▶ EngineEngine Manufacturer Deutz Kukje Engine Model TCD 3.6L4-C5VT83E 7845C: D3400T10-UTC-3; 7845R: D3400T1-UTR-3 Engine Type Water-cooled, 4-cylinder diesel engine Turbocharged, direct injection, liquid-cooled diesel No. of Cylinders 4 4 Displacement 221 in³ 208 in³ Rated Engine Speed 2200 rpm 2500 rpm Engine Power (Gross) 111 hp 78 hp PTO Power 107.3 hp 64 hp Engine Emissions Constraints Not Published Not Published Cooling System Type Water-cooled Liquid-cooled Air Cleaner Dual dry Dry, double filter element Fuel System CRDI Direct injection Alternator 120 A, 12 V 70 A, 12 V ▶ HydraulicsPump Type Dual gear pump Dual pumps (separate steering and main pumps) Implement Flow 14.3 gpm Not Published Steering Flow 7.1 gpm Not Published Total Hydraulic Flow 21.4 gpm 19.3 gpm Overall Hydraulic Pump Flow 21.4 gpm Not Published Hydraulic System Type Not Published Electric over hydraulic control (position, draft & mixed) Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 6 Not Published No. of Optional Remote Valves Not Published Not Published ▶ Fluid CapacityFuel Tank Capacity 31.7 gal 23.8 gal Coolant Capacity 19.1 qt Not Published Crankcase Capacity 8.5 qt Not Published Transmission / Hydraulic System Capacity 23.8 gal Not Published Front Axle Fluid Capacity 18.4 qt Not Published ▶ PTO & HitchPTO Type Independent Independent (6-spline shaft) PTO Rear 540/540E/1000 rpm (Reversible shaft) Not Published Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II Category II Hitch Lift Capacity 7,295 lb 3,820 lb Hitch Lift Capacity (at 24”) 6,007 lb 2,526 lb Lift Control Type Position/Draft Position, draft & mixed ▶ Transmission & DrivetrainTransmission Type Power shuttle & Hi-Lo shift Power shuttle (hydraulic shuttle); main shifting fully synchronized (4-speed) No. of Speeds F32 x R32 w/Creep 16F/16R Max Travel Speed (Forward) 23 mph 24.8 mph Max Travel Speed (Reverse) Not Published 25.6 mph Clutch Wet multi-plate Multi, wet Differential Lock & Limited Slip Options Not Published Not Published ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic Hydrostatic Brakes Wet, Multi disc Wet disc Seat Suspension & Adjustability Air-ride full suspension seat Deluxe seat with lumbar adjustment Front Axle Type 4WD, inboard planetary gear design 4WD, heavy-duty front axle, 56-degree steering angle each direction, no drag link Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 89.4 in 74.5 in Wheelbase 93.7 in 86.6 in Ground Clearance 16.7 in 18.3 in Min. Turn Radius without Brakes 159.5 in (left); 161 in (right) Not Published Height to Top of ROPS Not Published 102.6 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 112.2 in 107.8 in Overall Length 175.2 in (with 3-point hitch) 152.7 in ▶ WeightTractor Weight (Base) 8,940 lb 7845C: 6,250 lb; 7845R: 5,752 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Not Published Agricultural: 11.2x24 front / 16.9x30 rear R1 Agricultural - Front 13.6-24 11.2x24 R1 Agricultural - Rear 18.4-34 16.9x30 R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published Not Published R4 Industrial - Rear Not Published Not Published ▶ Loader & AttachmentsQuick Attach Loader System Not Published BL45: Quick attachment bucket mount Loader Model TL115SL BL45 Loader Lift Height TL115SL: 144.4 in BL45: 111.7 in Loader Lift Capacity (Full Height) TL115SL: 4,129 lb BL45: 2,804 lb (at pivot pins, full height) Loader Breakout Force TL115SL: 6,025 lb (at pivot pin, ground level) BL45: 5,467 lbf (at pivot pin, ground level) ▶ WarrantyWarranty Length & Coverage Basic 24 months or 2,000 hours, parts and labor; loaders, backhoes and mid-mount mowers 12 months Four-year limited warranty
