▶ EngineEngine Manufacturer TYM LS Mtron Engine Model T1700N2 L3CRV-T5 Engine Type 3-cylinder, naturally aspirated diesel 3-cylinder, turbocharged, liquid-cooled diesel No. of Cylinders 3 3 Displacement 104.5 in³ 114.7 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 35 hp 35 hp PTO Power 30 hp Gear: 29.7 hp; HST: 28 hp Engine Emissions Constraints Tier 4 Tier 4B (final) Cooling System Type Not Published Liquid cooled Air Cleaner Dry element Replaceable primary and inner elements Fuel System IDI (indirect injection) Electronically controlled common rail direct injection Alternator 50 A, 12 V 70 A, 12 V ▶ HydraulicsPump Type Dual gear pump Gear Implement Flow 7.7 gpm 8.2 gpm Steering Flow 4.2 gpm Gear: 4.2 gpm; HST: 5.3 gpm Total Hydraulic Flow 11.9 gpm Gear: 12.4 gpm; HST: 13.5 gpm Overall Hydraulic Pump Flow 11.9 gpm Gear: 12.4 gpm; HST: 13.5 gpm Hydraulic System Type Dual gear pump Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Loader: 2 / Rear: 0 1 No. of Optional Remote Valves Up to 4 Up to 2 (second valve optional) ▶ Fluid CapacityFuel Tank Capacity 7.1 gal 10.5 gal Coolant Capacity 5.3 qt 7.5 qt Crankcase Capacity 4.5 qt 5.8 qt Transmission / Hydraulic System Capacity 3515R: 9 gal; 3515H: 9.8 gal 8.5 gal Front Axle Fluid Capacity 6.8 qt 6.87 qt ▶ PTO & HitchPTO Type Independent Independent, electro-hydraulic engagement PTO Rear 540 rpm 540 rpm Mid-PTO Availability Not Published Standard (2000 rpm) Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 3,306 lb 1,808 lb Hitch Lift Capacity (at 24”) 2,425 lb 1,345 lb Lift Control Type Position control Position control (draft control optional) ▶ Transmission & DrivetrainTransmission Type 3515R: Synchromesh; 3515H: HST Gear: 12x12 synchronized shuttle shift (SSS); HST: 3-range hydrostatic, dual pedal No. of Speeds 3515R: F12 x R12; 3515H: 3-Range Gear: 12F/12R; HST: 3-range Max Travel Speed (Forward) 3515R: 14.4 mph; 3515H: 18.8 mph Gear: 14.2 mph; HST: 14.8 mph Max Travel Speed (Reverse) 3515R: 14.3 mph; 3515H: 18.7 mph Gear: 13.63 mph; HST: 13.60 mph Clutch 3515R: Dry single plate; 3515H: None (HST) Gear: dry single disc (9.4 in); HST: n/a Differential Lock & Limited Slip Options Differential lock (standard) Mechanical rear differential lock (pedal) ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Power steering Brakes Wet, multi-disc Wet multi-disc Seat Suspension & Adjustability Suspension seat Adjustable suspension seat (fore/aft, weight and height adjustment) Front Axle Type Not Published Four-wheel drive (FWD) Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 56.3 in 66.4 in Wheelbase 65.7 in 66 in Ground Clearance 14.4 in Not Published Min. Turn Radius without Brakes L: 124.8 in; R: 121.3 in 9.2 ft (with brake applied) Height to Top of ROPS 97.3 in 92.7 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published Overall Length 120.9 in (with 3-point hitch) 119 in ▶ WeightTractor Weight (Base) 3515R: 3,183 lb; 3515H: 3,163 lb Gear: 2,804 lb; HST: 2,870 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural 8-16 / 12.4-24; R3 Turf 27x8.5-15 6PR / 41x14.00 4PR; R4 Industrial 10-16.5 6PR / 420/70-24 6PR R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural - Front 8-16 7-14 R1 Agricultural - Rear 12.4-24 11.2-24 R3 Turf - Front 27x8.5-15, 6PR 25x8.50-14 R3 Turf - Rear 41x14.00, 4PR 41x14.00-20 R4 Industrial - Front 10-16.5, 6PR 25x8.50-14 R4 Industrial - Rear 420/70-24, 6PR 43x16.00-20 ▶ Loader & AttachmentsQuick Attach Loader System Not Published Tool-free loader mount; optional skid-steer quick-attach plates Loader Model BL150 250TLA Loader Lift Height BL150: 104.9 in 250TLA: 104 in (at pivot pin) Loader Lift Capacity (Full Height) BL150: 2,200 lb (at pivot pin) 250TLA: 1,822 lb (at bucket pivot pin, max height) Loader Breakout Force BL150: 3,422 lb (at pivot pin, ground level) 250TLA: 3,257 lb (at bucket pivot pin) ▶ WarrantyWarranty Length & Coverage Basic 24 months or 2,000 hours, parts and labor; non-commercial, 20 to 70 engine hp: powertrain 72 months or 3,000 hours; loaders, backhoes and mid-mount mowers 12 months Basic 2 years or 750 hours; powertrain 4 more years (6 years or 1,500 hours total) ▶ ITC Company AccessoriesAccessories that fit None tagged yet
