▶ EngineEngine Manufacturer Yanmar Yanmar Engine Model 3TNV80F-NXDKTFX 3TNV80F Engine Type 3-cylinder, naturally aspirated diesel 3-cylinder, indirect injection (swirl chamber), water-cooled No. of Cylinders 3 3 Displacement 77.3 in³ 77.3 in³ Rated Engine Speed 3000 rpm 3000 rpm Engine Power (Gross) 24.7 hp 24.7 hp PTO Power 18.3 hp 17.2 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Not Published Water-cooled Air Cleaner Single dry Dry Fuel System IDI In-line injection pump Alternator 40 A, 12 V 40 A, 12 V ▶ HydraulicsPump Type Single gear pump Gear pump, transmission driven Implement Flow 4.17 gpm 4.6 gpm Steering Flow 2.77 gpm 2.1 gpm Total Hydraulic Flow 6.94 gpm 6.7 gpm Overall Hydraulic Pump Flow 6.94 gpm 6.7 gpm Hydraulic System Type Not Published Open center system, position control Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published None No. of Optional Remote Valves Not Published 1 set (2 quick couplers, optional) ▶ Fluid CapacityFuel Tank Capacity 8.4 gal 6.6 gal Coolant Capacity 0.95 gal 0.9 gal Crankcase Capacity Not Published 0.8 gal Transmission / Hydraulic System Capacity 4.49 gal 3.0 gal (3.4 gal with front-end loader; 4.7 gal with front-end loader and backhoe) Front Axle Fluid Capacity 1.18 gal 0.5 gal ▶ PTO & HitchPTO Type Independent Independent (electro-hydraulic) PTO Rear 540 rpm Standard (540 rpm) Mid-PTO Availability Available (Mid-PTO kit) Standard (2,500 rpm) Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 1,550 lb 992 lb Hitch Lift Capacity (at 24”) 560 lb 728 lb Lift Control Type Position control Position control ▶ Transmission & DrivetrainTransmission Type HST Hydrostatic Drive No. of Speeds 2 2 ranges Max Travel Speed (Forward) 13.57 mph 8.70 mph Max Travel Speed (Reverse) Not Published 5.22 mph Clutch Not Published N/A Differential Lock & Limited Slip Options Differential lock Mechanical pedal type ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydraulic Hydrostatic power steering Brakes Wet disc Wet, multi-disc Seat Suspension & Adjustability Mechanical suspension seat Adjustable forward and backward via seat lever; reversible seat optional Front Axle Type Four-wheel drive (standard) Front wheel mechanical assist (4WD) Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Hitch: 882 lb vertical, 3,527 lb horizontal; drawbar with clevis: 772 lb vertical, 3,527 lb horizontal ▶ Dimensions & ManeuverabilityOverall Width 56.29 in 47 in Wheelbase 61.02 in 56 in Ground Clearance 10.23 in Not Published Min. Turn Radius without Brakes 110.23 in 7.87 ft Height to Top of ROPS 85.94 in 87 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published Overall Length 105.11 in (with 3-point hitch) 97 in (bumper to link) ▶ WeightTractor Weight (Base) 2,207 lb 1,444 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R3 Turf, R4 Industrial, Hybrid Front 18x8.50-10, rear 26x12.0-12; offered in industrial or turf R1 Agricultural - Front Not Published Not Published R1 Agricultural - Rear Not Published Not Published R3 Turf - Front 23x8.5-12 18x8.50-10 R3 Turf - Rear 33x12.5-16.5 26x12.0-12 R4 Industrial - Front 23x8.5-14 18x8.50-10 R4 Industrial - Rear 14-17.5 26x12.0-12 ▶ Loader & AttachmentsQuick Attach Loader System L2025P: Quick attach mechanism Not Published Loader Model L2025P LL1102; LL1700; LL1001 Loader Lift Height L2025P: 87.7 in LL1001: 72.6 in (at pivot pin) Loader Lift Capacity (Full Height) L2025P: 1,380 lb (at pivot pin) LL1001: 902 lb (at pivot pin, maximum height) Loader Breakout Force L2025P: 2,059 lb (at pivot pin, ground level) LL1001: 1,836 lb (at pivot pin) ▶ WarrantyWarranty Length & Coverage Basic 2 years or 2,000 hours; powertrain 3,000 hours maximum, parts and labor; loaders and backhoes 12 months 6-year limited warranty
