▶ EngineEngine Manufacturer TYM TYM Engine Model T1100N2 T1100N2 Engine Type 3-cylinder, naturally aspirated diesel 3-cylinder, naturally aspirated diesel No. of Cylinders 3 3 Displacement 71.7 in³ 71.7 in³ Rated Engine Speed 2850 rpm 2850 rpm Engine Power (Gross) 24 hp 24 hp PTO Power 18 hp 21 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Not Published Air Cleaner Dry element Dry element Fuel System IDI IDI Alternator 60 A, 12 V 60 A, 12 V ▶ HydraulicsPump Type Dual gear pump Dual gear pump Implement Flow 4.65 gpm 4.7 gpm Steering Flow 3.3 gpm 3.3 gpm Total Hydraulic Flow 7.9 gpm 7.9 gpm Overall Hydraulic Pump Flow 7.9 gpm 7.9 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow 3.1 gpm Not Published No. of Standard Remote Valves 0 0 No. of Optional Remote Valves 2 2 ▶ Fluid CapacityFuel Tank Capacity 6.0 gal 6.0 gal Coolant Capacity 5.3 qt 5.3 qt Crankcase Capacity 2.9 qt 2.9 qt Transmission / Hydraulic System Capacity 3.7 gal 3.7 gal Front Axle Fluid Capacity 3.5 qt 3.5 qt ▶ PTO & HitchPTO Type Live Live PTO Rear 540/1000 rpm 540/1000 rpm Mid-PTO Availability Mid-PTO available; 2,500 RPM mid-mount PTO option Available Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 1,499 lb 1,499 lb Hitch Lift Capacity (at 24”) 974 lb 974 lb Lift Control Type Position control Position control ▶ Transmission & DrivetrainTransmission Type HST 2400R: Constant Mesh; 2400H: HST No. of Speeds 3-Range 2400R: F6 x R2; 2400H: 2-Range Max Travel Speed (Forward) 17 mph 2400R: 9.9 mph; 2400H: 12.1 mph Max Travel Speed (Reverse) Not Published 2400R: 3.9 mph; 2400H: 12.1 mph Clutch Dry single plate Dry single plate Differential Lock & Limited Slip Options Differential lock Differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic Hydrostatic Brakes Wet, Multi disc Wet, Multi disc Seat Suspension & Adjustability Comfortable suspension seat Comfortable suspension seat Front Axle Type Selectable four wheel drive 4WD Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 122.9 in 120.3 in Overall Width 53.8 in 44.2 in Wheelbase 65.7 in 59.1 in Ground Clearance 15.1 in 12.1 in Min. Turn Radius without Brakes (L) 115.4 in; (R) 114.2 in (L) 115.4 in; (R) 114.2 in Height to Top of ROPS 91.5 in 87.3 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published ▶ WeightTractor Weight (Base) 2,106 lb 2400R: 1,792 lb; 2400H: 1,829 lb Weight with ROPS and Loader 2,760 lb Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Front: R1 Agricultural 6-12 | R3 Turf 23x8.50-12 | R4 Industrial 25x8.50-14; Rear: R1 Agricultural 9.5-16 | R3 Turf 33x12.50-16.5 | R4 Industrial 14-17.5 R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural - Front 7-16 6-12 R1 Agricultural - Rear 11.2-20 9.5-16 R3 Turf - Front 23x8.50-12 23x8.50-12 R3 Turf - Rear 33x12.50-16.5 33x12.50-16.5 R4 Industrial - Front 25x8.50-14 23x8.50-12 R4 Industrial - Rear 14-17.5 12-16.5 ▶ Loader & AttachmentsQuick Attach Loader System BL110S: Quick attach mechanism BL100S: Quick attach mechanism Loader Model BL110S BL100S Loader Lift Height BL110S: 91.1 in BL100S: 88.3 in Loader Lift Capacity (Full Height) BL110S: 1,373 lb BL100S: 1,314 lb Loader Breakout Force BL110S: 2,077 lb BL100S: 1,960 lb ▶ WarrantyWarranty Length & Coverage Up to 2 years or until the 2,000 hour mark, bumper-to-bumper warranty; 3000 hours maximum coverage period for parts and labour on drivetrains or powertrains; 12-months warranty period for implements, including loaders and backhoes. Up to 2 years or until the 2,000 hour mark, bumper-to-bumper warranty; 3000 hours maximum coverage period for parts and labour on drivetrains or powertrains; 12-months warranty period for implements, including loaders and backhoes. ▶ ITC Company AccessoriesAccessories that fit
