▶ EngineEngine Manufacturer Yanmar TYM Engine Model 3TNV80F-NXDKTFX T1700N6 Engine Type 3-cylinder, naturally aspirated diesel 3-cylinder, naturally aspirated diesel No. of Cylinders 3 3 Displacement 77.3 in³ 104.5 in³ Rated Engine Speed 3000 rpm 2100 rpm Engine Power (Gross) 24.7 hp 24 hp PTO Power 18.3 hp 21 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Not Published Not Published Air Cleaner Single dry Dry element Fuel System IDI IDI Alternator 40 A, 12 V 50 A, 12 V ▶ HydraulicsPump Type Single gear pump Dual gear pump Implement Flow 4.17 gpm 7.7 gpm Steering Flow 2.77 gpm 4.2 gpm Total Hydraulic Flow 6.94 gpm 11.9 gpm Overall Hydraulic Pump Flow 6.94 gpm 11.9 gpm Hydraulic System Type Not Published Dual gear pump Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Loader: 2 / Rear: 0 No. of Optional Remote Valves Not Published Up to 4 ▶ Fluid CapacityFuel Tank Capacity 8.4 gal 7.1 gal Coolant Capacity 0.95 gal 5.3 qt Crankcase Capacity Not Published 4.5 qt Transmission / Hydraulic System Capacity 4.49 gal 2515R: 9 gal; 2515H: 9.8 gal Front Axle Fluid Capacity 1.18 gal 6.8 qt ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540 rpm 540 rpm Mid-PTO Availability Available (Mid-PTO kit) Not Published Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 1,550 lb 3,306 lb Hitch Lift Capacity (at 24”) 560 lb 2,425 lb Lift Control Type Position control Position control ▶ Transmission & DrivetrainTransmission Type HST 2515R: Synchromesh; 2515H: HST No. of Speeds 2 2515R: F12 x R12; 2515H: 3-Range Max Travel Speed (Forward) 13.57 mph 2515R: 11.7 mph; 2515H: 15.2 mph Max Travel Speed (Reverse) Not Published 2515R: 11.6 mph; 2515H: 15.2 mph Clutch Not Published 2515R: Dry single plate; 2515H: None (HST) Differential Lock & Limited Slip Options Differential lock Differential lock (standard) ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydraulic Hydrostatic power steering Brakes Wet disc Wet, multi-disc Seat Suspension & Adjustability Mechanical suspension seat Suspension seat Front Axle Type Four-wheel drive (standard) Not Published Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 56.29 in 56.3 in Wheelbase 61.02 in 65.7 in Ground Clearance 10.23 in 14.4 in Min. Turn Radius without Brakes 110.23 in L: 124.8 in; R: 121.3 in Height to Top of ROPS 85.94 in 97.3 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published Overall Length 105.11 in (with 3-point hitch) 120.9 in (with 3-point hitch) ▶ WeightTractor Weight (Base) 2,207 lb 2515R: 2,989 lb; 2515H: 2,969 lb Weight with ROPS and Loader Not Published 2515R: 3,997 lb (2,989 + 1,008, computed); 2515H: 3,977 lb (2,969 + 1,008, computed) Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R3 Turf, R4 Industrial, Hybrid R1 Agricultural 8-16 / 12.4-24; R3 Turf 27x8.5-15 6PR / 41x14.00 4PR; R4 Industrial 10-16.5 6PR / 420/70-24 6PR R1 Agricultural - Front Not Published 8-16 R1 Agricultural - Rear Not Published 12.4-24 R3 Turf - Front 23x8.5-12 27x8.5-15, 6PR R3 Turf - Rear 33x12.5-16.5 41x14.00, 4PR R4 Industrial - Front 23x8.5-14 10-16.5, 6PR R4 Industrial - Rear 14-17.5 420/70-24, 6PR ▶ Loader & AttachmentsQuick Attach Loader System L2025P: Quick attach mechanism BL150: Quick attach mechanism Loader Model L2025P BL150 Loader Lift Height L2025P: 87.7 in BL150: 104.9 in Loader Lift Capacity (Full Height) L2025P: 1,380 lb (at pivot pin) BL150: 2,200 lb (at pivot pin) Loader Breakout Force L2025P: 2,059 lb (at pivot pin, ground level) BL150: 3,422 lb (at pivot pin, ground level) ▶ WarrantyWarranty Length & Coverage Basic 2 years or 2,000 hours; powertrain 3,000 hours maximum, parts and labor; loaders and backhoes 12 months Basic 24 months or 2,000 hours, parts and labor; non-commercial, 20 to 70 engine hp: powertrain 72 months or 3,000 hours; loaders, backhoes and mid-mount mowers 12 months ▶ ITC Company AccessoriesAccessories that fit None tagged yet
