▶ EngineEngine Manufacturer Yanmar YANMAR Engine Model 3TNV80F 3TNV80F Engine Type 3-cylinder, naturally aspirated diesel 4-cycle inline, water-cooled diesel, naturally aspirated No. of Cylinders 3 3 Displacement 77.3 in³ 77.2 in³ Rated Engine Speed 3000 rpm 3200 rpm Engine Power (Gross) 24.7 hp 23.9 hp PTO Power 18.3 hp 18.1 hp Engine Emissions Constraints Tier 4 Not Published Cooling System Type Water-cooled Liquid cooled Air Cleaner Single dry Not Published Fuel System IDI Not Published Alternator 40 A, 12 V 40 A ▶ HydraulicsPump Type Single gear pump Dual hydraulic pump Implement Flow 4.2 gpm 4.3 gpm Steering Flow 2.8 gpm 3.7 gpm Total Hydraulic Flow 6.9 gpm 8.0 gpm (4.3 + 3.7, computed) Overall Hydraulic Pump Flow 6.9 gpm 8.0 gpm (4.3 + 3.7, computed) Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 1 Not Published No. of Optional Remote Valves Not Published Not Published ▶ Fluid CapacityFuel Tank Capacity 6.6 gal 6.1 gal Coolant Capacity 3.8 qt 3.0 qt Crankcase Capacity 2.9 qt 3.6 qt Transmission / Hydraulic System Capacity 4.5 gal 4.1 gal Front Axle Fluid Capacity 4.7 qt 3.7 qt ▶ PTO & HitchPTO Type Independent Independent, hydraulic clutch PTO Rear 540 rpm 554 rpm @ 3,200 engine rpm; 1.4 in OD, 6 splines Mid-PTO Availability Available (Mid-PTO kit) Independent mid-PTO, 2,057 rpm at 3,200 engine rpm, SAE 16/32, 15 splines Category, 3-Point Hitch Category I Limited Category I Hitch Lift Capacity 1,551 lb Not Published Hitch Lift Capacity (at 24”) 1,230 lb 1,209 lb Lift Control Type Position control Position control ▶ Transmission & DrivetrainTransmission Type HST Hydrostatic transmission, dual range speeds No. of Speeds Infinite 2-Range Infinite forward and reverse (hydrostatic); 2 ranges Max Travel Speed (Forward) 13.7 mph 13.1 mph (high range, with R4 tires) Max Travel Speed (Reverse) Not Published 9.1 mph (high range, with R4 tires) Clutch Not Published Not Published Differential Lock & Limited Slip Options Differential lock Differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Full-frame chassis Steering Hydrostatic Hydrostatic power steering Brakes Wet disc Wet disc Seat Suspension & Adjustability Heavy duty mechanical suspension seat, manually adjustable for weight Fore-and-aft adjustable operator seat Front Axle Type 4WD Cast iron, selectable 4WD Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 50 in 54.1 in (with R4 tires) Wheelbase 61 in 63.0 in Ground Clearance 10.2 in 9.9 in (with R4 tires) Min. Turn Radius without Brakes 111.8 in 8.5 ft Height to Top of ROPS 91.3 in 87.2 in (with R4 tires) Height to Top of ROPS (folded) Not Published 71.8 in (folded ROPS, top of steering wheel, R4 tires) Height to Top of Cab Model Not Published Not Published Overall Length 102.8 in (with 3-point hitch) 105.8 in (with 3-point hitch) ▶ WeightTractor Weight (Base) 2,046 lb 1,830 lb (with ROPS, R4 tires) Weight with ROPS and Loader Not Published 2,338 lb (1,830 + 508, computed) Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural, R3 Turf, R4 Industrial R3 Turf; R4 Industrial R1 Agricultural - Front 6-12 4PR Not Published R1 Agricultural - Rear 9.5-20 6PR Not Published R3 Turf - Front Turf Master 23x8.50-12 NHS TL 4PR 23x8.50-12 4PR R3 Turf - Rear Multi-Trac CS 33x12.50-16.5 NHS TL 4PR 36x14.00-15 4PR R4 Industrial - Front Trac Chief 23x8.50-14 NHS TL 4PR 23x8.50-12 4PR R4 Industrial - Rear 36X12.5-15 14-17.5 6PR ▶ Loader & AttachmentsQuick Attach Loader System TL25: Quick attach mechanism YL210: YANMAR quick attachment system Loader Model TL25 YL210 Loader Lift Height TL25: 87.2 in YL210: 79 in to pivot pin (58 in under level bucket) Loader Lift Capacity (Full Height) TL25: 1,380 lb (at pivot pin) YL210: 1,200 lb at pivot pin Loader Breakout Force TL25: 2,059 lb (at pivot pin, ground level) YL210: 2,090 lb at pivot pin ▶ WarrantyWarranty Length & Coverage Basic 2 years or 2,000 hours; powertrain 3,000 hours maximum, parts and labor; loaders and backhoes 12 months Private individual use: basic 24 months or 2,000 hours, powertrain 10 years or 3,000 hours; attachments 1 year ▶ ITC Company AccessoriesAccessories that fit None tagged yet
