▶ EngineEngine Manufacturer Deutz FPT Engine Model TCD 3.6L4-C5VT83E F36 Engine Type Water-cooled, 4-cylinder diesel engine 4-cylinder No. of Cylinders 4 4 Displacement 221 in³ Not Published Rated Engine Speed 2200 rpm Not Published Engine Power (Gross) 111 hp 110 hp PTO Power 107.3 hp 93 hp Engine Emissions Constraints Not Published Not Published Cooling System Type Water-cooled Not Published Air Cleaner Dual dry Not Published Fuel System CRDI Not Published Alternator 120 A, 12 V Not Published ▶ HydraulicsPump Type Dual gear pump Not Published Implement Flow 14.3 gpm Not Published Steering Flow 7.1 gpm Not Published Total Hydraulic Flow 21.4 gpm 26.6 gpm Overall Hydraulic Pump Flow 21.4 gpm Not Published Hydraulic System Type Not Published Not Published Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 6 Not Published No. of Optional Remote Valves Not Published Not Published ▶ Fluid CapacityFuel Tank Capacity 31.7 gal 34.3 gal Coolant Capacity 19.1 qt Not Published Crankcase Capacity 8.5 qt Not Published Transmission / Hydraulic System Capacity 23.8 gal Not Published Front Axle Fluid Capacity 18.4 qt Not Published ▶ PTO & HitchPTO Type Independent Not Published PTO Rear 540/540E/1000 rpm (Reversible shaft) Not Published Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II Not Published Hitch Lift Capacity 7,295 lb Not Published Hitch Lift Capacity (at 24”) 6,007 lb Not Published Lift Control Type Position/Draft Not Published ▶ Transmission & DrivetrainTransmission Type Power shuttle & Hi-Lo shift 12x12 electronic power shuttle No. of Speeds F32 x R32 w/Creep 12 forward / 12 reverse Max Travel Speed (Forward) 23 mph Not Published Max Travel Speed (Reverse) Not Published Not Published Clutch Wet multi-plate Not Published Differential Lock & Limited Slip Options Not Published Not Published ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic Not Published Brakes Wet, Multi disc Not Published Seat Suspension & Adjustability Air-ride full suspension seat Air ride seat (standard); instructor seat available Front Axle Type 4WD, inboard planetary gear design Class 1.0 HD heavy-duty front axle Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 89.4 in Not Published Wheelbase 93.7 in Not Published Ground Clearance 16.7 in Not Published Min. Turn Radius without Brakes 159.5 in (left); 161 in (right) Not Published Height to Top of ROPS Not Published Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 112.2 in Not Published Overall Length 175.2 in (with 3-point hitch) Not Published ▶ WeightTractor Weight (Base) 8,940 lb Not Published Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Not Published Not Published R1 Agricultural - Front 13.6-24 Not Published R1 Agricultural - Rear 18.4-34 Not Published R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published Not Published R4 Industrial - Rear Not Published Not Published ▶ Loader & AttachmentsQuick Attach Loader System Not Published Not Published Loader Model TL115SL 630LU; 635LU Loader Lift Height TL115SL: 144.4 in 143.9 in (630LU and 635LU) Loader Lift Capacity (Full Height) TL115SL: 4,129 lb 630LU: 2,764 lb; 635LU: 3,882 lb (at max height, @ 31.5 in) Loader Breakout Force TL115SL: 6,025 lb (at pivot pin, ground level) Not Published ▶ WarrantyWarranty Length & Coverage Basic 24 months or 2,000 hours, parts and labor; loaders, backhoes and mid-mount mowers 12 months Not Published
