▶ EngineEngine Manufacturer Kukje TYM Engine Model 7845C: D3400T10-UTC-3; 7845R: D3400T1-UTR-3 T2300T1-UTC_4 Engine Type Turbocharged, direct injection, liquid-cooled diesel 4-cylinder, turbocharged diesel No. of Cylinders 4 4 Displacement 208 in³ 139.5 in³ Rated Engine Speed 2500 rpm 2600 rpm Engine Power (Gross) 78 hp 58 hp PTO Power 64 hp 48 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Liquid-cooled Not Published Air Cleaner Dry, double filter element Dry element Fuel System Direct injection IDI Alternator 70 A, 12 V 70 A, 12 V ▶ HydraulicsPump Type Dual pumps (separate steering and main pumps) Single gear pump Implement Flow Not Published 11.4 gpm Steering Flow Not Published 5.13 gpm Total Hydraulic Flow 19.3 gpm 16.5 gpm Overall Hydraulic Pump Flow Not Published 16.5 gpm Hydraulic System Type Electric over hydraulic control (position, draft & mixed) Not Published Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Loader: 6; Rear: 6 No. of Optional Remote Valves Not Published Not Published ▶ Fluid CapacityFuel Tank Capacity 23.8 gal 15.3 gal Coolant Capacity Not Published 6.2 qt Crankcase Capacity Not Published 4.8 qt Transmission / Hydraulic System Capacity Not Published 11.62 gal Front Axle Fluid Capacity Not Published 6.8 qt ▶ PTO & HitchPTO Type Independent (6-spline shaft) Independent PTO Rear Not Published 540 rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II Category II Hitch Lift Capacity 3,820 lb 4,409 lb Hitch Lift Capacity (at 24”) 2,526 lb 3,748 lb Lift Control Type Position, draft & mixed Position and draft control (electronic) ▶ Transmission & DrivetrainTransmission Type Power shuttle (hydraulic shuttle); main shifting fully synchronized (4-speed) Power shuttle No. of Speeds 16F/16R F12 x R12 Max Travel Speed (Forward) 24.8 mph 24.04 mph Max Travel Speed (Reverse) 25.6 mph Not Published Clutch Multi, wet Wet, multi-disc Differential Lock & Limited Slip Options Not Published Standard differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic Hydrostatic Brakes Wet disc Wet, multi-disc Seat Suspension & Adjustability Deluxe seat with lumbar adjustment Suspension seat Front Axle Type 4WD, heavy-duty front axle, 56-degree steering angle each direction, no drag link 4WD (selectable 2WD/4WD) Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 74.5 in 68.9 in Wheelbase 86.6 in 78.7 in Ground Clearance 18.3 in 18.1 in Min. Turn Radius without Brakes Not Published L: 139.7 in; R: 141.9 in Height to Top of ROPS 102.6 in Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 107.8 in 99.2 in Overall Length 152.7 in 141.5 in (with 3-point hitch) ▶ WeightTractor Weight (Base) 7845C: 6,250 lb; 7845R: 5,752 lb 4,952 lb (weight with cab) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published 6,252 lb (4,952 + 1,300, computed; L4058PC loader total weight) ▶ Tire OptionsTire Size & Options Agricultural: 11.2x24 front / 16.9x30 rear R1 Agricultural, R4 Industrial, Golf tires R1 Agricultural - Front 11.2x24 9.5-20 R1 Agricultural - Rear 16.9x30 14.9-28 R3 Turf - Front Not Published 29x12.5-15 (golf tire) R3 Turf - Rear Not Published 44x18.00-20 (golf tire) R4 Industrial - Front Not Published 10.5/80-18 R4 Industrial - Rear Not Published 16.9-24 ▶ Loader & AttachmentsQuick Attach Loader System BL45: Quick attachment bucket mount L4058PC: Quick attach mechanism Loader Model BL45 L4058PC Loader Lift Height BL45: 111.7 in L4058PC: 117.5 in Loader Lift Capacity (Full Height) BL45: 2,804 lb (at pivot pins, full height) L4058PC: 3,437 lb (at pivot pin) Loader Breakout Force BL45: 5,467 lbf (at pivot pin, ground level) L4058PC: 4,742 lb (at pivot pin, ground level) ▶ WarrantyWarranty Length & Coverage Four-year limited warranty Basic 2 years or 2,000 hours; powertrain 3,000 hours maximum, parts and labor; loaders and backhoes 12 months
