▶ EngineEngine Manufacturer TYM LS Mtron Engine Model T1700N2 L3CRV-T5 Engine Type 3-cylinder, naturally aspirated diesel 3-cylinder, turbocharged, liquid-cooled diesel No. of Cylinders 3 3 Displacement 104.5 in³ 114.7 in³ Rated Engine Speed 2500 rpm 2600 rpm Engine Power (Gross) 35 hp 35 hp PTO Power 28 hp Gear: 29.7 hp; HST: 28 hp Engine Emissions Constraints Tier 4 Tier 4B (final) Cooling System Type Liquid-cooled Liquid cooled Air Cleaner Dry element Replaceable primary and inner elements Fuel System IDI Electronically controlled common rail direct injection Alternator 50 A, 12 V 70 A, 12 V ▶ HydraulicsPump Type Dual gear pump Gear Implement Flow 7.7 gpm 8.2 gpm Steering Flow 4.2 gpm Gear: 4.2 gpm; HST: 5.3 gpm Total Hydraulic Flow 11.9 gpm Gear: 12.4 gpm; HST: 13.5 gpm Overall Hydraulic Pump Flow 11.9 gpm Gear: 12.4 gpm; HST: 13.5 gpm Hydraulic System Type Not Published Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Optional (up to 4) 1 No. of Optional Remote Valves Up to 4 Up to 2 (second valve optional) ▶ Fluid CapacityFuel Tank Capacity 11.8 gal 10.5 gal Coolant Capacity 6 qt 7.5 qt Crankcase Capacity 4.5 qt 5.8 qt Transmission / Hydraulic System Capacity 3620R: 10.3 gal; 3620H: 11.1 gal 8.5 gal Front Axle Fluid Capacity 6.8 qt 6.87 qt ▶ PTO & HitchPTO Type Independent Independent, electro-hydraulic engagement PTO Rear 540/750 rpm 540 rpm Mid-PTO Availability Not Published Standard (2000 rpm) Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 3,306 lb 1,808 lb Hitch Lift Capacity (at 24”) 2,425 lb 1,345 lb Lift Control Type Position control Position control (draft control optional) ▶ Transmission & DrivetrainTransmission Type 3620R: Synchromesh; 3620H: HST Gear: 12x12 synchronized shuttle shift (SSS); HST: 3-range hydrostatic, dual pedal No. of Speeds 3620R: F16 x R16; 3620H: 4-Range Gear: 12F/12R; HST: 3-range Max Travel Speed (Forward) 3620R: 16 mph; 3620H: 19.5 mph Gear: 14.2 mph; HST: 14.8 mph Max Travel Speed (Reverse) 3620R: 15.2 mph; 3620H: 19.5 mph Gear: 13.63 mph; HST: 13.60 mph Clutch 3620R: Dry single type; 3620H: No clutch (HST) Gear: dry single disc (9.4 in); HST: n/a Differential Lock & Limited Slip Options Standard differential lock Mechanical rear differential lock (pedal) ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic Power steering Brakes Wet, multi-disc Wet multi-disc Seat Suspension & Adjustability Suspension seat Adjustable suspension seat (fore/aft, weight and height adjustment) Front Axle Type 4WD (selectable 2WD/4WD) Four-wheel drive (FWD) Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 64.9 in 66.4 in Wheelbase 71.1 in 66 in Ground Clearance 15.5 in Not Published Min. Turn Radius without Brakes L: 128.7 in; R: 126.0 in 9.2 ft (with brake applied) Height to Top of ROPS 98.4 in 92.7 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published Overall Length 127.4 in (with 3-point hitch) 119 in ▶ WeightTractor Weight (Base) 3,754 lb (with ROPS) Gear: 2,804 lb; HST: 2,870 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural - Front 9.5-16 7-14 R1 Agricultural - Rear 12.4-28 11.2-24 R3 Turf - Front 27x8.5-15 / 29x12.5-15 25x8.50-14 R3 Turf - Rear 41x14-20 / 44x18-20 41x14.00-20 R4 Industrial - Front 10x16.5 25x8.50-14 R4 Industrial - Rear 420/70x24 43x16.00-20 ▶ Loader & AttachmentsQuick Attach Loader System BL200: Quick attach mechanism Tool-free loader mount; optional skid-steer quick-attach plates Loader Model BL200 250TLA Loader Lift Height BL200: 106.6 in 250TLA: 104 in (at pivot pin) Loader Lift Capacity (Full Height) BL200: 2,701 lb (at pivot pin) 250TLA: 1,822 lb (at bucket pivot pin, max height) Loader Breakout Force BL200: 3,660 lb (at pivot pin, ground level) 250TLA: 3,257 lb (at bucket pivot pin) ▶ WarrantyWarranty Length & Coverage Basic 2 years or 2,000 hours; powertrain 3,000 hours maximum, parts and labor; loaders and backhoes 12 months Basic 2 years or 750 hours; powertrain 4 more years (6 years or 1,500 hours total) ▶ ITC Company AccessoriesAccessories that fit None tagged yet
