▶ EngineEngine Manufacturer Kukje AGCO Power Engine Model 7845C: D3400T10-UTC-3; 7845R: D3400T1-UTR-3 33 AWIC Engine Type Vertical, 4-cycle, water-cooled diesel, direct injection, turbocharged 3-cylinder, intercooled turbocharged diesel No. of Cylinders 4 3 Displacement 208 in³ 201 in³ Rated Engine Speed 2500 rpm 2200 rpm Engine Power (Gross) 78 hp 75 hp PTO Power 64 hp 60 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Liquid-cooled Liquid cooled Air Cleaner Dry, double filter element Dual element (primary and secondary) Fuel System Direct injection High-pressure common rail direct fuel injection Alternator 70 A, 12 V 80 A ▶ HydraulicsPump Type Dual gear pumps (separate steering and main pumps) Two-stage pump Implement Flow 12.4 gpm Not Published Steering Flow 8.3 gpm Not Published Total Hydraulic Flow 20.7 gpm Not Published Overall Hydraulic Pump Flow Not Published Not Published Hydraulic System Type 7845C (cab): Electric over hydraulic control (Position, Draft); 7845R: Electric over hydraulic control (Position) Open center Rear Remote Hydraulic Flow Not Published 17.2 gpm No. of Standard Remote Valves Not Published 2 No. of Optional Remote Valves Not Published 1 ▶ Fluid CapacityFuel Tank Capacity 23.8 gal 33 gal Coolant Capacity Not Published 4.2 gal Crankcase Capacity Not Published 3.3 gal Transmission / Hydraulic System Capacity Not Published Power Shuttle: 10.6 to 11.4 gal; Mechanical: 8.5 to 9.2 gal Front Axle Fluid Capacity Not Published Dana: 1.45 gal beam plus 0.24 gal per final drive; Carraro: 1.3 gal beam plus 0.21 gal per final drive ▶ PTO & HitchPTO Type Independent (6-spline shaft) Independent, electrohydraulic engagement PTO Rear Not Published 540/540E standard; 540/1000 optional Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II Category II Hitch Lift Capacity 3,820 lb Not Published Hitch Lift Capacity (at 24”) 2,526 lb 4,850 lb Lift Control Type 7845C (cab): Position, draft; 7845R: Position Not Published ▶ Transmission & DrivetrainTransmission Type Power shuttle (hydraulic shuttle); main shifting fully synchronized (4-speed) 12x12 fully synchronized power shuttle, 6 gears x 2 ranges, electrohydraulic shuttle lever; optional Dyna-2 24x24 powershift No. of Speeds 16F/16R 12 forward and 12 reverse; 24 forward and 24 reverse with optional Dyna-2 Max Travel Speed (Forward) 24.8 mph 25 mph Max Travel Speed (Reverse) 25.6 mph Not Published Clutch Wet disc Multidisc wet clutch with easy shift knob and electrohydraulic power shuttle lever Differential Lock & Limited Slip Options Not Published Hydraulic with electronic control, rear axle engaged via electrohydraulic rocker switch; 4WD front axle Hydra-Lock ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic Cab: tilt and telescopic steering column; Platform: tilt steering column Brakes Wet disc Hydraulic multidisc brakes with mechanical parking brake, independently controlled via foot pedals Seat Suspension & Adjustability Deluxe seat with lumbar adjustment Cab: mechanical swiveling seat with armrests, air-ride swivel seat optional; Platform: mechanical spring suspension seat with armrests Front Axle Type 4WD, heavy-duty front axle, 56 degree steering angle each direction, no drag link Heavy-duty 2WD or 4WD front axle Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 152.7 in Not Published Overall Width 74.5 in 60.3 in (minimum, with std. 420/85R30 rear tires) Wheelbase 86.6 in 88.5 in Ground Clearance 18.3 in Not Published Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS 102.6 in Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 107.8 in Not Published ▶ WeightTractor Weight (Base) 7845C: 6,250 lb; 7845R: 5,752 lb 2WD ROPS: 7,478 lb; 2WD Cab: 8,294 lb; 4WD ROPS: 7,734 lb; 4WD Cab: 8,644 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Agricultural: 11.2x24 front / 16.9x30 rear 2WD: 9.5L-15 front, 420/85R30 rear; 4WD: 320/85R24 front, 420/85R30 rear R1 Agricultural - Front 11.2x24 2WD: 9.5L-15; 4WD: 320/85R24 R1 Agricultural - Rear 16.9x30 420/85R30 R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published Not Published R4 Industrial - Rear Not Published Not Published ▶ Loader & AttachmentsQuick Attach Loader System BL45: Quick attachment bucket mount 931X and 936X: universal skid steer type quick release Loader Model BL45 FL.3522, FL.3615, 931X, 936X Loader Lift Height BL45: 111.7 in FL.3522: 140 in; FL.3615: 140 in; 931X: 136 in; 936X: 136 in (at pivot pin) Loader Lift Capacity (Full Height) BL45: 2,804 lb FL.3522: 2,760 lb; FL.3615: 3,420 lb; 931X: 2,140 lb; 936X: 3,340 lb (to full height, at 31.5 in forward of pivot pin) Loader Breakout Force BL45: 5,467 lbf Not Published ▶ WarrantyWarranty Length & Coverage Four-year limited warranty Not Published
