▶ EngineEngine Manufacturer TYM Kubota Engine Model T2300T3 V3307-DI Engine Type 4-cylinder, turbocharged diesel 4-cylinder inline, direct injected diesel No. of Cylinders 4 4 Displacement 139.5 in³ 203 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 55 hp Not Published PTO Power 44 hp 55 hp Engine Emissions Constraints Tier 4 Tier 2 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Dry element 8 in dry, dual element Fuel System IDI (indirect injection) Direct injection Alternator 50 A, 12 V ROPS: 45 A, 12 V; Cab: 60 A, 12 V ▶ HydraulicsPump Type Dual gear pump Not Published Implement Flow 11.4 gpm 11.0 gpm Steering Flow 5.2 gpm 6.1 gpm Total Hydraulic Flow 16.5 gpm 17.1 gpm (11.0 + 6.1, computed) Overall Hydraulic Pump Flow 16.5 gpm 17.1 gpm (11.0 + 6.1, computed) Hydraulic System Type Not Published Open center Rear Remote Hydraulic Flow Not Published 11.0 gpm No. of Standard Remote Valves None standard (optional, up to 4) 1 No. of Optional Remote Valves Up to 4 2nd and 3rd optional ▶ Fluid CapacityFuel Tank Capacity 11.8 gal ROPS: 18.5 gal; Cab: 29.1 gal Coolant Capacity 6.2 qt 8.5 qt Crankcase Capacity 4.8 qt 11.6 qt Transmission / Hydraulic System Capacity 5520R: 10.3 gal; 5520H: 11.1 gal 59.2 qt Front Axle Fluid Capacity 6.8 qt Front differential case: 5.8 qt; front axle gear case: 3.7 qt each side ▶ PTO & HitchPTO Type Independent Live, independent PTO, hydraulically operated wet clutch with PTO brake PTO Rear 540/750 rpm 540 rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category I Category I and II Hitch Lift Capacity 3,306 lb 4,189 lb Hitch Lift Capacity (at 24”) 2,425 lb 3,307 lb Lift Control Type Position control Position, draft (top link sensing) and mix control ▶ Transmission & DrivetrainTransmission Type 5520R: Synchromesh; 5520H: HST Synchro shuttle, 8F/8R (4-speed synchronized main, 2-speed Hi/Lo range); hydraulic shuttle optional on cab models No. of Speeds 5520R: F16 x R16; 5520H: 4-Range 8F/8R (12F/12R with optional creep) Max Travel Speed (Forward) 5520R: 16 mph; 5520H: 19.5 mph 17.8 mph Max Travel Speed (Reverse) 5520R: 15.2 mph; 5520H: 19.5 mph 18.0 mph Clutch 5520R: Dry single type; 5520H: N/A (HST) Dry single plate (synchro shuttle); multiple wet discs (hydraulic shuttle) Differential Lock & Limited Slip Options Standard differential lock Rear differential lock (bevel gears) ▶ Chassis, Steering & ControlsFrame Type Not Published Two-post foldable ROPS (canopy optional); Ultra Grand Cab optional Steering Hydrostatic Hydrostatic power steering Brakes Wet, multi-disc Multiple wet disc, mechanical Seat Suspension & Adjustability Suspension seat Reclining, fully adjustable seat (height, weight, fore-aft, armrests) with retractable seat belt; optional air-suspension seat (cab) Front Axle Type 4WD (selectable 2WD/4WD) 4WD: bevel-gear type, on-the-go engagement Front Axle Rating Not Published Not Published Drawbar Capacity Not Published 2,200 lb ▶ Dimensions & ManeuverabilityOverall Width 64.9 in 73.2 in Wheelbase 71.1 in 2WD ROPS: 82.1 in; 2WD cab: 84.4 in; 4WD ROPS: 80.7 in; 4WD cab: 83.1 in Ground Clearance 15.5 in 15.4 in Min. Turn Radius without Brakes L: 128.7 in; R: 126.0 in 2WD: 11.2 ft; 4WD: 11.8 ft Height to Top of ROPS 98.4 in 96.9 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published 99.8 in Overall Length 127.4 in (with 3-point hitch) 2WD: 140.4 in; 4WD: 135.6 in ▶ WeightTractor Weight (Base) 3,836 lb 2WD ROPS: 4,650 lb; 4WD ROPS: 4,785 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural, R3 Turf, R4 Industrial Standard: 7.50-16 (2WD) or 9.5-24 (4WD) front, 16.9-28 rear R1 Agricultural - Front 9.5-16 2WD: 7.5-16; 4WD: 9.5-24 R1 Agricultural - Rear 13.6-26 16.9-28 R3 Turf - Front 27x8.5-15 / 29x12.5-15 2WD: 29x12.5-15 or 27x9.5-15 R3 Turf - Rear 41x14-20 / 44x18-20 2WD: 21.5L-16.1 or 16.9-24 R4 Industrial - Front 12-16.5 12.5/80-18 (4WD) R4 Industrial - Rear 17.5Lx24 16.9-24 (4WD) ▶ Loader & AttachmentsQuick Attach Loader System BL200: Quick attach mechanism LA1153: two-lever quick coupler Loader Model BL200 LA1153 Loader Lift Height BL200: 106.6 in LA1153 height position: 132.7 in; LA1153 power position: 117.2 in Loader Lift Capacity (Full Height) BL200: 2,701 lb (at pivot pin) Not Published Loader Breakout Force BL200: 3,660 lb (at pivot pin, ground level) Not Published ▶ WarrantyWarranty Length & Coverage Basic 2 years or 2,000 hours; powertrain 3,000 hours maximum, parts and labor; loaders and backhoes 12 months Not Published ▶ ITC Company AccessoriesAccessories that fit None tagged yet
