▶ EngineEngine Manufacturer TYM KIOTI Engine Model T2300T3 3F183T Engine Type 4-cylinder, turbocharged diesel 3-cylinder, in-line vertical, water-cooled, 4-cycle, turbocharged, common rail diesel No. of Cylinders 4 3 Displacement 139.5 in³ 111.4 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 55 hp 55 hp PTO Power 44 hp 46 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Water-cooled Air Cleaner Dry element Dry type element Fuel System IDI (indirect injection) Common Rail Diesel (CRDI) Alternator 50 A, 12 V Not Published ▶ HydraulicsPump Type Dual gear pump Gear Implement Flow 11.4 gpm Not Published Steering Flow 5.2 gpm Not Published Total Hydraulic Flow 16.5 gpm 16.5 gpm Overall Hydraulic Pump Flow 16.5 gpm 16.5 gpm Hydraulic System Type Not Published Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves None standard (optional, up to 4) 1 No. of Optional Remote Valves Up to 4 1 ▶ Fluid CapacityFuel Tank Capacity 11.8 gal 14.8 gal Coolant Capacity 6.2 qt 2.0 gal Crankcase Capacity 4.8 qt 1.58 gal Transmission / Hydraulic System Capacity 5520R: 10.3 gal; 5520H: 11.1 gal 14.53 gal Front Axle Fluid Capacity 6.8 qt 1.8 gal ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540/750 rpm 540 rpm Mid-PTO Availability Not Published Optional (2,000 rpm) Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 3,306 lb 3,538 lb Hitch Lift Capacity (at 24”) 2,425 lb 3,177 lb Lift Control Type Position control Position with Draft Control ▶ Transmission & DrivetrainTransmission Type 5520R: Synchromesh; 5520H: HST Synchro Shuttle No. of Speeds 5520R: F16 x R16; 5520H: 4-Range 24x24 Max Travel Speed (Forward) 5520R: 16 mph; 5520H: 19.5 mph 17.35 mph Max Travel Speed (Reverse) 5520R: 15.2 mph; 5520H: 19.5 mph 15.42 mph Clutch 5520R: Dry single type; 5520H: N/A (HST) Dry Type Single Stage Differential Lock & Limited Slip Options Standard differential lock Differential Lock: Rear (Standard) ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic Hydrostatic Power Steering Brakes Wet, multi-disc Wet Multi Disc Seat Suspension & Adjustability Suspension seat Adjustable Seat Front Axle Type 4WD (selectable 2WD/4WD) Not Published Front Axle Rating Not Published Not Published Drawbar Capacity Not Published 1,655 lb (max. drawbar vertical load) ▶ Dimensions & ManeuverabilityOverall Width 64.9 in 65.7 in Wheelbase 71.1 in 75.6 in Ground Clearance 15.5 in 15.7 in Min. Turn Radius without Brakes L: 128.7 in; R: 126.0 in 10.0 ft Height to Top of ROPS 98.4 in 103.1 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published Overall Length 127.4 in (with 3-point hitch) 139.6 in (with 3-point hitch) ▶ WeightTractor Weight (Base) 3,836 lb 4,209 lb (with AG tires) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural, R3 Turf, R4 Industrial Agricultural, Turf, Industrial R1 Agricultural - Front 9.5-16 9.5-16 R1 Agricultural - Rear 13.6-26 16.9-24 R3 Turf - Front 27x8.5-15 / 29x12.5-15 29-12.5-15 R3 Turf - Rear 41x14-20 / 44x18-20 21.5L-16.1 R4 Industrial - Front 12-16.5 10-16.5 R4 Industrial - Rear 17.5Lx24 17.5-24 ▶ Loader & AttachmentsQuick Attach Loader System BL200: Quick attach mechanism Built-in parking stand; quick attach/detach; single-lever joystick control with float; bucket level indicator Loader Model BL200 KL6010 Loader Lift Height BL200: 106.6 in KL6010: 108.3 in (to pivot pin) Loader Lift Capacity (Full Height) BL200: 2,701 lb (at pivot pin) KL6010: 2,761 lb (at pivot pin, max height) Loader Breakout Force BL200: 3,660 lb (at pivot pin, ground level) KL6010: 2,990 lb (at pivot pin) ▶ WarrantyWarranty Length & Coverage Basic 2 years or 2,000 hours; powertrain 3,000 hours maximum, parts and labor; loaders and backhoes 12 months Non-commercial: basic 2 years, powertrain 72 months, unlimited hours, parts and labor ▶ ITC Company AccessoriesAccessories that fit
