TYM 5835 vs TYM 5520 | Side-by-side comparison | ITC Resource Center
ITC Resource Center
Tractor Comparison
Pick up to 4tractors and we'll lay every spec sheet out side by side. Same data we publish on the individual model pages, stacked in columns so you can compare numbers at a glance.
—
TYM5835
—
TYM5520
Comparison loaded for 2 tractors.
Spec
TYM5835
TYM5520
PTO Power
48 hp
44 hp
Alternator
70 A, 12 V
50 A, 12 V
Air Cleaner
Dry element
Dry element
Engine Type
4-cylinder, turbocharged diesel
4-cylinder, turbocharged diesel
Fuel System
IDI
IDI
Displacement
139.5 in³
139.5 in³
No. of Cylinders
4
4
Rated Engine Speed
2600 rpm
2600 rpm
Cooling System Type
Not Published
Not Published
Engine Manufacturer
TYM
TYM
Engine Power (Gross)
58 hp
55 hp
Engine Emissions Constraints
Tier 4
Tier 4
Tractor Weight with Loader
Not Published
—
Weight with Cab and Loader
Not Applicable
Not Applicable
Weight with ROPS and Loader
Not Published
Not Published
Pump Type
Single gear pump
Dual gear pump
Steering Flow
5.2 gpm
5.2 gpm
Implement Flow
11.4 gpm
11.4 gpm
Total Hydraulic Flow
16.5 gpm
16.5 gpm
Hydraulic System Type
Not Published
Not Published
Rear Remote Hydraulic Flow
Not Published
Not Published
Overall Hydraulic Pump Flow
16.5 gpm
16.5 gpm
No. of Optional Remote Valves
Not Published
Up to 4
No. of Standard Remote Valves
Loader: 4; Rear: 2
0
PTO Rear
540 rpm
540/750 rpm
PTO Type
Independent
Independent
Lift Control Type
Mechanical
Position control
Hitch Lift Capacity
4,409 lb
3,306 lb
Mid-PTO Availability
Not Published
Not Published
Category, 3-Point Hitch
Category II
Category I
Hitch Lift Capacity (at 24”)
3,748 lb
2,425 lb
R3 Turf - Rear
Not Published
41x14-20 / 44x18-20
R3 Turf - Front
Not Published
27x8.5-15 / 29x12.5-15
Tire Size & Options
R1 Agricultural, R4 Industrial
R1 Agricultural, R3 Turf, R4 Industrial
R4 Industrial - Rear
16.9-24
17.5Lx24
R4 Industrial - Front
10.5/80-18
12-16.5
R1 Agricultural - Rear
14.9-28
13.6-26
R1 Agricultural - Front
9.5-20
9.5-16
Coolant Capacity
6.2 qt
6.2 qt
Crankcase Capacity
4.8 qt
4.8 qt
Fuel Tank Capacity
15.3 gal
11.8 gal
Front Axle Fluid Capacity
6.8 qt
6.8 qt
Transmission / Hydraulic System Capacity
11.6 gal
HST: 11.1 gal; Gear: 10.3 gal
Loader Lift Height
117.5 in
106.6 in
Loader Breakout Force
4,742 lb
3,660 lb
Price for Backhoe Option
BH350
BH200
Price for Mid-Mount Mower
Not Published
Not Published
Quick Attach Loader System
BL350: Quick attachment assembly
BL200: Quick attach assembly (lever-lock)
Loader Lift Capacity (Full Height)
3,437 lb
2,701 lb
Clutch
Wet, multi-disc
Dry single type (N/A)
No. of Speeds
F12 x R12
HST: 4-Range; Gear: F16 x R16 (4-Range)
Transmission Type
Power shuttle
HST: Hydrostatic (HST); Gear: Synchromesh
Max Travel Speed (Forward)
19.9 mph
HST: 19.5 mph; Gear: 16 mph
Max Travel Speed (Reverse)
Not Published
Not Published
Differential Lock & Limited Slip Options
Not Published
Differential lock system
Brakes
Wet, multi-disc
Wet, multi disc
Steering
Hydrostatic
Hydrostatic
Frame Type
Not Published
Not Published
Front Axle Type
Not Published
Not Published
Drawbar Capacity
Not Published
Not Published
Front Axle Rating
Not Published
Not Published
Seat Suspension & Adjustability
Suspension seat
Suspension seat
Wheelbase
78.7 in
71.1 in
Overall Width
68.9 in
64.9 in
Ground Clearance
18.1 in
15.5 in
Height to Top of ROPS
102.8 in
98.4 in
Height to Top of Cab Model
Not Applicable
Not Applicable
Height to Top of ROPS (folded)
Not Published
Not Published
Min. Turn Radius without Brakes
L: 124.4 in; R: 124.0 in
L: 128.7 in; R: 126.0 in
Overall Length with 3-Point Hitch
136.4 in
127.4 in
Financing Options
0% financing for up to 72 months and instant cash rebates. Contact dealer for more information.
0% financing for up to 72 months and instant cash rebates. Contact dealer for more information.
Base Price with Loader
Not Published
Not Published
Warranty Length & Coverage
Up to 2 years or until the 2,000 hours mark, bumper-to-bumper warranty; 3000 hours maximum coverage period for parts and labour on drivetrains or powertrains; 12-months warranty period for implements, including loaders and backhoes.
Up to 2 years or until the 2,000 hours mark, bumper-to-bumper warranty; 3000 hours maximum coverage period for parts and labour on drivetrains or powertrains; 12-months warranty period for implements, including loaders and backhoes.
