▶ EngineEngine Manufacturer Yanmar Yanmar Engine Model 3TNV74F 3TNV74F Engine Type 3-cylinder, naturally aspirated diesel Diesel, swirl chamber combustion, naturally aspirated No. of Cylinders 3 3 Displacement 60.6 in³ 60.6 in³ Rated Engine Speed 3000 rpm 3000 rpm Engine Power (Gross) 19 hp 19 hp PTO Power 14.6 hp 13.4 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Water-cooled Liquid-cooled Air Cleaner Single dry Dry, single filter element Fuel System IDI Indirect injection (swirl chamber) Alternator 40 A, 12 V 40 A, 12 V ▶ HydraulicsPump Type Single gear pump Single gear pump with flow divider Implement Flow 4.17 gpm 4.17 gpm Steering Flow 2.11 gpm 2.11 gpm Total Hydraulic Flow 6.28 gpm 6.28 gpm (4.17 + 2.11, computed) Overall Hydraulic Pump Flow 6.28 gpm Not Published Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves 1 Not Published ▶ Fluid CapacityFuel Tank Capacity 6.6 gal 6.6 gal Coolant Capacity 3.7 qt 3.7 qt Crankcase Capacity 2.1 qt 2.1 qt Transmission / Hydraulic System Capacity 3.6 gal 3.6 gal Front Axle Fluid Capacity 2.6 qt 2.6 qt ▶ PTO & HitchPTO Type Independent Transmission-driven (over-running clutch) PTO Rear 540 rpm Not Published Mid-PTO Availability Available Not Published Category, 3-Point Hitch Category I (Narrow) Category I Hitch Lift Capacity 1,100 lb 1,100 lb Hitch Lift Capacity (at 24”) 679 lb 679 lb Lift Control Type Position control Position control ▶ Transmission & DrivetrainTransmission Type HST Hydrostatic (HST) No. of Speeds 2 Range Infinite (2-range HST) Max Travel Speed (Forward) 7.8 mph 7.8 mph Max Travel Speed (Reverse) Not Published 7.8 mph Clutch Not Published Dry, single Differential Lock & Limited Slip Options Differential lock Not Published ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic Hydrostatic power steering Brakes Wet disc Wet disc Seat Suspension & Adjustability Not Published Not Published Front Axle Type Not Published 4WD (MFWD) Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 44.5 in 44.5 in Wheelbase 53.1 in 53.1 in Ground Clearance 8.3 in 8.3 in Min. Turn Radius without Brakes 86.6 in Not Published Height to Top of ROPS 86.6 in 86.6 in Height to Top of ROPS (folded) Not Published 60 in Height to Top of Cab Model Not Published Not Published Overall Length 94.2 in (with 3-point hitch) 94.2 in ▶ WeightTractor Weight (Base) 1,433 lb 1,433 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural, R3 Turf, R4 Industrial Turf: 18x8.5-10 front, 26x12-12 rear; Industrial: 18x8.5-10 front, 26x12-12 rear R1 Agricultural - Front BAR F 16x6.50-8 16x7.50-9 R1 Agricultural - Rear BAR R 24x12.00-12 24x12.00-12 R3 Turf - Front 16x7.50-8 Not Published R3 Turf - Rear 24x12.00-12 Not Published R4 Industrial - Front 16x7.50-8 18x8.5-10 R4 Industrial - Rear 24x12.00-12 26x12-12 ▶ Loader & AttachmentsQuick Attach Loader System TX19H: Quick attach mechanism BL90: Standard pin-on (skid steer quick-attach optional) Loader Model TX19H BL90 Loader Lift Height TX19H: 71.3 in BL90: 71.3 in Loader Lift Capacity (Full Height) TX19H: 617 lb BL90: 617 lb (at pivot pin, full height) Loader Breakout Force TX19H: 1,235 lb (at pivot pin, ground level) BL90: 1,235 lbf (at pivot pin, ground level) ▶ WarrantyWarranty Length & Coverage Not Published Basic two years or 1,000 hours; powertrain 7 years or 2,000 hours
