▶ EngineEngine Manufacturer Doosan Infracore FPT Engine Model D34P F36 Engine Type 4-cylinder, turbocharged diesel 4-cylinder No. of Cylinders 4 4 Displacement 208 in³ Not Published Rated Engine Speed 2300 rpm Not Published Engine Power (Gross) 110 hp 110 hp PTO Power 98.8 hp 93 hp Engine Emissions Constraints Tier 4 Not Published Cooling System Type Liquid-cooled Not Published Air Cleaner Dual dry Not Published Fuel System CRDI Not Published Alternator 110 A, 12 V Not Published ▶ HydraulicsPump Type Dual gear pump Not Published Implement Flow 14.1 gpm Not Published Steering Flow 7.1 gpm Not Published Total Hydraulic Flow 21.3 gpm 26.6 gpm Overall Hydraulic Pump Flow 21.3 gpm Not Published Hydraulic System Type Open center Not Published Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 3 Not Published No. of Optional Remote Valves Not Published Not Published ▶ Fluid CapacityFuel Tank Capacity 29.1 gal (DEF 5.3 gal) 34.3 gal Coolant Capacity 17.4 qt Not Published Crankcase Capacity 16.8 qt Not Published Transmission / Hydraulic System Capacity 19.8 gal Not Published Front Axle Fluid Capacity 18.4 qt Not Published ▶ PTO & HitchPTO Type Independent Not Published PTO Rear 540/750/1000 rpm Not Published Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II Not Published Hitch Lift Capacity 6,860 lb Not Published Hitch Lift Capacity (at 24”) 5,490 lb Not Published Lift Control Type Position/Draft/Elec Not Published ▶ Transmission & DrivetrainTransmission Type Power shuttle & Hi-Lo shift 12x12 electronic power shuttle No. of Speeds F32 x R32 12 forward / 12 reverse Max Travel Speed (Forward) 24.6 mph Not Published Max Travel Speed (Reverse) Not Published Not Published Clutch Wet multi plate Not Published Differential Lock & Limited Slip Options Not Published Not Published ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic Not Published Brakes Wet disc Not Published Seat Suspension & Adjustability Not Published Air ride seat (standard); instructor seat available Front Axle Type 4WD Class 1.0 HD heavy-duty front axle Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 86 in Not Published Wheelbase 90.6 in Not Published Ground Clearance 18.3 in Not Published Min. Turn Radius without Brakes 162 in Not Published Height to Top of ROPS Not Published Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 107 in Not Published Overall Length 167.3 in (with 3-point hitch) Not Published ▶ WeightTractor Weight (Base) 8,929 lb Not Published Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Not Published Not Published R1 Agricultural - Front FSTR 380/85R24 TL (14.9R24) Not Published R1 Agricultural - Rear FSTR 460/85R34 TL (18.4R34) Not Published R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published Not Published R4 Industrial - Rear Not Published Not Published ▶ Loader & AttachmentsQuick Attach Loader System Not Published Not Published Loader Model TX110SL 630LU; 635LU Loader Lift Height TX110SL: 144.4 in 143.9 in (630LU and 635LU) Loader Lift Capacity (Full Height) TX110SL: 4,129 lb (at pivot pin) 630LU: 2,764 lb; 635LU: 3,882 lb (at max height, @ 31.5 in) Loader Breakout Force TX110SL: 6,025 lb (at pivot pin, ground level) Not Published ▶ WarrantyWarranty Length & Coverage Basic 24 months or 2,000 hours, parts and labor; loaders, backhoes and mid-mount mowers 12 months Not Published
