▶ EngineEngine Manufacturer Yanmar Yanmar Engine Model 3TNV74F 3TNV74F Engine Type 3-cylinder, naturally aspirated diesel Naturally aspirated, indirect injection, liquid-cooled diesel No. of Cylinders 3 3 Displacement 60.6 in³ 60.6 in³ Rated Engine Speed 3000 rpm 3000 rpm Engine Power (Gross) 19 hp 19.4 hp PTO Power 14.6 hp 14.2 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Water-cooled Water-cooled Air Cleaner Single dry Not Published Fuel System IDI Indirect Injection Alternator 40 A, 12 V 45 A, 12 V ▶ HydraulicsPump Type Single gear pump Not Published Implement Flow 4.17 gpm 4.1 gpm Steering Flow 2.11 gpm 2.11 gpm Total Hydraulic Flow 6.28 gpm 6.2 gpm Overall Hydraulic Pump Flow 6.28 gpm 6.2 gpm Hydraulic System Type Open center Open Center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves 1 1 ▶ Fluid CapacityFuel Tank Capacity 6.6 gal 6.6 gal Coolant Capacity 3.7 qt Not Published Crankcase Capacity 2.1 qt Not Published Transmission / Hydraulic System Capacity 3.6 gal Not Published Front Axle Fluid Capacity 2.6 qt Not Published ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540 rpm 540 @ 2942 rpm Mid-PTO Availability Available Available; 2500 @ 2958 rpm Category, 3-Point Hitch Category I (Narrow) CAT I Narrow with Check Chains Hitch Lift Capacity 1,100 lb 680 lb Hitch Lift Capacity (at 24”) 679 lb Not Published Lift Control Type Position control Position ▶ Transmission & DrivetrainTransmission Type HST HST - 2 range No. of Speeds 2 Range Infinite Max Travel Speed (Forward) 7.8 mph Not Published Max Travel Speed (Reverse) Not Published Not Published Clutch Not Published Dry-Single Differential Lock & Limited Slip Options Differential lock Not Published ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic Power steering Brakes Wet disc Wet Disc Seat Suspension & Adjustability Not Published Not Published Front Axle Type Not Published Not Published Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 44.5 in 44.5 in Wheelbase 53.1 in 53.1 in Ground Clearance 8.3 in 8.3 in Min. Turn Radius without Brakes 86.6 in 7.2 ft Height to Top of ROPS 86.6 in Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published 79.6 in Overall Length 94.2 in (with 3-point hitch) 94.2 in ▶ WeightTractor Weight (Base) 1,433 lb 1,800 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published 2,219 lb (1,800 + 419, computed; 6.1 gal loader shipping weight) ▶ Tire OptionsTire Size & Options R1 Agricultural, R3 Turf, R4 Industrial Agricultural, Industrial, Turf R1 Agricultural - Front BAR F 16x6.50-8 18x8.5-10 R1 Agricultural - Rear BAR R 24x12.00-12 26x12-12 R3 Turf - Front 16x7.50-8 18x8.5-10 R3 Turf - Rear 24x12.00-12 26x12-12 R4 Industrial - Front 16x7.50-8 18x8.5-10 R4 Industrial - Rear 24x12.00-12 26x12-12 ▶ Loader & AttachmentsQuick Attach Loader System TX19H: Quick attach mechanism 23L: Skid steer style quick coupler, standard Loader Model TX19H 23L Loader Lift Height TX19H: 71.3 in 71.3 in Loader Lift Capacity (Full Height) TX19H: 617 lb 617 lb (at pivot pin) Loader Breakout Force TX19H: 1,235 lb (at pivot pin, ground level) 1,235 lb (at pivot pin, ground level) ▶ WarrantyWarranty Length & Coverage Not Published Two Year All Aggregate (bumper to bumper) Warranty and Five-Year Limited Powertrain Warranty
