▶ EngineEngine Manufacturer TYM TYM Engine Model T2300N2 A2300N2 Engine Type 4-cylinder, naturally aspirated diesel 4 cylinder water-cooled diesel, naturally aspirated No. of Cylinders 4 4 Displacement 139.5 in³ 139.5 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 48 hp 48 hp PTO Power 38.4 hp 38.4 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Water-cooled Air Cleaner Dry element Dry element Fuel System IDI (indirect injection) Not Published Alternator 70 A, 12 V 50 A, 12 V ▶ HydraulicsPump Type Dual gear pump Not Published Implement Flow 11.4 gpm 10.7 gpm Steering Flow 5.2 gpm 5 gpm Total Hydraulic Flow 16.5 gpm 15.7 gpm Overall Hydraulic Pump Flow 16.5 gpm 15.7 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 4 Not Published No. of Optional Remote Valves Not Published Up to 4 ports ▶ Fluid CapacityFuel Tank Capacity 11.8 gal 11.8 gal Coolant Capacity 8.3 qt 2.08 gal Crankcase Capacity 4.8 qt 1.20 gal Transmission / Hydraulic System Capacity 4820C: 10.3 gal; 4820CH: 11.1 gal 10.04 gal Front Axle Fluid Capacity 6.8 qt 1.90 gal ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540/750 rpm 540 / 540E rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 3,306 lb 3,306 lb Hitch Lift Capacity (at 24”) 2,425 lb 2,425 lb Lift Control Type Position control Position control ▶ Transmission & DrivetrainTransmission Type 4820C: Synchromesh; 4820CH: HST Hydrostatic (HST), 4-range No. of Speeds 4820C: F16 x R16; 4820CH: 4-Range 4 range (HST) Max Travel Speed (Forward) 4820C: 16 mph; 4820CH: 19.5 mph 19.5 mph Max Travel Speed (Reverse) 4820C: 15.2 mph; 4820CH: 19.5 mph 19.5 mph Clutch 4820C: Dry single type; 4820CH: N/A (HST) None (HST) Differential Lock & Limited Slip Options Standard differential lock Rear differential lock (standard) ▶ Chassis, Steering & ControlsFrame Type Not Published Compact utility tractor, 4WD Steering Hydrostatic Hydrostatic power steering Brakes Wet, multi-disc Wet, multi-disc Seat Suspension & Adjustability Suspension seat Deluxe suspension seat Front Axle Type 4WD (selectable 2WD/4WD) Selectable 4WD Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 64.9 in 64.9 in Wheelbase 71.1 in 71.1 in Ground Clearance 15.5 in 15.5 in Min. Turn Radius without Brakes L: 128.7 in; R: 126.0 in 9.18 ft (with brake applied) Height to Top of ROPS Not Published 98.4 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 97 in Not Applicable Overall Length 127.4 in (with 3-point hitch) 127.4 in (with 3-point hitch) ▶ WeightTractor Weight (Base) 4,349 lb 3,831 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural, R3 Turf, R4 Industrial 9.5-16 front / 12.4-28 rear (ag) R1 Agricultural - Front 9.5-16 9.5-16 R1 Agricultural - Rear 13.6-26 12.4-28 R3 Turf - Front 27x8.5-15 / 29x12.5-15 Not Published R3 Turf - Rear 41x14-20 / 44x18-20 Not Published R4 Industrial - Front 12-16.5 Not Published R4 Industrial - Rear 17.5Lx24 Not Published ▶ Loader & AttachmentsQuick Attach Loader System BL200C: Quick attach mechanism SSQA Loader Model BL200C BBL500 Loader Lift Height BL200C: 106.6 in 106.6 in Loader Lift Capacity (Full Height) BL200C: 2,701 lb (at pivot pin) 2,700 lb (at pivot pin) Loader Breakout Force BL200C: 3,660 lb (at pivot pin, ground level) 3,660 lb ▶ WarrantyWarranty Length & Coverage Basic 2 years or 2,000 hours; powertrain 3,000 hours maximum, parts and labor; loaders and backhoes 12 months Basic 24 months or 1,000 hours; powertrain 72 months or 2,000 hours ▶ ITC Company AccessoriesAccessories that fit
