TYM 5520C vs Mahindra 5155 Shuttle | Side-by-side comparison | ITC Resource Center
Compare Tractors
See horsepower, lift capacity, hydraulic flow, and the numbers that matter to your work. Up to 4 machines, side by side, in graphs built to show which tractor is better at what.
CAT I & II with telescopic stabilizers & flex links
Hitch Lift Capacity
3,306 lb
Not Published
Hitch Lift Capacity (at 24”)
2,425 lb
3748 lb
Lift Control Type
Position control
Position control
Transmission Type
5520C: Synchromesh; 5520CH: HST
Full synchromesh with forward/reverse synchro shuttle & constant mesh range
No. of Speeds
5520C: F16 x R16; 5520CH: 4-Range
12F / 12R
Max Travel Speed (Forward)
5520C: 16 mph; 5520CH: 19.5 mph
17.9 mph
Max Travel Speed (Reverse)
5520C: 15.2 mph; 5520CH: 19.5 mph
Not Published
Clutch
5520C: Dry single type; 5520CH: N/A (HST)
Dual dry with cerametallic lining
Differential Lock & Limited Slip Options
Standard differential lock
Not Published
Frame Type
Not Published
Not Published
Steering
Hydrostatic
Hydrostatic power steering with tilt steering wheel
Brakes
Wet, multi-disc
Fully-enclosed, 7-in diameter, dry disc
Seat Suspension & Adjustability
Suspension seat
Adjustable seat with contoured cushions, armrests and a soft-coil suspension
Front Axle Type
4WD (selectable 2WD/4WD)
Not Published
Front Axle Rating
Not Published
Not Published
Drawbar Capacity
Not Published
Not Published
Overall Length with 3-Point Hitch
127.4 in
136.6 in
Overall Width
64.9 in
74.8 in
Wheelbase
71.1 in
77.9 in
Ground Clearance
15.5 in
16.4 in
Min. Turn Radius without Brakes
L: 128.7 in; R: 126.0 in
10.8 ft
Height to Top of ROPS
Not Published
Not Published
Height to Top of ROPS (folded)
Not Published
Not Published
Height to Top of Cab Model
97 in
Not Published
Tractor Weight (Base)
4,349 lb
5390 lb
Weight with ROPS and Loader
Not Published
6,690 lb
Weight with Cab and Loader
Not Published
Not Published
Tire Size & Options
R1 Agricultural, R3 Turf, R4 Industrial
R1 Agricultural or R4 Industrial
R1 Agricultural - Front
9.5-16
9.5 x 20
R1 Agricultural - Rear
13.6-26
14.9 x 28
R3 Turf - Front
27x8.5-15 / 29x12.5-15
Not Published
R3 Turf - Rear
41x14-20 / 44x18-20
Not Published
R4 Industrial - Front
12-16.5
10.5/80 x 18
R4 Industrial - Rear
17.5Lx24
16.9 x 24
Quick Attach Loader System
BL200C: Quick attach mechanism
Skid-steer style quick-attach coupler
Loader Model
BL200C
5155-4L (front loader); 65B (rear backhoe)
Loader Lift Height
BL200C: 106.6 in
5155-4L: 122 in
Loader Lift Capacity (Full Height)
BL200C: 2,701 lb
5155-4L: 3,100 lb
Loader Breakout Force
BL200C: 3,660 lb
5155-4L: 5,200 lb
Warranty Length & Coverage
Up to 2 years or until the 2,000 hour mark, bumper-to-bumper warranty; 3,000 hours maximum coverage period for parts and labour on drivetrains or powertrains; 12-months warranty period for implements, including loaders and backhoes
