▶ EngineEngine Manufacturer TYM TYM Engine Model T1700N6 A1100N2 Engine Type 3-cylinder, naturally aspirated diesel 3 cylinder, water-cooled diesel, swirl chamber, natural aspiration No. of Cylinders 3 3 Displacement 104.5 in³ 70.7 in³ Rated Engine Speed 2100 rpm 2600 rpm Engine Power (Gross) 24 hp 24 hp PTO Power 21 hp 18 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Not Published Water-cooled Air Cleaner Dry element Dry element Fuel System IDI (indirect injection) Indirect injection (swirl chamber) Alternator 50 A, 12 V 50 A, 12 V ▶ HydraulicsPump Type Dual gear pump Gear type pump with primary and secondary pumps Implement Flow 7.7 gpm 4.3 gpm Steering Flow 4.2 gpm 3.1 gpm Total Hydraulic Flow 11.9 gpm 7.4 gpm Overall Hydraulic Pump Flow 11.9 gpm 7.7 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Loader: 2 / Rear: 0 0 No. of Optional Remote Valves Up to 4 1 ▶ Fluid CapacityFuel Tank Capacity 7.1 gal 6.08 gal Coolant Capacity 5.3 qt 1.21 gal Crankcase Capacity 4.5 qt 0.79 gal Transmission / Hydraulic System Capacity 2515R: 9 gal; 2515H: 9.8 gal 2.90 gal Front Axle Fluid Capacity 6.8 qt 0.79 gal ▶ PTO & HitchPTO Type Independent Live PTO (6 spline shaft) PTO Rear 540 rpm 540 / 960 rpm Mid-PTO Availability Not Published Optional, 2,500 rpm Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 3,306 lb 1,433 lb Hitch Lift Capacity (at 24”) 2,425 lb 974 lb Lift Control Type Position control Position control ▶ Transmission & DrivetrainTransmission Type 2515R: Synchromesh; 2515H: HST Hydrostatic (HST) No. of Speeds 2515R: F12 x R12; 2515H: 3-Range 3 range (L/M/H) Max Travel Speed (Forward) 2515R: 11.7 mph; 2515H: 15.2 mph 14.8 mph Max Travel Speed (Reverse) 2515R: 11.6 mph; 2515H: 15.2 mph 14.8 mph Clutch 2515R: Dry single plate; 2515H: None (HST) Dry, single plate Differential Lock & Limited Slip Options Differential lock (standard) Mechanical rear differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Steel frame with cast iron axles Steering Hydrostatic power steering Hydrostatic power steering Brakes Wet, multi-disc Wet disc Seat Suspension & Adjustability Suspension seat Adjustable seat, flips up and back for rear backhoe operation Front Axle Type Not Published Selectable 4WD Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 120.9 in 110 in Overall Width 56.3 in 53.9 in Wheelbase 65.7 in 65.7 in Ground Clearance 14.4 in 16.4 in Min. Turn Radius without Brakes L: 124.8 in; R: 121.3 in Not Published Height to Top of ROPS 97.3 in 91.4 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published ▶ WeightTractor Weight (Base) 2515R: 2,989 lb; 2515H: 2,969 lb 2,107 lb Weight with ROPS and Loader 2515R: 3,997 lb; 2515H: 3,977 lb Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural 8-16 / 12.4-24; R3 Turf 27x8.5-15 / 41x14.00; R4 Industrial 10-16.5 / 420/70-24; optional R1 8.0-16 / 12.4-24 and R4 25x8.50-14 / 15x19.5 R1 Agricultural (11.2-20 rear standard), R4 Industrial (25x8.50-14 / 14-17.5) R1 Agricultural - Front 8-16 7-16 6PR R1 Agricultural - Rear 12.4-24 11.2-20 R3 Turf - Front 27x8.5-15, 6PR Not Published R3 Turf - Rear 41x14.00, 4PR Not Published R4 Industrial - Front 10-16.5, 6PR 25x8.50-14 R4 Industrial - Rear 420/70-24, 6PR 14-17.5 ▶ Loader & AttachmentsQuick Attach Loader System BL150: Quick attach assembly (lever-lock) Quick attach front loader Loader Model BL150 BBL300 Loader Lift Height BL150: 104.9 in 87.5 in Loader Lift Capacity (Full Height) BL150: 2,200 lb 1,314 lb Loader Breakout Force BL150: 3,422 lb 1,960 lbf ▶ WarrantyWarranty Length & Coverage 24 months or 2,000 hours bumper-to-bumper (parts and labor); 72 months or 3,000 hours powertrain (non-commercial use, 20 to 70 engine hp); 12 months on front-end loaders, backhoes and mid-mount mowers Engine and powertrain: 72 months or 2,000 hours; other tractor parts: 24 months or 1,000 hours; loader and backhoe: 24 months from shipment, 12 months from sale, or 500 hours ▶ ITC Company AccessoriesAccessories that fit
