▶ EngineEngine Manufacturer TYM TYM Engine Model T2300T3 T2300T3 Engine Type 4-cylinder, turbocharged diesel 4-cylinder, turbocharged diesel No. of Cylinders 4 4 Displacement 139.5 in³ 139.5 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 55 hp 55 hp PTO Power 44 hp 44 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Dry element Dry element Fuel System IDI (indirect injection) IDI (indirect injection) Alternator 50 A, 12 V 70 A, 12 V ▶ HydraulicsPump Type Dual gear pump Dual gear pump Implement Flow 11.4 gpm 11.4 gpm Steering Flow 5.2 gpm 5.2 gpm Total Hydraulic Flow 16.5 gpm 16.5 gpm Overall Hydraulic Pump Flow 16.5 gpm 16.5 gpm Hydraulic System Type Not Published Not Published Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves None standard (optional, up to 4) 4 No. of Optional Remote Valves Up to 4 Not Published ▶ Fluid CapacityFuel Tank Capacity 11.8 gal 11.8 gal Coolant Capacity 6.2 qt 8.3 qt Crankcase Capacity 4.8 qt 4.8 qt Transmission / Hydraulic System Capacity 5520R: 10.3 gal; 5520H: 11.1 gal 5520C: 10.3 gal; 5520CH: 11.1 gal Front Axle Fluid Capacity 6.8 qt 6.8 qt ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540/750 rpm 540/750 rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 3,306 lb 3,306 lb Hitch Lift Capacity (at 24”) 2,425 lb 2,425 lb Lift Control Type Position control Position control ▶ Transmission & DrivetrainTransmission Type 5520R: Synchromesh; 5520H: HST 5520C: Synchromesh; 5520CH: HST No. of Speeds 5520R: F16 x R16; 5520H: 4-Range 5520C: F16 x R16; 5520CH: 4-Range Max Travel Speed (Forward) 5520R: 16 mph; 5520H: 19.5 mph 5520C: 16 mph; 5520CH: 19.5 mph Max Travel Speed (Reverse) 5520R: 15.2 mph; 5520H: 19.5 mph 5520C: 15.2 mph; 5520CH: 19.5 mph Clutch 5520R: Dry single type; 5520H: N/A (HST) 5520C: Dry single type; 5520CH: N/A (HST) Differential Lock & Limited Slip Options Standard differential lock Standard differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic Hydrostatic Brakes Wet, multi-disc Wet, multi-disc Seat Suspension & Adjustability Suspension seat Suspension seat Front Axle Type 4WD (selectable 2WD/4WD) 4WD (selectable 2WD/4WD) Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 64.9 in 64.9 in Wheelbase 71.1 in 71.1 in Ground Clearance 15.5 in 15.5 in Min. Turn Radius without Brakes L: 128.7 in; R: 126.0 in L: 128.7 in; R: 126.0 in Height to Top of ROPS 98.4 in Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published 97 in Overall Length 127.4 in (with 3-point hitch) 127.4 in (with 3-point hitch) ▶ WeightTractor Weight (Base) 3,836 lb 4,349 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural - Front 9.5-16 9.5-16 R1 Agricultural - Rear 13.6-26 13.6-26 R3 Turf - Front 27x8.5-15 / 29x12.5-15 27x8.5-15 / 29x12.5-15 R3 Turf - Rear 41x14-20 / 44x18-20 41x14-20 / 44x18-20 R4 Industrial - Front 12-16.5 12-16.5 R4 Industrial - Rear 17.5Lx24 17.5Lx24 ▶ Loader & AttachmentsQuick Attach Loader System BL200: Quick attach mechanism BL200C: Quick attach mechanism Loader Model BL200 BL200C Loader Lift Height BL200: 106.6 in BL200C: 106.6 in Loader Lift Capacity (Full Height) BL200: 2,701 lb (at pivot pin) BL200C: 2,701 lb (at pivot pin) Loader Breakout Force BL200: 3,660 lb (at pivot pin, ground level) BL200C: 3,660 lb (at pivot pin, ground level) ▶ WarrantyWarranty Length & Coverage Basic 2 years or 2,000 hours; powertrain 3,000 hours maximum, parts and labor; loaders and backhoes 12 months Basic 2 years or 2,000 hours; powertrain 3,000 hours maximum, parts and labor; loaders and backhoes 12 months ▶ ITC Company AccessoriesAccessories that fit
