▶ EngineEngine Manufacturer TYM LS Mtron Engine Model T2300T3 L3C19-T Engine Type 4-cylinder, turbocharged diesel 3 Cylinder, Liquid-cooled, Diesel, TC, CRDI No. of Cylinders 4 3 Displacement 139.5 in³ 114.7 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 57 hp 57 hp PTO Power 48 hp 48.4 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Not Published Liquid-cooled Air Cleaner Dry element Dry Fuel System IDI (indirect injection) Common rail direct injection (CRDI) Alternator 70 A, 12 V 70 A, 12 V ▶ HydraulicsPump Type Single gear pump Not Published Implement Flow 11.4 gpm 8.2 gpm Steering Flow 5.2 gpm 4.1 gpm Total Hydraulic Flow 16.5 gpm 12.3 gpm Overall Hydraulic Pump Flow 16.5 gpm 12.3 gpm Hydraulic System Type Not Published Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Loader: 4; Rear: 2 2 sets, with detent No. of Optional Remote Valves Not Published Not Published ▶ Fluid CapacityFuel Tank Capacity 15.3 gal PCT: 10.6 gal; PCTC: 12.4 gal Coolant Capacity 6.2 qt 2.3 gal Crankcase Capacity 4.8 qt 1.6 gal Transmission / Hydraulic System Capacity 11.6 gal 11.4 gal Front Axle Fluid Capacity 6.8 qt 2.2 gal ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540 rpm 540 rpm Mid-PTO Availability Not Published Optional (2,000 rpm) Category, 3-Point Hitch Category II Category II Hitch Lift Capacity 4,409 lb 2,755 lb Hitch Lift Capacity (at 24”) 3,748 lb 2,469 lb Lift Control Type Mechanical Position & Draft ▶ Transmission & DrivetrainTransmission Type Power shuttle Synchro shuttle / Power Clutch No. of Speeds F12 x R12 F16 x R16 Max Travel Speed (Forward) 19.9 mph Not Published Max Travel Speed (Reverse) 18.9 mph Not Published Clutch Wet, multi-disc Power clutch valve and lever Differential Lock & Limited Slip Options Standard differential lock Mechanical rear differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic Hydrostatic Power Steering Brakes Wet, multi-disc Wet, Multi-disc Seat Suspension & Adjustability Suspension seat Not Published Front Axle Type 4WD (selectable 2WD/4WD) Mechanical front-wheel drive (4WD) Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 68.9 in 62.5 in Wheelbase 78.7 in 73.2 in Ground Clearance 18.1 in Not Published Min. Turn Radius without Brakes L: 124.4 in; R: 124.0 in Not Published Height to Top of ROPS 102.8 in PCT: 95 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published PCTC: 90 in Overall Length 136.4 in (with 3-point hitch) 133 in (frame to link) ▶ WeightTractor Weight (Base) 4,299 lb PCT: 3,869 lb; PCTC: 4,380 lb Weight with ROPS and Loader Not Published 4,649 lb (3,869 + 780, computed; LL4106 loader without bucket) Weight with Cab and Loader Not Published 5,160 lb (4,380 + 780, computed; LL4106 loader without bucket) ▶ Tire OptionsTire Size & Options R1 Agricultural, R4 Industrial Agricultural, Turf, Industrial R1 Agricultural - Front 9.5-20 9.5-16 R1 Agricultural - Rear 14.9-28 13.6-24 R3 Turf - Front Not Published 28x8.5-15 R3 Turf - Rear Not Published 41x14-20 R4 Industrial - Front 10.5/80-18 12-16.5 R4 Industrial - Rear 16.9-24 17.5L-24 ▶ Loader & AttachmentsQuick Attach Loader System BL350: Quick attach mechanism LL4106, LL4001: 2-lever skid-steer coupler, fits universal skid-steer attachments Loader Model BL350 LL4106; LL4001 Loader Lift Height BL350: 117.5 in LL4106: 94.4 in; LL4001: 104.3 in Loader Lift Capacity (Full Height) BL350: 3,437 lb (at pivot pin) LL4106: 2,680 lb (at pivot pin); LL4001: 2,998 lb (at pivot pin) Loader Breakout Force BL350: 4,742 lb (at pivot pin, ground level) LL4106: 4,063 lb (at pivot pin); LL4001: 4,295 lb (at pivot pin) ▶ WarrantyWarranty Length & Coverage Basic 24 months or 2,000 hours, parts and labor; non-commercial, 20 to 70 engine hp: powertrain 72 months or 3,000 hours; loaders, backhoes and mid-mount mowers 12 months 6-year limited powertrain warranty ▶ ITC Company AccessoriesAccessories that fit None tagged yet
