▶ EngineEngine Manufacturer TYM TYM Engine Model T1100N2 T1100N2 Engine Type 3-cylinder, naturally aspirated diesel 3-cylinder, naturally aspirated diesel No. of Cylinders 3 3 Displacement 71.7 in³ 71.7 in³ Rated Engine Speed 2800 rpm 2850 rpm Engine Power (Gross) 24 hp 24 hp PTO Power 18.3 hp 18 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Single dry Dry element Fuel System IDI IDI Alternator 50 A, 12 V 60 A, 12 V ▶ HydraulicsPump Type Dual gear pump Dual gear pump Implement Flow 4.4 gpm 4.65 gpm Steering Flow 2.7 gpm 3.3 gpm Total Hydraulic Flow 7.1 gpm 7.9 gpm Overall Hydraulic Pump Flow 7.1 gpm 7.9 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published 3.1 gpm No. of Standard Remote Valves 0 0 No. of Optional Remote Valves 1 2 ▶ Fluid CapacityFuel Tank Capacity 6.6 gal 6.0 gal Coolant Capacity 5.9 qt 5.3 qt Crankcase Capacity 4.5 qt 2.9 qt Transmission / Hydraulic System Capacity 4.7 gal 3.7 gal Front Axle Fluid Capacity 4.7 qt 3.5 qt ▶ PTO & HitchPTO Type Independent Live PTO Rear 540 rpm 540/1000 rpm Mid-PTO Availability Available Mid-PTO available; 2,500 RPM mid-mount PTO option Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 1,534 lb 1,499 lb Hitch Lift Capacity (at 24”) 1,102 lb 974 lb Lift Control Type Position control Position control ▶ Transmission & DrivetrainTransmission Type HST HST No. of Speeds Infinite 2-Range 3-Range Max Travel Speed (Forward) 12.9 mph 17 mph Max Travel Speed (Reverse) Not Published Not Published Clutch Dry single plate Dry single plate Differential Lock & Limited Slip Options Differential lock Differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic Hydrostatic Brakes Wet disc Wet, Multi disc Seat Suspension & Adjustability Adjustable suspension seat Comfortable suspension seat Front Axle Type 4WD center-pivot, reverse Eliot type Selectable four wheel drive Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 107.8 in 122.9 in Overall Width 52.8 in 53.8 in Wheelbase 58.3 in 65.7 in Ground Clearance 7.7 in 15.1 in Min. Turn Radius without Brakes 105.5 in (L) 115.4 in; (R) 114.2 in Height to Top of ROPS 89.8 in 91.5 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published ▶ WeightTractor Weight (Base) 1,881 lb 2,106 lb Weight with ROPS and Loader 2,564 lb 2,760 lb Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R3 Turf, R4 Industrial Front: R1 Agricultural 6-12 | R3 Turf 23x8.50-12 | R4 Industrial 25x8.50-14; Rear: R1 Agricultural 9.5-16 | R3 Turf 33x12.50-16.5 | R4 Industrial 14-17.5 R1 Agricultural - Front Not Published 7-16 R1 Agricultural - Rear Not Published 11.2-20 R3 Turf - Front Turf Master 23x8.50-12 NHS TL 4PR 23x8.50-12 R3 Turf - Rear Multi-Trac CS 33x12.50-16.5 NHS TL 4PR 33x12.50-16.5 R4 Industrial - Front Trac Chief 23x8.50-12 NHS TL 4PR 25x8.50-14 R4 Industrial - Rear Trac Chief 12-16.5 NHS TL 6PR 14-17.5 ▶ Loader & AttachmentsQuick Attach Loader System TX2000: Quick attach mechanism BL110S: Quick attach mechanism Loader Model TX2000 BL110S Loader Lift Height TX2000: 86.9 in BL110S: 91.1 in Loader Lift Capacity (Full Height) TX2000: 1,380 lb BL110S: 1,373 lb Loader Breakout Force TX2000: 2,059 lb BL110S: 2,077 lb ▶ WarrantyWarranty Length & Coverage Up to 2 years or until the 2,000 hour mark, bumper-to-bumper warranty; 3000 hours maximum coverage period for parts and labour on drivetrains or powertrains; 12-months warranty period for implements, including loaders and backhoes. Up to 2 years or until the 2,000 hour mark, bumper-to-bumper warranty; 3000 hours maximum coverage period for parts and labour on drivetrains or powertrains; 12-months warranty period for implements, including loaders and backhoes. ▶ ITC Company AccessoriesAccessories that fit
