▶ EngineEngine Manufacturer TYM TYM Engine Model T1700N6 T1100N2 Engine Type 3-cylinder, naturally aspirated diesel 3-cylinder, naturally aspirated diesel No. of Cylinders 3 3 Displacement 104.5 in³ 71.7 in³ Rated Engine Speed 2100 rpm 2850 rpm Engine Power (Gross) 24 hp 24 hp PTO Power 21 hp 18 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Not Published Liquid-cooled Air Cleaner Dry element Dry element Fuel System IDI (indirect injection) IDI Alternator 50 A, 12 V 60 A, 12 V ▶ HydraulicsPump Type Dual gear pump Dual gear pump Implement Flow 7.5 gpm 4.65 gpm Steering Flow 4.0 gpm 3.3 gpm Total Hydraulic Flow 11.5 gpm 7.9 gpm Overall Hydraulic Pump Flow 11.5 gpm 7.9 gpm Hydraulic System Type Not Published Open center Rear Remote Hydraulic Flow Not Published 3.1 gpm No. of Standard Remote Valves Loader: 4 / Rear: 0 None No. of Optional Remote Valves Up to 4 2 ▶ Fluid CapacityFuel Tank Capacity 8.7 gal 6.0 gal Coolant Capacity 5.3 qt 5.3 qt Crankcase Capacity 4.5 qt 2.9 qt Transmission / Hydraulic System Capacity T3025R: 8.9 gal; T3025H: 9.8 gal 3.7 gal Front Axle Fluid Capacity 6.8 qt 3.5 qt ▶ PTO & HitchPTO Type Independent Live PTO Rear 540 rpm 540/1000 rpm Mid-PTO Availability Not Published Optional (Mid-PTO kit) Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 3,307 lb 1,499 lb Hitch Lift Capacity (at 24”) 2,425 lb 974 lb Lift Control Type Position control Position control ▶ Transmission & DrivetrainTransmission Type T3025R: Synchromesh; T3025H: HST HST No. of Speeds T3025R: F12 x R12; T3025H: 3-Range 3-Range Max Travel Speed (Forward) T3025R: 11.7 mph; T3025H: 16.7 mph 17 mph Max Travel Speed (Reverse) Not Published Not Published Clutch T3025R: Dry single plate; T3025H: N/A Dry single plate Differential Lock & Limited Slip Options Not Published Differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic Hydrostatic Brakes Wet, multi-disc Wet, Multi disc Seat Suspension & Adjustability Suspension seat Comfortable suspension seat Front Axle Type Not Published 4WD Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 56.3 in 53.8 in Wheelbase 65.7 in 65.7 in Ground Clearance 14.4 in 15.1 in Min. Turn Radius without Brakes 105.5 in (L) 9.6 ft; (R) 9.5 ft Height to Top of ROPS 97.2 in 91.5 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published Overall Length 121 in (with 3-point hitch) 122.9 in (with 3-point hitch) ▶ WeightTractor Weight (Base) 2,970 lb (with ROPS) 2,106 lb Weight with ROPS and Loader Not Published 2,760 lb (2,106 + 654, computed) Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural 8-16 / 12.4-24; R3 Turf 27x8.5-15 / 41x14.00; R4 Industrial 10-16.5 / 420/70-24 R1 ag: 7-16 front, 11.2-20 rear; R3 turf: 23x8.50-12 front, 33x12.50-16.5 rear; R4 industrial: 23x8.50-12 front, 12-16.5 rear R1 Agricultural - Front 8-16 7-16 R1 Agricultural - Rear 12.4-24 11.2-20 R3 Turf - Front 27x8.5-15 23x8.50-12 R3 Turf - Rear 41x14.00 33x12.50-16.5 R4 Industrial - Front 10-16.5 23x8.50-12 R4 Industrial - Rear 420/70-24 12-16.5 ▶ Loader & AttachmentsQuick Attach Loader System Not Published BL110S: Quick attach mechanism Loader Model Not Published BL110S Loader Lift Height Not Published BL110S: 91.1 in Loader Lift Capacity (Full Height) Not Published BL110S: 1,373 lb (at pivot pin) Loader Breakout Force Not Published BL110S: 2,077 lb (at pivot pin, ground level) ▶ WarrantyWarranty Length & Coverage Basic 24 months or 2,000 hours, parts and labor; non-commercial, 20 to 70 engine hp: powertrain 72 months or 3,000 hours; loaders, backhoes and mid-mount mowers 12 months Basic 2 years or 2,000 hours; powertrain 3,000 hours maximum, parts and labor; loaders and backhoes 12 months ▶ ITC Company AccessoriesAccessories that fit None tagged yet
