▶ EngineEngine Manufacturer Deutz FPT Industrial Engine Model TCD3.6L4 NEF Engine Type Water-cooled, 4-cylinder diesel engine 4-cylinder diesel No. of Cylinders 4 4 Displacement 221 in³ 273.7 in³ Rated Engine Speed 2200 rpm 2200 rpm Engine Power (Gross) 127 hp 130 hp PTO Power 118 hp 111 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Water-cooled Liquid-cooled Air Cleaner Dual dry Not Published Fuel System CRDI Not Published Alternator 120 A, 12 V Standard: 120 A, 12 V; Optional: 200 A, 12 V ▶ HydraulicsPump Type Dual gear pump Closed-center load-sensing pump plus separate steering and services pump Implement Flow 20.1 gpm 21.1 gpm Steering Flow 9.1 gpm 9.6 gpm Total Hydraulic Flow 29.2 gpm Not Published Overall Hydraulic Pump Flow 29.2 gpm Not Published Hydraulic System Type Not Published Closed center load sensing (CCLS) Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 6 Not Published No. of Optional Remote Valves Not Published Up to 4 rear remote valves (with diverter); up to 3 mid-mount valves ▶ Fluid CapacityFuel Tank Capacity 50.2 gal 47.5 gal Coolant Capacity 19.1 qt Not Published Crankcase Capacity 8.5 qt Not Published Transmission / Hydraulic System Capacity 26.9 gal Not Published Front Axle Fluid Capacity 6.3 qt Not Published ▶ PTO & HitchPTO Type Independent Fully independent direct-drive PTO with electro-hydraulic wet clutch and Soft Start PTO Rear 540/540E/1000 rpm (Reversible shaft) 540/1000 rpm (540 at 1969, 540E at 1546, 1000 at 1893 engine rpm) Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II Category II Hitch Lift Capacity 8,261 lb 12,125 lb (at ball ends) Hitch Lift Capacity (at 24”) 8,014 lb 10,228 lb Lift Control Type Position/Draft Electronic draft control (EDC) ▶ Transmission & DrivetrainTransmission Type Power shuttle & 6-speed shift APS Dynamic Command: 24x24 dual-clutch 8-step semi-powershift; Auto Command: continuously variable transmission (CVT) No. of Speeds F36 x R36 w/Creep Dynamic Command: 24F/24R; Auto Command: infinitely variable Max Travel Speed (Forward) 23 mph Dynamic Command: 25 mph; Auto Command: 25 mph (31 mph optional) Max Travel Speed (Reverse) Not Published Not Published Clutch Wet Multi Plate Not Published Differential Lock & Limited Slip Options Not Published Automatic differential lock and automatic 4WD engagement (standard); electro-hydraulic front and rear differential locks ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic Power steering Brakes Wet, Multi disc Hydraulic wet disc Seat Suspension & Adjustability Air-ride full suspension seat Standard: low-frequency suspension seat, cloth; optional: heated seat with active ventilation; instructor seat optional Front Axle Type Not Published Class 1.75 heavy-duty 4WD front axle (standard); Terraglide suspension (optional) Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 176.8 in 173 in (max, weight carrier to rear linkage) Overall Width 92.9 in 74 in (narrow); 90 in (standard) Wheelbase 102 in 98 in Ground Clearance 16.1 in Not Published Min. Turn Radius without Brakes 186.6 in (left); 189 in (right) 182 in (4WD, Terraglide suspended front axle; brake use not stated) Height to Top of ROPS Not Published Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 115.7 in 106 in (low-profile roof, 540/65R34 tires) ▶ WeightTractor Weight (Base) 10,020 lb 12,125 lb (minimum shipping weight, cab) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Not Published Not Published R1 Agricultural - Front 380/85 R28 Not Published R1 Agricultural - Rear 460/85 R38 (18.4R38) Not Published R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published Not Published R4 Industrial - Rear Not Published Not Published ▶ Loader & AttachmentsQuick Attach Loader System Not Published Not Published Loader Model TL130SL 800TL Series (wide frame) Loader Lift Height TL130SL: 162 in Not Published Loader Lift Capacity (Full Height) TL130SL: 5,415 lb Not Published Loader Breakout Force TL130SL: 6,618 lb Not Published ▶ WarrantyWarranty Length & Coverage Basic 2 years or 2,000 hours; powertrain 3,000 hours maximum, parts and labor; loaders and backhoes 12 months Not Published
