Tractor Comparison
Pick up to 4tractors and we'll lay every spec sheet out side by side. Same data we publish on the individual model pages, stacked in columns so you can compare numbers at a glance.
No photo
—
TYM4820
No photo
—
KubotaL4802
Comparison loaded for 2 tractors.
Spec
TYM4820
KubotaL4802
PTO Power
38.4 hp (28.6 kW)
DT (2WD/4WD), DTN (4WD): 40.5 hp (30.2 kW); HST (4WD): 39.0 hp (29.1 kW)
Alternator
12 V, 50 A
Not Published
Air Cleaner
Dry element
Not Published
Engine Type
4-cylinder, naturally aspirated diesel
Direct injection, vertical, water-cooled 4-cycle, diesel
Fuel System
IDI
Direct injection
Displacement
139.5 in³ (2,286 cc)
148.5 in³ (2434 cc)
No. of Cylinders
4
4
Rated Engine Speed
2,600 rpm
2600 rpm
Cooling System Type
Not Published
Water-cooled
Engine Manufacturer
TYM
Kubota
Engine Emissions Constraints
Tier 4
Not Published
Engine Power (Gross vs. Net HP)
Gross: 48 hp (36 kW)
Gross: 48.4 hp (36.1 kW); Net: 46.0 hp (34.3 kW)
Tractor Weight with Loader
Not Published
Not Published
Weight with Cab and Loader
Not Applicable
Not Applicable
Weight with ROPS and Loader
Not Published
Not Published
Pump Type
Dual gear pump
Not Published
Steering Flow
19.4 L/min (5.2 gpm)
17.9 L/min (4.7 gpm)
Implement Flow
43.2 L/min (11.4 gpm)
29.4 L/min (7.8 gpm)
Total Hydraulic Flow
62.6 L/min (16.5 gpm)
47.3 L/min (12.5 gpm)
Hydraulic System Type
Open center
Not Published
Rear Remote Hydraulic Flow
Not Published
Not Published
Overall Hydraulic Pump Flow
62.6 L/min (16.5 gpm)
47.3 L/min (12.5 gpm)
No. of Optional Remote Valves
Up to 4
Not Published
No. of Standard Remote Valves
0
Not Published
R3 Turf - Rear
41x14-20 / 44x18-20
DT (2WD/4WD), HST (4WD): 44X18-20; DTN (4WD): Not Applicable
Up to 2 years or until the 2,000 hours mark, bumper-to-bumper warranty; 3000 hours maximum coverage period for parts and labour on drivetrains or powertrains; 12-months warranty period for implements, including loaders and backhoes.
Non-Commercial Home & Residential Use — Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 72 months or 2000 hours. Commercial Use — Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 36 months or 2000 hours.
