▶ EngineEngine Manufacturer TYM Yanmar Engine Model T1100N2 3TNV80F Engine Type 3-cylinder, naturally aspirated diesel Water cooled, 4-cycle diesel No. of Cylinders 3 3 Displacement 71.7 in³ 77.3 in³ Rated Engine Speed 2800 rpm 3000 rpm Engine Power (Gross) 24 hp 24 hp PTO Power 18.3 hp 18.8 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Water-cooled Water cooled, forced circulation Air Cleaner Single dry Single element Fuel System IDI Indirect fuel injection Alternator 50 A, 12 V 40 A, 12 V ▶ HydraulicsPump Type Dual gear pump Not Published Implement Flow 4.4 gpm 4.18 gpm Steering Flow 2.7 gpm 2.77 gpm Total Hydraulic Flow 7.1 gpm 6.95 gpm Overall Hydraulic Pump Flow 7.1 gpm 6.95 gpm Hydraulic System Type Open center Live, independent Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves None 1 No. of Optional Remote Valves 1 Not Published ▶ Fluid CapacityFuel Tank Capacity 6.6 gal 5.81 gal Coolant Capacity 5.9 qt 0.96 gal Crankcase Capacity 4.5 qt 0.71 gal Transmission / Hydraulic System Capacity 4.7 gal 3.83 gal Front Axle Fluid Capacity 4.7 qt 0.85 gal ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540 rpm 540 rpm Mid-PTO Availability Available 2,000 rpm Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 1,534 lb 1,323 lb Hitch Lift Capacity (at 24”) 1,102 lb 1,058 lb Lift Control Type Position control Position ▶ Transmission & DrivetrainTransmission Type HST 2-range hydrostatic No. of Speeds Infinite 2-Range 2 ranges (high/low), infinite forward and reverse Max Travel Speed (Forward) 12.9 mph 11.2 mph Max Travel Speed (Reverse) Not Published Not Published Clutch Dry single plate Electro-hydraulic PTO clutch assembly (hydrostatic drive, no traction clutch) Differential Lock & Limited Slip Options Differential lock 4WD with differential lock (bevel gears with diff-lock) ▶ Chassis, Steering & ControlsFrame Type Not Published Unit frame: engine, transmission and front axle support bolted together into a rigid assembly Steering Hydrostatic Hydrostatic power steering Brakes Wet disc Wet disc, independent foot pedals that lock together Seat Suspension & Adjustability Adjustable seat (sliding) Suspension seat with armrests & retractable seat belt Front Axle Type 4WD center-pivot, reverse Eliot type 4WD, center-pivot reverse Eliot type Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 52.8 in 45.8 in Wheelbase 58.3 in 57.5 in Ground Clearance 7.7 in 9.4 in Min. Turn Radius without Brakes 105.5 in Not Published Height to Top of ROPS 89.8 in 91.3 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published Overall Length 107.8 in (with 3-point hitch) 100.5 in ▶ WeightTractor Weight (Base) 1,881 lb (with ROPS) 1,610 lb Weight with ROPS and Loader 2,564 lb (1,881 + 683, computed; TX2000 loader with bucket) 2,091 lb (1,610 + 481, computed) Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R3 Turf, R4 Industrial, R4 Lg Industrial Titan: R4 Industrial (Std), R3 Turf (Opt), R1 Agricultural (Opt), R14 (Opt) R1 Agricultural - Front Not Published 6-12 R1 Agricultural - Rear Not Published 9.5-16 R3 Turf - Front Turf Master 23x8.50-12 NHS TL 4PR 20x8-10 R3 Turf - Rear Multi-Trac CS 33x12.50-16.5 NHS TL 4PR 29x12.5-15 R4 Industrial - Front Trac Chief 23x8.50-12 NHS TL 4PR 20x8-10 R4 Industrial - Rear Trac Chief 12-16.5 NHS TL 6PR 27x12.5-15 ▶ Loader & AttachmentsQuick Attach Loader System TX2000: Quick attach mechanism L75: skid-steer compatible quick-attach Loader Model TX2000 L75 Loader Lift Height TX2000: 86.9 in L75: 75.3 in (maximum lift height to pivot pin) Loader Lift Capacity (Full Height) TX2000: 1,380 lb (at pivot pin) L75: 947 lb (at pivot pin, to full height) Loader Breakout Force TX2000: 2,059 lb (at pivot pin, ground level) L75: 1,680 lb (at pivot pin) ▶ WarrantyWarranty Length & Coverage Basic 24 months or 2,000 hours, parts and labor; non-commercial, 20 to 70 engine hp: powertrain 72 months or 3,000 hours; loaders, backhoes and mid-mount mowers 12 months Government and non-institutional: basic 24 months or 2,000 hours, powertrain 96 months or 3,000 hours; all other use: basic 24 months or 2,000 hours, powertrain 36 months or 3,000 hours ▶ ITC Company AccessoriesAccessories that fit
