▶ EngineEngine Manufacturer Kukje TYM Engine Model 3T90L-ATC T1700N2 Engine Type Diesel, liquid-cooled 3-cylinder, naturally aspirated diesel No. of Cylinders 3 3 Displacement 109.5 in³ 104.5 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 35 hp 35 hp PTO Power Not Published 30 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Liquid-cooled Not Published Air Cleaner Dry element Dry element Fuel System Not Published IDI (indirect injection) Alternator Not Published 50 A, 12 V ▶ HydraulicsPump Type Not Published Dual gear pump Implement Flow Not Published 7.7 gpm Steering Flow Not Published 4.2 gpm Total Hydraulic Flow Not Published 11.9 gpm Overall Hydraulic Pump Flow Not Published 11.9 gpm Hydraulic System Type Not Published Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Loader: 2 / Rear: 0 No. of Optional Remote Valves Not Published Up to 4 ▶ Fluid CapacityFuel Tank Capacity 10.6 gal 7.1 gal Coolant Capacity Not Published 5.3 qt Crankcase Capacity Not Published 4.5 qt Transmission / Hydraulic System Capacity Not Published 3515R: 9 gal; 3515H: 9.8 gal Front Axle Fluid Capacity Not Published 6.8 qt ▶ PTO & HitchPTO Type Transmission-driven Independent PTO Rear 540 / 1000 rpm 540 rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category I Category I Hitch Lift Capacity Not Published 3,306 lb Hitch Lift Capacity (at 24”) Not Published 2,425 lb Lift Control Type Not Published Position control ▶ Transmission & DrivetrainTransmission Type Synchronized shuttle 3515R: Synchromesh; 3515H: HST No. of Speeds 12F/12R 3515R: F12 x R12; 3515H: 3-Range Max Travel Speed (Forward) Not Published 3515R: 14.4 mph; 3515H: 18.8 mph Max Travel Speed (Reverse) Not Published 3515R: 14.3 mph; 3515H: 18.7 mph Clutch Not Published 3515R: Dry single plate; 3515H: None (HST) Differential Lock & Limited Slip Options Not Published Differential lock (standard) ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Hydrostatic power steering Brakes Wet disc Wet, multi-disc Seat Suspension & Adjustability Not Published Suspension seat Front Axle Type 4WD (MFWD) Not Published Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 129.7 in 120.9 in Overall Width 60 in 56.3 in Wheelbase 68.8 in 65.7 in Ground Clearance 12.2 in 14.4 in Min. Turn Radius without Brakes Not Published L: 124.8 in; R: 121.3 in Height to Top of ROPS 86.4 in 97.3 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published ▶ WeightTractor Weight (Base) 3,624 lb 3515R: 3,183 lb; 3515H: 3,163 lb Weight with ROPS and Loader Not Published HST: 4,171 lb; Gear: 4,191 lb Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Agricultural: 8-18 front / 12.4-28 rear R1 Agricultural 8-16 / 12.4-24; R3 Turf 27x8.5-15 / 41x14.00; R4 Industrial 10-16.5 / 420/70-24; optional R1 8.0-16 / 12.4-24 and R4 25x8.50-14 / 15x19.5 R1 Agricultural - Front 8-18 8-16 R1 Agricultural - Rear 12.4-28 12.4-24 R3 Turf - Front Not Published 27x8.5-15, 6PR R3 Turf - Rear Not Published 41x14.00, 4PR R4 Industrial - Front Not Published 10-16.5, 6PR R4 Industrial - Rear Not Published 420/70-24, 6PR ▶ Loader & AttachmentsQuick Attach Loader System Not Published BL150: Quick attach assembly (lever-lock) Loader Model Not Published BL150 Loader Lift Height Not Published BL150: 104.9 in Loader Lift Capacity (Full Height) Not Published BL150: 2,200 lb Loader Breakout Force Not Published BL150: 3,422 lb ▶ WarrantyWarranty Length & Coverage Not Published 24 months or 2,000 hours bumper-to-bumper (parts and labor); 72 months or 3,000 hours powertrain (non-commercial use, 20 to 70 engine hp); 12 months on front-end loaders, backhoes and mid-mount mowers ▶ ITC Company AccessoriesAccessories that fit None tagged yet
