9 gpm Overall Hydraulic Pump Flow Not Published 7.9 gpm Hydraulic System Type Open center Dual gear pump Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published None No. of Optional Remote Valves Not Published 2 ▶ Fluid CapacityFuel Tank Capacity 6.6 gal 6.0 gal Coolant Capacity 3.7 qt 5.3 qt Crankcase Capacity 2.1 qt 2.9 qt Transmission / Hydraulic System Capacity 3.6 gal 3.7 gal Front Axle Fluid Capacity 2.6 qt 3.5 qt ▶ PTO & HitchPTO Type Transmission-driven (over-running clutch) Live PTO Rear Not Published 540/1000 rpm Mid-PTO Availability Not Published Available Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 1,100 lb 1,499 lb Hitch Lift Capacity (at 24”) 679 lb 974 lb Lift Control Type Position control Position control ▶ Transmission & DrivetrainTransmission Type Hydrostatic (HST) 2400R: Constant Mesh; 2400H: HST No. of Speeds Infinite (2-range HST) 2400R: F6 x R2; 2400H: 2-Range Max Travel Speed (Forward) 7.8 mph 2400R: 9.9 mph; 2400H: 12.1 mph Max Travel Speed (Reverse) 7.8 mph 2400R: 3.9 mph; 2400H: 12.1 mph Clutch Dry, single Dry single plate Differential Lock & Limited Slip Options Not Published Differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Hydrostatic Brakes Wet disc Wet, Multi disc Seat Suspension & Adjustability Not Published Comfortable suspension seat Front Axle Type 4WD (MFWD) 4WD Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 44.5 in 44.2 in Wheelbase 53.1 in 59.1 in Ground Clearance 8.3 in 12.1 in Min. Turn Radius without Brakes Not Published (L) 9.6 ft; (R) 9.5 ft Height to Top of ROPS 86.6 in 87.3 in Height to Top of ROPS (folded) 60 in Not Published Height to Top of Cab Model Not Published Not Published Overall Length 94.2 in 120.3 in (with 3-point hitch) ▶ WeightTractor Weight (Base) 1,433 lb 2400R: 1,792 lb; 2400H: 1,829 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Turf: 18x8.5-10 front, 26x12-12 rear; Industrial: 18x8.5-10 front, 26x12-12 rear R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural - Front 16x7.50-9 6-12 R1 Agricultural - Rear 24x12.00-12 9.5-16 R3 Turf - Front Not Published 23x8.50-12 R3 Turf - Rear Not Published 33x12.50-16.5 R4 Industrial - Front 18x8.5-10 23x8.50-12 R4 Industrial - Rear 26x12-12 12-16.5 ▶ Loader & AttachmentsQuick Attach Loader System BL90: Standard pin-on (skid steer quick-attach optional) BL100S: Quick attach mechanism Loader Model BL90 BL100S Loader Lift Height BL90: 71.3 in BL100S: 88.3 in Loader Lift Capacity (Full Height) BL90: 617 lb (at pivot pin, full height) BL100S: 1,314 lb (at pivot pin) Loader Breakout Force BL90: 1,235 lbf (at pivot pin, ground level) BL100S: 1,960 lb (at pivot pin, ground level) ▶ WarrantyWarranty Length & Coverage Basic two years or 1,000 hours; powertrain 7 years or 2,000 hours Basic 2 years or 2,000 hours; powertrain 3,000 hours maximum, parts and labor; loaders and backhoes 12 months ▶ ITC Company AccessoriesAccessories that fit None tagged yet
