▶ EngineEngine Manufacturer TYM Mahindra Engine Model T2300N2 MDI 2700 R1 Engine Type 4-cylinder, naturally aspirated diesel Four-stroke, direct-injection water-cooled, diesel No. of Cylinders 4 4 Displacement 139.5 in³ 166.7 in³ Rated Engine Speed 2600 rpm 2300 rpm Engine Power (Gross) 48 hp 48 hp PTO Power 40 hp 38 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Water-cooled Water-cooled Air Cleaner Dry element Dry type with safety cartridge and dust unloader valve Fuel System IDI Direct injection Alternator 50 A, 12 V 45 A, 12 V ▶ HydraulicsPump Type Dual gear pump Not Published Implement Flow 11.4 gpm 8.7 gpm Steering Flow 5.2 gpm 5 gpm Total Hydraulic Flow 16.5 gpm 8.7 gpm Overall Hydraulic Pump Flow 16.5 gpm 8.7 gpm Hydraulic System Type Dual gear pump Open center, full-live hydraulic with position and draft controls Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Rear: 0 (loader: 2) 1 spool standard No. of Optional Remote Valves Up to 4 Not Published ▶ Fluid CapacityFuel Tank Capacity 7.1 gal 14.55 gal Coolant Capacity 5.8 qt 2.25 gal Crankcase Capacity 4.8 qt 2.14 gal Transmission / Hydraulic System Capacity 4815R: 9 gal; 4815H: 9.8 gal 10.57 gal Front Axle Fluid Capacity 6.8 qt 2.24 gal ▶ PTO & HitchPTO Type Independent Live PTO Rear 540 rpm 540 rpm @ 2058 engine rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category I Category I & II adjustable, with telescopic stabilizers Hitch Lift Capacity 3,306 lb 3,527 lb Hitch Lift Capacity (at 24”) 2,425 lb Not Published Lift Control Type Position control Position & draft control ▶ Transmission & DrivetrainTransmission Type 4815R: Synchromesh shuttle; 4815H: HST Full constant mesh No. of Speeds 4815R: 12 forward / 12 reverse; 4815H: 3-range hydrostatic 8F / 2R Max Travel Speed (Forward) 4815R: 14.9 mph; 4815H: 18.8 mph 17.6 mph Max Travel Speed (Reverse) 4815R: 14.3 mph; 4815H: 18.7 mph 7.53 mph Clutch 4815R: Dry single plate; 4815H: Not applicable (HST) Dual Differential Lock & Limited Slip Options Differential lock (standard) Foot-operated differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic Hydrostatic power steering Brakes Wet, multi-disc Fully enclosed dry disc Seat Suspension & Adjustability Suspension seat mComfort mechanical suspension seat Front Axle Type Not Published Not Published Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 56.3 in 82.6 in Wheelbase 65.7 in 76.7 in Ground Clearance 14.4 in 8.7 in Min. Turn Radius without Brakes 124.8 in (left); 121.3 in (right) 147.63 in Height to Top of ROPS 97.3 in 93.7 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published Overall Length 120.9 in (with 3-point hitch) 127 in ▶ WeightTractor Weight (Base) 3,278 lb 5,192 lb (operating weight) Weight with ROPS and Loader 4,286 lb (3,278 + 1,008, computed) 6,746 lb (5,192 + 1,554, computed; 4550-1.1 gal loader transport weight) Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural, R4 Industrial R4 Industrial (standard); R1 Agricultural (optional) R1 Agricultural - Front 8-16 9.5X16 R1 Agricultural - Rear 12.4-24 12.4X28 R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front 10-16.5 12.6X16.5 R4 Industrial - Rear 420/70x24 16.9X24 ▶ Loader & AttachmentsQuick Attach Loader System BL150: quick attachment assembly Skid-steer style quick-attach coupler Loader Model BL150 4550-4L Loader Lift Height BL150: 104.9 in 116.6 in Loader Lift Capacity (Full Height) BL150: 2,200 lb (at pivot pin) 2,866 lb at pivot pins to full height Loader Breakout Force BL150: 3,422 lb (at pivot pin, ground level) 4,978 lb at pivot pins ▶ WarrantyWarranty Length & Coverage Basic 24 months or 2,000 hours, parts and labor; non-commercial: powertrain 72 months or 3,000 hours; rental and commercial: powertrain 36 months or 2,000 hours; loaders and backhoes 12 months 7-Year Limited Powertrain Warranty ▶ ITC Company AccessoriesAccessories that fit None tagged yet
