▶ EngineEngine Manufacturer Yanmar TYM Engine Model 3TNV80F-NXDKTFX T1100N2 Engine Type 3-cylinder, naturally aspirated diesel 3-cylinder, naturally aspirated diesel No. of Cylinders 3 3 Displacement 77.3 in³ 71.7 in³ Rated Engine Speed 3000 rpm 2850 rpm Engine Power (Gross) 24.7 hp 24 hp PTO Power 18.3 hp 21 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Not Published Not Published Air Cleaner Single dry Dry element Fuel System IDI IDI Alternator 40 A, 12 V 60 A, 12 V ▶ HydraulicsPump Type Single gear pump Dual gear pump Implement Flow 4.17 gpm 4.7 gpm Steering Flow 2.77 gpm 3.3 gpm Total Hydraulic Flow 6.94 gpm 7.9 gpm Overall Hydraulic Pump Flow 6.94 gpm 7.9 gpm Hydraulic System Type Not Published Dual gear pump Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published None No. of Optional Remote Valves Not Published 2 ▶ Fluid CapacityFuel Tank Capacity 8.4 gal 6.0 gal Coolant Capacity 0.95 gal 5.3 qt Crankcase Capacity Not Published 2.9 qt Transmission / Hydraulic System Capacity 4.49 gal 3.7 gal Front Axle Fluid Capacity 1.18 gal 3.5 qt ▶ PTO & HitchPTO Type Independent Live PTO Rear 540 rpm 540/1000 rpm Mid-PTO Availability Available (Mid-PTO kit) Available Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 1,550 lb 1,499 lb Hitch Lift Capacity (at 24”) 560 lb 974 lb Lift Control Type Position control Position control ▶ Transmission & DrivetrainTransmission Type HST 2400R: Constant Mesh; 2400H: HST No. of Speeds 2 2400R: F6 x R2; 2400H: 2-Range Max Travel Speed (Forward) 13.57 mph 2400R: 9.9 mph; 2400H: 12.1 mph Max Travel Speed (Reverse) Not Published 2400R: 3.9 mph; 2400H: 12.1 mph Clutch Not Published Dry single plate Differential Lock & Limited Slip Options Differential lock Differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydraulic Hydrostatic Brakes Wet disc Wet, Multi disc Seat Suspension & Adjustability Mechanical suspension seat Comfortable suspension seat Front Axle Type Four-wheel drive (standard) 4WD Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 56.29 in 44.2 in Wheelbase 61.02 in 59.1 in Ground Clearance 10.23 in 12.1 in Min. Turn Radius without Brakes 110.23 in (L) 9.6 ft; (R) 9.5 ft Height to Top of ROPS 85.94 in 87.3 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published Overall Length 105.11 in (with 3-point hitch) 120.3 in (with 3-point hitch) ▶ WeightTractor Weight (Base) 2,207 lb 2400R: 1,792 lb; 2400H: 1,829 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R3 Turf, R4 Industrial, Hybrid R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural - Front Not Published 6-12 R1 Agricultural - Rear Not Published 9.5-16 R3 Turf - Front 23x8.5-12 23x8.50-12 R3 Turf - Rear 33x12.5-16.5 33x12.50-16.5 R4 Industrial - Front 23x8.5-14 23x8.50-12 R4 Industrial - Rear 14-17.5 12-16.5 ▶ Loader & AttachmentsQuick Attach Loader System L2025P: Quick attach mechanism BL100S: Quick attach mechanism Loader Model L2025P BL100S Loader Lift Height L2025P: 87.7 in BL100S: 88.3 in Loader Lift Capacity (Full Height) L2025P: 1,380 lb (at pivot pin) BL100S: 1,314 lb (at pivot pin) Loader Breakout Force L2025P: 2,059 lb (at pivot pin, ground level) BL100S: 1,960 lb (at pivot pin, ground level) ▶ WarrantyWarranty Length & Coverage Basic 2 years or 2,000 hours; powertrain 3,000 hours maximum, parts and labor; loaders and backhoes 12 months Basic 2 years or 2,000 hours; powertrain 3,000 hours maximum, parts and labor; loaders and backhoes 12 months ▶ ITC Company AccessoriesAccessories that fit None tagged yet
