▶ EngineEngine Manufacturer TYM TYM Engine Model T1100N2 A1100N2 Engine Type 3-cylinder, naturally aspirated diesel 3 cylinder, water-cooled diesel, swirl chamber, natural aspiration No. of Cylinders 3 3 Displacement 71.7 in³ 70.7 in³ Rated Engine Speed 2800 rpm 2600 rpm Engine Power (Gross) 24 hp 24 hp PTO Power 18.3 hp 18 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Water-cooled Air Cleaner Single dry Dry element Fuel System IDI Indirect injection (swirl chamber) Alternator 50 A, 12 V 50 A, 12 V ▶ HydraulicsPump Type Dual gear pump Gear type pump with primary and secondary pumps Implement Flow 4.4 gpm 4.3 gpm Steering Flow 2.7 gpm 3.1 gpm Total Hydraulic Flow 7.1 gpm 7.4 gpm Overall Hydraulic Pump Flow 7.1 gpm 7.7 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 0 0 No. of Optional Remote Valves 1 1 ▶ Fluid CapacityFuel Tank Capacity 6.6 gal 6.08 gal Coolant Capacity 5.9 qt 1.21 gal Crankcase Capacity 4.5 qt 0.79 gal Transmission / Hydraulic System Capacity 4.7 gal 2.90 gal Front Axle Fluid Capacity 4.7 qt 0.79 gal ▶ PTO & HitchPTO Type Independent Live PTO (6 spline shaft) PTO Rear 540 rpm 540 / 960 rpm Mid-PTO Availability Available Optional, 2,500 rpm Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 1,534 lb 1,433 lb Hitch Lift Capacity (at 24”) 1,102 lb 974 lb Lift Control Type Position control Position control ▶ Transmission & DrivetrainTransmission Type HST Hydrostatic (HST) No. of Speeds Infinite 2-Range 3 range (L/M/H) Max Travel Speed (Forward) 12.9 mph 14.8 mph Max Travel Speed (Reverse) Not Published 14.8 mph Clutch Dry single plate Dry, single plate Differential Lock & Limited Slip Options Differential lock Mechanical rear differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Steel frame with cast iron axles Steering Hydrostatic Hydrostatic power steering Brakes Wet disc Wet disc Seat Suspension & Adjustability Adjustable suspension seat Adjustable seat, flips up and back for rear backhoe operation Front Axle Type 4WD center-pivot, reverse Eliot type Selectable 4WD Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 107.8 in 110 in Overall Width 52.8 in 53.9 in Wheelbase 58.3 in 65.7 in Ground Clearance 7.7 in 16.4 in Min. Turn Radius without Brakes 105.5 in Not Published Height to Top of ROPS 89.8 in 91.4 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published ▶ WeightTractor Weight (Base) 1,881 lb 2,107 lb Weight with ROPS and Loader 2,564 lb Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R3 Turf, R4 Industrial R1 Agricultural (11.2-20 rear standard), R4 Industrial (25x8.50-14 / 14-17.5) R1 Agricultural - Front Not Published 7-16 6PR R1 Agricultural - Rear Not Published 11.2-20 R3 Turf - Front Turf Master 23x8.50-12 NHS TL 4PR Not Published R3 Turf - Rear Multi-Trac CS 33x12.50-16.5 NHS TL 4PR Not Published R4 Industrial - Front Trac Chief 23x8.50-12 NHS TL 4PR 25x8.50-14 R4 Industrial - Rear Trac Chief 12-16.5 NHS TL 6PR 14-17.5 ▶ Loader & AttachmentsQuick Attach Loader System TX2000: Quick attach mechanism Quick attach front loader Loader Model TX2000 BBL300 Loader Lift Height TX2000: 86.9 in 87.5 in Loader Lift Capacity (Full Height) TX2000: 1,380 lb 1,314 lb Loader Breakout Force TX2000: 2,059 lb 1,960 lbf ▶ WarrantyWarranty Length & Coverage Up to 2 years or until the 2,000 hour mark, bumper-to-bumper warranty; 3000 hours maximum coverage period for parts and labour on drivetrains or powertrains; 12-months warranty period for implements, including loaders and backhoes. Engine and powertrain: 72 months or 2,000 hours; other tractor parts: 24 months or 1,000 hours; loader and backhoe: 24 months from shipment, 12 months from sale, or 500 hours ▶ ITC Company AccessoriesAccessories that fit
