▶ EngineEngine Manufacturer Yanmar KIOTI (Daedong) Engine Model 4TNE-88 3F183T Engine Type Diesel, liquid-cooled KIOTI 3 Cylinder, In-Line Vertical, Water-Cooled 4-Cycle Turbo Diesel, CRDI No. of Cylinders 4 3 Displacement 133.6 in³ 111.4 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 45 hp 45 hp PTO Power 40 hp 33.9 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Liquid-cooled Water-cooled Air Cleaner Dry element Dry type element Fuel System Not Published Common Rail Direct Injection (CRDI) Alternator Not Published Not Published ▶ HydraulicsPump Type Not Published Gear Implement Flow Not Published 9.6 gpm Steering Flow Not Published 8.2 gpm Total Hydraulic Flow Not Published 17.9 gpm Overall Hydraulic Pump Flow Not Published 17.9 gpm Hydraulic System Type Not Published Open Center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published 1 No. of Optional Remote Valves Not Published 1 ▶ Fluid CapacityFuel Tank Capacity 10.6 gal 14.8 gal Coolant Capacity Not Published 2.0 gal Crankcase Capacity Not Published 1.58 gal Transmission / Hydraulic System Capacity Not Published 11.89 gal Front Axle Fluid Capacity Not Published 1.8 gal ▶ PTO & HitchPTO Type Transmission-driven Independent PTO Rear 540 / 1000 rpm 540 rpm Mid-PTO Availability Not Published Optional (2,000 rpm) Category, 3-Point Hitch Category I Category I Hitch Lift Capacity Not Published 3,538 lb Hitch Lift Capacity (at 24”) Not Published 3,177 lb Lift Control Type Not Published Position with Draft Control ▶ Transmission & DrivetrainTransmission Type Synchronized shuttle Hydrostatic No. of Speeds 12F/12R 3 Range Max Travel Speed (Forward) Not Published 16.52 mph Max Travel Speed (Reverse) Not Published 16.52 mph Clutch Not Published Not Published Differential Lock & Limited Slip Options Not Published Differential Lock: Rear (Standard) ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Hydrostatic Power Steering Brakes Wet disc Wet Multi Disc Seat Suspension & Adjustability Not Published Adjustable Seat Front Axle Type 4WD (MFWD) Not Published Front Axle Rating Not Published Not Published Drawbar Capacity Not Published 1,655 lb (max. drawbar vertical load) ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 129.7 in 139.6 in Overall Width 60 in 65.6 in Wheelbase 68.8 in 75.6 in Ground Clearance 12.2 in 13.8 in Min. Turn Radius without Brakes Not Published 9.8 ft Height to Top of ROPS 86.4 in Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published 94.1 in ▶ WeightTractor Weight (Base) 3,624 lb 4,309 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Agricultural: 8-18 front / 12.4-28 rear R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural - Front 8-18 8-16 R1 Agricultural - Rear 12.4-28 13.6-24 R3 Turf - Front Not Published 29-12.5-15 R3 Turf - Rear Not Published 21.5L-16.1 R4 Industrial - Front Not Published 10-16.5 R4 Industrial - Rear Not Published 14.9-24 ▶ Loader & AttachmentsQuick Attach Loader System Not Published Built-in parking stand; quick attach/detach; single-lever joystick control with float; bucket level indicator Loader Model Not Published KL6010 Loader Lift Height Not Published KL6010: 108.3 in (to pivot pin) Loader Lift Capacity (Full Height) Not Published KL6010: 2,761 lb (at pivot pin, max height) Loader Breakout Force Not Published KL6010: 3,727 lb (at pivot pin) ▶ WarrantyWarranty Length & Coverage Not Published Non-commercial tractor: 24 months, unlimited hours, parts & labor; non-commercial powertrain (engine and driveline): 72 months, unlimited hours, parts & labor ▶ ITC Company AccessoriesAccessories that fit None tagged yet
