▶ EngineEngine Manufacturer Deutz AGCO Power Engine Model TCD 3.6L4-C5VT83E 44 AWFC Engine Type Water-cooled, 4-cylinder diesel engine 4-cylinder, intercooled turbocharged, liquid-cooled diesel No. of Cylinders 4 4 Displacement 221 in³ 268.5 in³ Rated Engine Speed 2200 rpm 2200 rpm Engine Power (Gross) 111 hp 110 hp PTO Power 107.3 hp Power Shuttle: 93 hp; Dyna-4: 86 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Water-cooled Liquid cooled Air Cleaner Dual dry Not Published Fuel System CRDI High-pressure common-rail direct injection (HPCR) Alternator 120 A, 12 V 80 A, 12 V ▶ HydraulicsPump Type Dual gear pump Two high-pressure gear pumps Implement Flow 14.3 gpm 15.1 gpm Steering Flow 7.1 gpm Not Published Total Hydraulic Flow 21.4 gpm 26 gpm Overall Hydraulic Pump Flow 21.4 gpm Not Published Hydraulic System Type Not Published Open center Rear Remote Hydraulic Flow Not Published 26 gpm No. of Standard Remote Valves 6 2 No. of Optional Remote Valves Not Published 1 ▶ Fluid CapacityFuel Tank Capacity 31.7 gal 38.3 gal Coolant Capacity 19.1 qt Not Published Crankcase Capacity 8.5 qt Not Published Transmission / Hydraulic System Capacity 23.8 gal Not Published Front Axle Fluid Capacity 18.4 qt Not Published ▶ PTO & HitchPTO Type Independent Independent, electro-hydraulic engagement via switch PTO Rear 540/540E/1000 rpm (Reversible shaft) 540 / 540E / 1000 rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II Category II Hitch Lift Capacity 7,295 lb Not Published Hitch Lift Capacity (at 24”) 6,007 lb 7,710 lb Lift Control Type Position/Draft Cab: electric controlled 3-point linkage with draft control; Platform: lever controlled 3-point linkage with draft control ▶ Transmission & DrivetrainTransmission Type Power shuttle & Hi-Lo shift Power Shuttle: 12F x 12R, 2 ranges, electro-hydraulic shuttle; Dyna-4: 16F x 16R powershift No. of Speeds F32 x R32 w/Creep Power Shuttle: 12 forward, 12 reverse; Dyna-4: 16 forward, 16 reverse Max Travel Speed (Forward) 23 mph 25 mph Max Travel Speed (Reverse) Not Published Not Published Clutch Wet multi-plate Wet clutch with easy shift knob and electrohydraulic power shuttle lever Differential Lock & Limited Slip Options Not Published Electro-hydraulic rear differential lock (rocker switch); hydraulic front differential lock on 4WD ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic Cab: tilt and telescopic steering column; Platform: tilt steering column Brakes Wet, Multi disc Hydraulic multidisc brakes with mechanical parking brake, independently controlled via foot pedals Seat Suspension & Adjustability Air-ride full suspension seat Cab: air-suspension swivel seat; platform: mechanical spring-suspension seat with armrests Front Axle Type 4WD, inboard planetary gear design Heavy-duty 4WD front axle, center driveline Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 89.4 in 64.8 in Wheelbase 93.7 in 95.7 in Ground Clearance 16.7 in Not Published Min. Turn Radius without Brakes 159.5 in (left); 161 in (right) Not Published Height to Top of ROPS Not Published Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 112.2 in Not Published Overall Length 175.2 in (with 3-point hitch) Not Published ▶ WeightTractor Weight (Base) 8,940 lb 4WD ROPS: 9,195 lb; 4WD Cab: 10,011 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Not Published Rear: 460/85R34 standard radial R1 Agricultural - Front 13.6-24 Not Published R1 Agricultural - Rear 18.4-34 Not Published R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published Not Published R4 Industrial - Rear Not Published Not Published ▶ Loader & AttachmentsQuick Attach Loader System Not Published Not Published Loader Model TL115SL 941X; 946X; FL.3723; FL.3819 Loader Lift Height TL115SL: 144.4 in 941X: 148 in; 946X: 148 in; FL.3723: 149 in; FL.3819: 149 in Loader Lift Capacity (Full Height) TL115SL: 4,129 lb 941X: 2,220 lb; FL.3723: 2,840 lb (to full height, at 31.5 in forward of pivot pin) Loader Breakout Force TL115SL: 6,025 lb (at pivot pin, ground level) FL.3723: 5,819 lb; FL.3819: 4,893 lb ▶ WarrantyWarranty Length & Coverage Basic 24 months or 2,000 hours, parts and labor; loaders, backhoes and mid-mount mowers 12 months Not Published
