▶ EngineEngine Manufacturer TYM Iseki Engine Model T1100N2 Not Published Engine Type 3-cylinder, naturally aspirated diesel 3-cylinder diesel No. of Cylinders 3 3 Displacement 71.7 in³ 90.9 in³ Rated Engine Speed 2850 rpm 2600 rpm Engine Power (Gross) 24 hp 24 hp PTO Power 21 hp Mech: 20.4 hp; HST: 19.2 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Not Published Liquid cooled Air Cleaner Dry element Not Published Fuel System IDI Not Published Alternator 60 A, 12 V Not Published ▶ HydraulicsPump Type Dual gear pump Two gear-type pumps Implement Flow 4.7 gpm 7.3 gpm Steering Flow 3.3 gpm 3.6 gpm Total Hydraulic Flow 7.9 gpm 10.9 gpm (7.3 + 3.6, computed) Overall Hydraulic Pump Flow 7.9 gpm 10.9 gpm (7.3 + 3.6, computed) Hydraulic System Type Dual gear pump Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves None Not Published No. of Optional Remote Valves 2 Not Published ▶ Fluid CapacityFuel Tank Capacity 6.0 gal 10 gal Coolant Capacity 5.3 qt Not Published Crankcase Capacity 2.9 qt Not Published Transmission / Hydraulic System Capacity 3.7 gal Not Published Front Axle Fluid Capacity 3.5 qt Not Published ▶ PTO & HitchPTO Type Live Mech: Independent; HST: Transmission PTO Rear 540/1000 rpm 540 rpm Mid-PTO Availability Available Not Published Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 1,499 lb 2,205 lb Hitch Lift Capacity (at 24”) 974 lb 1,598 lb Lift Control Type Position control Not Published ▶ Transmission & DrivetrainTransmission Type 2400R: Constant Mesh; 2400H: HST Mech: 8x8 synchro shuttle; HST: 3-range hydrostatic No. of Speeds 2400R: F6 x R2; 2400H: 2-Range Mech: 8x8 synchro shuttle; HST: 3-range hydrostatic Max Travel Speed (Forward) 2400R: 9.9 mph; 2400H: 12.1 mph Not Published Max Travel Speed (Reverse) 2400R: 3.9 mph; 2400H: 12.1 mph Not Published Clutch Dry single plate Not Published Differential Lock & Limited Slip Options Differential lock Not Published ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic Power steering Brakes Wet, Multi disc Not Published Seat Suspension & Adjustability Comfortable suspension seat Not Published Front Axle Type 4WD Not Published Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 44.2 in 52.4 in Wheelbase 59.1 in Not Published Ground Clearance 12.1 in 11 in Min. Turn Radius without Brakes (L) 9.6 ft; (R) 9.5 ft Not Published Height to Top of ROPS 87.3 in 97.6 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published Overall Length 120.3 in (with 3-point hitch) 116.5 in ▶ WeightTractor Weight (Base) 2400R: 1,792 lb; 2400H: 1,829 lb 2,668 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural, R3 Turf, R4 Industrial Not Published R1 Agricultural - Front 6-12 Not Published R1 Agricultural - Rear 9.5-16 Not Published R3 Turf - Front 23x8.50-12 Not Published R3 Turf - Rear 33x12.50-16.5 Not Published R4 Industrial - Front 23x8.50-12 Not Published R4 Industrial - Rear 12-16.5 Not Published ▶ Loader & AttachmentsQuick Attach Loader System BL100S: Quick attach mechanism Skid steer quick attach Loader Model BL100S FL2407X Loader Lift Height BL100S: 88.3 in FL2407X: 94.3 in (at pivot pin) Loader Lift Capacity (Full Height) BL100S: 1,314 lb (at pivot pin) FL2407X: 1,450 lb (to maximum height, at pivot pin) Loader Breakout Force BL100S: 1,960 lb (at pivot pin, ground level) FL2407X: 2,288 lb (at pivot pin) ▶ WarrantyWarranty Length & Coverage Basic 2 years or 2,000 hours; powertrain 3,000 hours maximum, parts and labor; loaders and backhoes 12 months Not Published ▶ ITC Company AccessoriesAccessories that fit None tagged yet
