▶ EngineEngine Manufacturer TYM LS Mtron Engine Model T1700N2 L3C19-T5 Engine Type 3-cylinder, naturally aspirated diesel 3-cylinder, turbocharged, liquid-cooled diesel No. of Cylinders 3 3 Displacement 104.5 in³ 114.7 in³ Rated Engine Speed 2500 rpm 2600 rpm Engine Power (Gross) 35 hp 35 hp PTO Power 28 hp Gear: 29.7 hp; HST: 28 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Pressurized liquid with recirculating bypass Air Cleaner Dry element Dual element (primary and inner safety element) Fuel System IDI High pressure common rail, ECU-controlled timing Alternator 50 A, 12 V 70 A, 12 V ▶ HydraulicsPump Type Dual gear pump Gear Implement Flow 7.7 gpm 8.2 gpm Steering Flow 4.2 gpm Gear: 4.2 gpm; HST: 5.3 gpm Total Hydraulic Flow 11.9 gpm Gear: 12.4 gpm; HST: 13.5 gpm Overall Hydraulic Pump Flow 11.9 gpm Gear: 12.4 gpm; HST: 13.5 gpm Hydraulic System Type Not Published Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Optional (up to 4) Not Published No. of Optional Remote Valves Up to 4 1 or 2 ▶ Fluid CapacityFuel Tank Capacity 11.8 gal 7.4 gal Coolant Capacity 6 qt 7.5 qt Crankcase Capacity 4.5 qt 5.8 qt Transmission / Hydraulic System Capacity 3620R: 10.3 gal; 3620H: 11.1 gal 8.5 gal Front Axle Fluid Capacity 6.8 qt 6.9 qt ▶ PTO & HitchPTO Type Independent Independent, electro-hydraulic engagement PTO Rear 540/750 rpm 540 rpm Mid-PTO Availability Not Published HST: Standard; Gear: Optional (2,000 rpm) Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 3,306 lb 1,808 lb Hitch Lift Capacity (at 24”) 2,425 lb 1,433 lb Lift Control Type Position control Position control ▶ Transmission & DrivetrainTransmission Type 3620R: Synchromesh; 3620H: HST Gear: 12x12 synchronized shuttle; HST: 3-range hydrostatic, dual pedal No. of Speeds 3620R: F16 x R16; 3620H: 4-Range Gear: 12F/12R; HST: Infinite (3 ranges) Max Travel Speed (Forward) 3620R: 16 mph; 3620H: 19.5 mph Gear: 14.2 mph; HST: 14.8 mph Max Travel Speed (Reverse) 3620R: 15.2 mph; 3620H: 19.5 mph Gear: 13.63 mph; HST: 14.96 mph Clutch 3620R: Dry single type; 3620H: No clutch (HST) Gear: 9.4 in single dry disc; HST: Not applicable Differential Lock & Limited Slip Options Standard differential lock Mechanical rear differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic Power steering Brakes Wet, multi-disc Wet, multi-disc Seat Suspension & Adjustability Suspension seat Mechanical suspension seat, fore/aft adjustable, tilting Front Axle Type 4WD (selectable 2WD/4WD) 4WD Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 64.9 in 66.5 in Wheelbase 71.1 in 67.5 in Ground Clearance 15.5 in 13 in Min. Turn Radius without Brakes L: 128.7 in; R: 126.0 in 123 in (left turn); 124 in (right turn) Height to Top of ROPS 98.4 in 87.7 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published Overall Length 127.4 in (with 3-point hitch) 121 in ▶ WeightTractor Weight (Base) 3,754 lb (with ROPS) 3,067 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural - Front 9.5-16 7-14 R1 Agricultural - Rear 12.4-28 11.2-24 R3 Turf - Front 27x8.5-15 / 29x12.5-15 25x8.50-14 R3 Turf - Rear 41x14-20 / 44x18-20 41x14.00-20 R4 Industrial - Front 10x16.5 25x8.50-14 R4 Industrial - Rear 420/70x24 43x16-20 ▶ Loader & AttachmentsQuick Attach Loader System BL200: Quick attach mechanism 140TL: tool-free quick-mount system; optional skid-steer quick-attach plates Loader Model BL200 140TL Loader Lift Height BL200: 106.6 in 140TL: 91.5 in (at pivot pin) Loader Lift Capacity (Full Height) BL200: 2,701 lb (at pivot pin) 140TL: 1,500 lb (at bucket pivot pin, max height) Loader Breakout Force BL200: 3,660 lb (at pivot pin, ground level) 140TL: 2,700 lb (at bucket pivot pin) ▶ WarrantyWarranty Length & Coverage Basic 2 years or 2,000 hours; powertrain 3,000 hours maximum, parts and labor; loaders and backhoes 12 months Basic 2 years or 750 hours; powertrain to 6 years or 1,500 hours total ▶ ITC Company AccessoriesAccessories that fit None tagged yet
