▶ EngineEngine Manufacturer TYM Kubota Engine Model T2300N2 Not Published Engine Type 4-cylinder, naturally aspirated diesel 4-cylinder, indirect injection, liquid-cooled diesel No. of Cylinders 4 4 Displacement 139.5 in³ 148.5 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 48 hp 48 hp PTO Power 38.4 hp 37.5 hp Engine Emissions Constraints Tier 4 Not Published Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Dry element Not Published Fuel System IDI (indirect injection) Not Published Alternator 70 A, 12 V Not Published ▶ HydraulicsPump Type Dual gear pump Not Published Implement Flow 11.4 gpm Not Published Steering Flow 5.2 gpm Not Published Total Hydraulic Flow 16.5 gpm 25.9 gpm Overall Hydraulic Pump Flow 16.5 gpm 25.9 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 4 Not Published No. of Optional Remote Valves Not Published Not Published ▶ Fluid CapacityFuel Tank Capacity 11.8 gal 13.2 gal Coolant Capacity 8.3 qt Not Published Crankcase Capacity 4.8 qt Not Published Transmission / Hydraulic System Capacity 4820C: 10.3 gal; 4820CH: 11.1 gal Not Published Front Axle Fluid Capacity 6.8 qt Not Published ▶ PTO & HitchPTO Type Independent Live-continuous running PTO Rear 540/750 rpm 540 rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category I Category I (standard) Hitch Lift Capacity 3,306 lb Not Published Hitch Lift Capacity (at 24”) 2,425 lb 3,310 lb Lift Control Type Position control Position control ▶ Transmission & DrivetrainTransmission Type 4820C: Synchromesh; 4820CH: HST "Feather Step" hydrostatic transmission, 3-range No. of Speeds 4820C: F16 x R16; 4820CH: 4-Range 3-range (infinite) Max Travel Speed (Forward) 4820C: 16 mph; 4820CH: 19.5 mph 15.3 mph Max Travel Speed (Reverse) 4820C: 15.2 mph; 4820CH: 19.5 mph Not Published Clutch 4820C: Dry single type; 4820CH: N/A (HST) Dry, single Differential Lock & Limited Slip Options Standard differential lock Not Published ▶ Chassis, Steering & ControlsFrame Type Not Published Four-post ROPS/FOPS standard Steering Hydrostatic Hydrostatic power steering Brakes Wet, multi-disc Wet disc Seat Suspension & Adjustability Suspension seat Movable seat, spins in place; tilt steering standard Front Axle Type 4WD (selectable 2WD/4WD) Not Published Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 64.9 in 74.5 in Wheelbase 71.1 in 74.0 in Ground Clearance 15.5 in Not Published Min. Turn Radius without Brakes L: 128.7 in; R: 126.0 in 10.5 ft Height to Top of ROPS Not Published Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 97 in Not Published Overall Length 127.4 in (with 3-point hitch) Not Published ▶ WeightTractor Weight (Base) 4,349 lb Not Published Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural, R3 Turf, R4 Industrial Industrial (R4): 10-16.5 R4 front, 17.5L-24 R4 rear R1 Agricultural - Front 9.5-16 Not Published R1 Agricultural - Rear 13.6-26 Not Published R3 Turf - Front 27x8.5-15 / 29x12.5-15 Not Published R3 Turf - Rear 41x14-20 / 44x18-20 Not Published R4 Industrial - Front 12-16.5 10-16.5 R4 R4 Industrial - Rear 17.5Lx24 17.5L-24 R4 ▶ Loader & AttachmentsQuick Attach Loader System BL200C: Quick attach mechanism Not Published Loader Model BL200C TL1150 Loader Lift Height BL200C: 106.6 in TL1150: 116.1 in (at pivot pin) Loader Lift Capacity (Full Height) BL200C: 2,701 lb (at pivot pin) TL1150: 3,000 lb (at pivot pin) Loader Breakout Force BL200C: 3,660 lb (at pivot pin, ground level) TL1150: 4,375 lbf (at pivot pin) ▶ WarrantyWarranty Length & Coverage Basic 2 years or 2,000 hours; powertrain 3,000 hours maximum, parts and labor; loaders and backhoes 12 months Not Published ▶ ITC Company AccessoriesAccessories that fit None tagged yet
