▶ EngineEngine Manufacturer Doosan Infracore FPT Engine Model D34P NEF Engine Type 4-cylinder, turbocharged diesel 4-cylinder, 16-valve, turbocharged and intercooled, common-rail diesel No. of Cylinders 4 4 Displacement 208 in³ 274 in³ Rated Engine Speed 2300 rpm 2200 rpm Engine Power (Gross) 110 hp 110 hp PTO Power 98.8 hp 92 hp Engine Emissions Constraints Tier 4 Tier 4B/Final Cooling System Type Liquid-cooled Not Published Air Cleaner Dual dry Not Published Fuel System CRDI High-pressure common rail fuel injection Alternator 110 A, 12 V 120 A ▶ HydraulicsPump Type Dual gear pump Fixed-displacement pumps for steering, implement and auxiliary circuits, with a combining/diverter valve Implement Flow 14.1 gpm 13 gpm (implement pump); 9 gpm auxiliary pump standard on Plus, optional on Value Steering Flow 7.1 gpm 7 gpm Total Hydraulic Flow 21.3 gpm 29 gpm (with the 9 gpm auxiliary pump: standard on Plus, optional on Value) Overall Hydraulic Pump Flow 21.3 gpm 29 gpm (with the 9 gpm auxiliary pump: standard on Plus, optional on Value) Hydraulic System Type Open center Fixed-displacement pumps with combining/diverter valve; closed-center rear remote valves with flow control Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 3 Not Published No. of Optional Remote Valves Not Published Not Published ▶ Fluid CapacityFuel Tank Capacity 29.1 gal (DEF 5.3 gal) 57.5 gal Coolant Capacity 17.4 qt Not Published Crankcase Capacity 16.8 qt Not Published Transmission / Hydraulic System Capacity 19.8 gal Not Published Front Axle Fluid Capacity 18.4 qt Not Published ▶ PTO & HitchPTO Type Independent Not Published PTO Rear 540/750/1000 rpm 540/1000 rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II Category II (flex link ends) Hitch Lift Capacity 6,860 lb 3,735 lb (ASAE); 5,499 lb with one optional auxiliary lift cylinder; 7,326 lb with two Hitch Lift Capacity (at 24”) 5,490 lb Not Published Lift Control Type Position/Draft/Elec Not Published ▶ Transmission & DrivetrainTransmission Type Power shuttle & Hi-Lo shift 8x8 synchronized power shuttle (hydraulic, left-hand) standard; 16x8 Dual Power synchronized hydraulic shuttle with Hi-Lo (premium); 10:1 creeper optional No. of Speeds F32 x R32 8F/8R (base); 16F/8R (premium Dual Power with Hi-Lo) Max Travel Speed (Forward) 24.6 mph 19 mph or 25 mph (25 mph 4WD only) Max Travel Speed (Reverse) Not Published Not Published Clutch Wet multi plate Not Published Differential Lock & Limited Slip Options Not Published Not Published ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic Not Published Brakes Wet disc Not Published Seat Suspension & Adjustability Not Published Mechanical-suspension seat standard; air-suspension seat with swivel and full-size cushioned instructor seat optional (VisionView cab) Front Axle Type 4WD 4WD heavy-duty front axle, standard-duty Class 3 (cab and 4WD only) Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 86 in Not Published Wheelbase 90.6 in 99.2 in (4WD, Standard Duty Class 3 axle) Ground Clearance 18.3 in Not Published Min. Turn Radius without Brakes 162 in Not Published Height to Top of ROPS Not Published Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 107 in 110.2 in Overall Length 167.3 in (with 3-point hitch) 184.7 in (4WD, with front weights) ▶ WeightTractor Weight (Base) 8,929 lb 11,200 lb (shipping, 4WD, cab, flange axle); 12,192 lb (4WD, cab, bar axle) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Not Published 18.4-38 R1 rear with 14.9-28 R1 front (4WD) R1 Agricultural - Front FSTR 380/85R24 TL (14.9R24) 14.9-28 (4WD) R1 Agricultural - Rear FSTR 460/85R34 TL (18.4R34) 18.4-38 R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published Not Published R4 Industrial - Rear Not Published Not Published ▶ Loader & AttachmentsQuick Attach Loader System Not Published Skid steer (SSL) or Euro style attachment couplers Loader Model TX110SL 830LA (NSL); 835LA (MSL) Loader Lift Height TX110SL: 144.4 in 830LA: 150.0 in; 835LA: 150.0 in (to pivot pin) Loader Lift Capacity (Full Height) TX110SL: 4,129 lb (at pivot pin) 830LA: 2,557 lb; 835LA: 3,813 lb (to maximum height, measured 31.5 in forward of the pivot pin) Loader Breakout Force TX110SL: 6,025 lb (at pivot pin, ground level) 830LA: 3,681 lb; 835LA: 3,968 lb (measured 31.5 in forward of the pivot pin) ▶ WarrantyWarranty Length & Coverage Basic 24 months or 2,000 hours, parts and labor; loaders, backhoes and mid-mount mowers 12 months Not Published
