▶ EngineEngine Manufacturer TYM LS Mtron Engine Model T2300T3 L3CRV-T7 Engine Type 4-cylinder, turbocharged diesel 3-cylinder, turbocharged, liquid-cooled diesel No. of Cylinders 4 3 Displacement 139.5 in³ 114.7 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 55 hp 55 hp PTO Power 44 hp Gear: 46.7 hp; HST: 44 hp Engine Emissions Constraints Tier 4 Tier 4B (final) Cooling System Type Liquid-cooled Liquid cooled Air Cleaner Dry element Replaceable primary and inner elements Fuel System IDI (indirect injection) Electronically controlled common rail direct injection Alternator 50 A, 12 V ROPS: 70 A; Cab: 85 A ▶ HydraulicsPump Type Dual gear pump Gear Implement Flow 11.4 gpm 8.2 gpm Steering Flow 5.2 gpm Gear: 4.2 gpm; HST: 5.3 gpm Total Hydraulic Flow 16.5 gpm Gear: 12.4 gpm; HST: 13.5 gpm Overall Hydraulic Pump Flow 16.5 gpm Gear: 12.4 gpm; HST: 13.5 gpm Hydraulic System Type Not Published Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves None standard (optional, up to 4) 1 No. of Optional Remote Valves Up to 4 Up to 2 (second valve optional) ▶ Fluid CapacityFuel Tank Capacity 11.8 gal ROPS: 10.5 gal; Cab: 12.4 gal Coolant Capacity 6.2 qt 2.3 gal Crankcase Capacity 4.8 qt 5.8 qt Transmission / Hydraulic System Capacity 5520R: 10.3 gal; 5520H: 11.1 gal 11.4 gal Front Axle Fluid Capacity 6.8 qt 2.2 gal ▶ PTO & HitchPTO Type Independent Independent, electro-hydraulic engagement PTO Rear 540/750 rpm 540 rpm Mid-PTO Availability Not Published Standard (2000 rpm) Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 3,306 lb 2,756 lb Hitch Lift Capacity (at 24”) 2,425 lb 2,116 lb Lift Control Type Position control Position control (draft control optional) ▶ Transmission & DrivetrainTransmission Type 5520R: Synchromesh; 5520H: HST Gear: 16x16 synchronized shuttle shift (SSS); HST: 3-range hydrostatic, dual pedal No. of Speeds 5520R: F16 x R16; 5520H: 4-Range Gear: 16F/16R; HST: 3-range Max Travel Speed (Forward) 5520R: 16 mph; 5520H: 19.5 mph Gear: 17.0 mph; HST: 17.9 mph Max Travel Speed (Reverse) 5520R: 15.2 mph; 5520H: 19.5 mph Gear: 15.3 mph; HST: 11.37 mph Clutch 5520R: Dry single type; 5520H: N/A (HST) Gear: dry single disc (10.8 in); HST: n/a Differential Lock & Limited Slip Options Standard differential lock Mechanical rear differential lock (pedal) ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic Power steering Brakes Wet, multi-disc Wet multi-disc Seat Suspension & Adjustability Suspension seat ROPS: adjustable suspension seat (fore/aft, weight and height adjustment); Cab: cloth suspension seat with weight control, fore/aft adjustment and adjustable armrests Front Axle Type 4WD (selectable 2WD/4WD) Four-wheel drive (FWD) Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Short position: 2,317 lb; Regular position: 1,598 lb; Extended position: 1,091 lb ▶ Dimensions & ManeuverabilityOverall Width 64.9 in 69.1 in Wheelbase 71.1 in 73.2 in Ground Clearance 15.5 in 15 in Min. Turn Radius without Brakes L: 128.7 in; R: 126.0 in 111.8 in (right turn); 123.2 in (left turn) (with brake applied) Height to Top of ROPS 98.4 in 97.1 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published 94 in Overall Length 127.4 in (with 3-point hitch) 128.1 in ▶ WeightTractor Weight (Base) 3,836 lb ROPS Gear: 3,424 lb; ROPS HST: 3,490 lb; Cab: 4,194 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural - Front 9.5-16 9.5-16 R1 Agricultural - Rear 13.6-26 13.6-24 R3 Turf - Front 27x8.5-15 / 29x12.5-15 28x8.50-15 R3 Turf - Rear 41x14-20 / 44x18-20 41x14.00-20 R4 Industrial - Front 12-16.5 12x16.5 R4 Industrial - Rear 17.5Lx24 17.5Lx24 ▶ Loader & AttachmentsQuick Attach Loader System BL200: Quick attach mechanism Tool-free loader mount; optional skid-steer quick-attach plates Loader Model BL200 260TLA Loader Lift Height BL200: 106.6 in 260TLA: 109 in (at pivot pin) Loader Lift Capacity (Full Height) BL200: 2,701 lb (at pivot pin) 260TLA: 2,371 lb (at bucket pivot pin, max height) Loader Breakout Force BL200: 3,660 lb (at pivot pin, ground level) 260TLA: 4,081 lb (at bucket pivot pin) ▶ WarrantyWarranty Length & Coverage Basic 2 years or 2,000 hours; powertrain 3,000 hours maximum, parts and labor; loaders and backhoes 12 months Basic 2 years or 750 hours; powertrain 4 more years (6 years or 1,500 hours total) ▶ ITC Company AccessoriesAccessories that fit None tagged yet
