▶ EngineEngine Manufacturer Deutz John Deere Engine Model TCD3.6L4 PowerTech 4045 EWL Engine Type Water-cooled, 4-cylinder diesel engine Diesel, turbocharged with intercooler, 4-valve HPCR No. of Cylinders 4 4 Displacement 221 in³ 276 in³ Rated Engine Speed 2200 rpm 2200 rpm Engine Power (Gross) 127 hp 130 hp PTO Power 118 hp 115 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Water-cooled Not Published Air Cleaner Dual dry Dry type air cleaner with safety (secondary) element Fuel System CRDI Electronic high-pressure common-rail injection, 4-valve Alternator 120 A, 12 V 120 A, 12 V ▶ HydraulicsPump Type Dual gear pump Tandem gear pump Implement Flow 20.1 gpm 18.4 gpm Steering Flow 9.1 gpm 6.3 gpm Total Hydraulic Flow 29.2 gpm 25.6 gpm Overall Hydraulic Pump Flow 29.2 gpm 25.6 gpm Hydraulic System Type Not Published Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 6 2 (rear); 2 (mid) No. of Optional Remote Valves Not Published Up to 3 total (rear); up to 3 total (mid) ▶ Fluid CapacityFuel Tank Capacity 50.2 gal 43.7 gal (Standard Cab) Coolant Capacity 19.1 qt Not Published Crankcase Capacity 8.5 qt Not Published Transmission / Hydraulic System Capacity 26.9 gal Not Published Front Axle Fluid Capacity 6.3 qt Not Published ▶ PTO & HitchPTO Type Independent Independent rear PTO, electro-hydraulic clutch PTO Rear 540/540E/1000 rpm (Reversible shaft) 540/1000 rpm standard; 540 rpm optional Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II Category II (convertible to I) Hitch Lift Capacity 8,261 lb Not Published Hitch Lift Capacity (at 24”) 8,014 lb 6,975 lb standard; 7,868 lb optional Lift Control Type Position/Draft Electrohydraulic ▶ Transmission & DrivetrainTransmission Type Power shuttle & 6-speed shift APS PowrQuad PLUS 16F/16R or Powr8 32F/16R (cab only) No. of Speeds F36 x R36 w/Creep 16F/16R (PowrQuad PLUS); 32F/16R (Powr8) Max Travel Speed (Forward) 23 mph 24.9 mph; PowrQuad PLUS 16F/16R (standard) or Powr8 32F/16R (optional) Max Travel Speed (Reverse) Not Published Not Published Clutch Wet Multi Plate Electro-hydraulic Differential Lock & Limited Slip Options Not Published Electro-hydraulic rear differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Cast iron mid-frame design Steering Hydrostatic Power steering Brakes Wet, Multi disc Hydraulic wet disc brakes, self-equalizing and self-adjusting Seat Suspension & Adjustability Air-ride full suspension seat Mechanical-suspension seat, standard; air-suspension seat, optional; heated low-frequency air-suspension seat, optional Front Axle Type Not Published MFWD Front Axle Rating Not Published Not Published Drawbar Capacity Not Published 3,197 lb ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 176.8 in Not Published Overall Width 92.9 in Not Published Wheelbase 102 in 92.5 in Ground Clearance 16.1 in Not Published Min. Turn Radius without Brakes 186.6 in (left); 189 in (right) 13.1 ft Height to Top of ROPS Not Published Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 115.7 in Not Published ▶ WeightTractor Weight (Base) 10,020 lb 9,185 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Not Published R1 Agricultural R1 Agricultural - Front 380/85 R28 12.4R24 R1 Agricultural - Rear 460/85 R38 (18.4R38) 18.4R30 R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published 12.5/80-18 in, 12PR R4 Bias R4 Industrial - Rear Not Published 19.5L-24 in, 10PR R4 Bias ▶ Loader & AttachmentsQuick Attach Loader System Not Published Not Published Loader Model TL130SL 520M (4WD only); 540M; 540R; 600M Loader Lift Height TL130SL: 162 in 520M: NSL/MSL 130-132 in; 540M: NSL 137-141 in, MSL 138-141 in; 540R: 141.85 in; 600M: NSL 148.8-152.8 in, MSL 148-153 in Loader Lift Capacity (Full Height) TL130SL: 5,415 lb 520M (4WD): NSL 3,335-3,612 lb, MSL 2,460-2,661 lb; 540M: NSL 2,394-2,666 lb, MSL 3,117-3,309 lb; 540R: 3,406 lb; 600M: NSL 3,104-3,236 lb, MSL 3,891-4,085 lb Loader Breakout Force TL130SL: 6,618 lb Not Published ▶ WarrantyWarranty Length & Coverage Basic 2 years or 2,000 hours; powertrain 3,000 hours maximum, parts and labor; loaders and backhoes 12 months Basic 24 months or 2,000 hours, whole-machine standard agricultural equipment term
