▶ EngineEngine Manufacturer TYM TYM Engine Model T1100N2 A1100N2 Engine Type 3-cylinder, naturally aspirated diesel 3 cylinder, water-cooled diesel, swirl chamber, natural aspiration No. of Cylinders 3 3 Displacement 71.7 in³ 70.7 in³ Rated Engine Speed 2850 rpm 2600 rpm Engine Power (Gross) 24 hp 24 hp PTO Power 18 hp 18 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Water-cooled Air Cleaner Dry element Dry element Fuel System IDI Indirect injection (swirl chamber) Alternator 60 A, 12 V 50 A, 12 V ▶ HydraulicsPump Type Dual gear pump Gear type pump with primary and secondary pumps Implement Flow 4.65 gpm 4.3 gpm Steering Flow 3.3 gpm 3.1 gpm Total Hydraulic Flow 7.9 gpm 7.4 gpm Overall Hydraulic Pump Flow 7.9 gpm 7.7 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow 3.1 gpm Not Published No. of Standard Remote Valves 0 0 No. of Optional Remote Valves 2 1 ▶ Fluid CapacityFuel Tank Capacity 6.0 gal 6.08 gal Coolant Capacity 5.3 qt 1.21 gal Crankcase Capacity 2.9 qt 0.79 gal Transmission / Hydraulic System Capacity 3.7 gal 2.90 gal Front Axle Fluid Capacity 3.5 qt 0.79 gal ▶ PTO & HitchPTO Type Live Live PTO (6 spline shaft) PTO Rear 540/1000 rpm 540 / 960 rpm Mid-PTO Availability Mid-PTO available; 2,500 RPM mid-mount PTO option Optional, 2,500 rpm Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 1,499 lb 1,433 lb Hitch Lift Capacity (at 24”) 974 lb 974 lb Lift Control Type Position control Position control ▶ Transmission & DrivetrainTransmission Type HST Hydrostatic (HST) No. of Speeds 3-Range 3 range (L/M/H) Max Travel Speed (Forward) 17 mph 14.8 mph Max Travel Speed (Reverse) Not Published 14.8 mph Clutch Dry single plate Dry, single plate Differential Lock & Limited Slip Options Differential lock Mechanical rear differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Steel frame with cast iron axles Steering Hydrostatic Hydrostatic power steering Brakes Wet, Multi disc Wet disc Seat Suspension & Adjustability Comfortable suspension seat Adjustable seat, flips up and back for rear backhoe operation Front Axle Type Selectable four wheel drive Selectable 4WD Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 122.9 in 110 in Overall Width 53.8 in 53.9 in Wheelbase 65.7 in 65.7 in Ground Clearance 15.1 in 16.4 in Min. Turn Radius without Brakes (L) 115.4 in; (R) 114.2 in Not Published Height to Top of ROPS 91.5 in 91.4 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published ▶ WeightTractor Weight (Base) 2,106 lb 2,107 lb Weight with ROPS and Loader 2,760 lb Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Front: R1 Agricultural 6-12 | R3 Turf 23x8.50-12 | R4 Industrial 25x8.50-14; Rear: R1 Agricultural 9.5-16 | R3 Turf 33x12.50-16.5 | R4 Industrial 14-17.5 R1 Agricultural (11.2-20 rear standard), R4 Industrial (25x8.50-14 / 14-17.5) R1 Agricultural - Front 7-16 7-16 6PR R1 Agricultural - Rear 11.2-20 11.2-20 R3 Turf - Front 23x8.50-12 Not Published R3 Turf - Rear 33x12.50-16.5 Not Published R4 Industrial - Front 25x8.50-14 25x8.50-14 R4 Industrial - Rear 14-17.5 14-17.5 ▶ Loader & AttachmentsQuick Attach Loader System BL110S: Quick attach mechanism Quick attach front loader Loader Model BL110S BBL300 Loader Lift Height BL110S: 91.1 in 87.5 in Loader Lift Capacity (Full Height) BL110S: 1,373 lb 1,314 lb Loader Breakout Force BL110S: 2,077 lb 1,960 lbf ▶ WarrantyWarranty Length & Coverage Up to 2 years or until the 2,000 hour mark, bumper-to-bumper warranty; 3000 hours maximum coverage period for parts and labour on drivetrains or powertrains; 12-months warranty period for implements, including loaders and backhoes. Engine and powertrain: 72 months or 2,000 hours; other tractor parts: 24 months or 1,000 hours; loader and backhoe: 24 months from shipment, 12 months from sale, or 500 hours ▶ ITC Company AccessoriesAccessories that fit
