▶ EngineEngine Manufacturer TYM Yanmar Engine Model T1100N2 3TNV80F Engine Type 3-cylinder, naturally aspirated diesel Water cooled, 4-cycle diesel No. of Cylinders 3 3 Displacement 71.7 in³ 77.3 in³ Rated Engine Speed 2850 rpm 3000 rpm Engine Power (Gross) 24 hp 24 hp PTO Power 18 hp 18.8 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Water cooled, forced circulation Air Cleaner Dry element Single element Fuel System IDI Indirect fuel injection Alternator 60 A, 12 V 40 A, 12 V ▶ HydraulicsPump Type Dual gear pump Not Published Implement Flow 4.65 gpm 4.18 gpm Steering Flow 3.3 gpm 2.77 gpm Total Hydraulic Flow 7.9 gpm 6.95 gpm Overall Hydraulic Pump Flow 7.9 gpm 6.95 gpm Hydraulic System Type Open center Live, independent Rear Remote Hydraulic Flow 3.1 gpm Not Published No. of Standard Remote Valves None 1 No. of Optional Remote Valves 2 Not Published ▶ Fluid CapacityFuel Tank Capacity 6.0 gal 5.81 gal Coolant Capacity 5.3 qt 0.96 gal Crankcase Capacity 2.9 qt 0.71 gal Transmission / Hydraulic System Capacity 3.7 gal 3.83 gal Front Axle Fluid Capacity 3.5 qt 0.85 gal ▶ PTO & HitchPTO Type Live Independent PTO Rear 540/1000 rpm 540 rpm Mid-PTO Availability Optional (Mid-PTO kit) 2,000 rpm Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 1,499 lb 1,323 lb Hitch Lift Capacity (at 24”) 974 lb 1,058 lb Lift Control Type Position control Position ▶ Transmission & DrivetrainTransmission Type HST 2-range hydrostatic No. of Speeds 3-Range 2 ranges (high/low), infinite forward and reverse Max Travel Speed (Forward) 17 mph 11.2 mph Max Travel Speed (Reverse) Not Published Not Published Clutch Dry single plate Electro-hydraulic PTO clutch assembly (hydrostatic drive, no traction clutch) Differential Lock & Limited Slip Options Differential lock 4WD with differential lock (bevel gears with diff-lock) ▶ Chassis, Steering & ControlsFrame Type Not Published Unit frame: engine, transmission and front axle support bolted together into a rigid assembly Steering Hydrostatic Hydrostatic power steering Brakes Wet, Multi disc Wet disc, independent foot pedals that lock together Seat Suspension & Adjustability Comfortable suspension seat Suspension seat with armrests & retractable seat belt Front Axle Type 4WD 4WD, center-pivot reverse Eliot type Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 53.8 in 45.8 in Wheelbase 65.7 in 57.5 in Ground Clearance 15.1 in 9.4 in Min. Turn Radius without Brakes (L) 9.6 ft; (R) 9.5 ft Not Published Height to Top of ROPS 91.5 in 91.3 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published Overall Length 122.9 in (with 3-point hitch) 100.5 in ▶ WeightTractor Weight (Base) 2,106 lb 1,610 lb Weight with ROPS and Loader 2,760 lb (2,106 + 654, computed) 2,091 lb (1,610 + 481, computed) Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 ag: 7-16 front, 11.2-20 rear; R3 turf: 23x8.50-12 front, 33x12.50-16.5 rear; R4 industrial: 23x8.50-12 front, 12-16.5 rear Titan: R4 Industrial (Std), R3 Turf (Opt), R1 Agricultural (Opt), R14 (Opt) R1 Agricultural - Front 7-16 6-12 R1 Agricultural - Rear 11.2-20 9.5-16 R3 Turf - Front 23x8.50-12 20x8-10 R3 Turf - Rear 33x12.50-16.5 29x12.5-15 R4 Industrial - Front 23x8.50-12 20x8-10 R4 Industrial - Rear 12-16.5 27x12.5-15 ▶ Loader & AttachmentsQuick Attach Loader System BL110S: Quick attach mechanism L75: skid-steer compatible quick-attach Loader Model BL110S L75 Loader Lift Height BL110S: 91.1 in L75: 75.3 in (maximum lift height to pivot pin) Loader Lift Capacity (Full Height) BL110S: 1,373 lb (at pivot pin) L75: 947 lb (at pivot pin, to full height) Loader Breakout Force BL110S: 2,077 lb (at pivot pin, ground level) L75: 1,680 lb (at pivot pin) ▶ WarrantyWarranty Length & Coverage Basic 2 years or 2,000 hours; powertrain 3,000 hours maximum, parts and labor; loaders and backhoes 12 months Government and non-institutional: basic 24 months or 2,000 hours, powertrain 96 months or 3,000 hours; all other use: basic 24 months or 2,000 hours, powertrain 36 months or 3,000 hours ▶ ITC Company AccessoriesAccessories that fit
