▶ EngineEngine Manufacturer TYM TYM Engine Model T1700N6 T2300T1-UTC_4 Engine Type 3-cylinder, naturally aspirated diesel 4-cylinder, turbocharged diesel No. of Cylinders 3 4 Displacement 104.5 in³ 139.5 in³ Rated Engine Speed 2100 rpm 2600 rpm Engine Power (Gross) 24 hp 58 hp PTO Power 21 hp 48 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Not Published Not Published Air Cleaner Dry element Dry element Fuel System IDI (indirect injection) IDI Alternator 50 A, 12 V 70 A, 12 V ▶ HydraulicsPump Type Dual gear pump Single gear pump Implement Flow 7.5 gpm 11.4 gpm Steering Flow 4.0 gpm 5.13 gpm Total Hydraulic Flow 11.5 gpm 16.5 gpm Overall Hydraulic Pump Flow 11.5 gpm 16.5 gpm Hydraulic System Type Not Published Not Published Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Loader: 4 / Rear: 0 Loader: 6; Rear: 6 No. of Optional Remote Valves Up to 4 Not Published ▶ Fluid CapacityFuel Tank Capacity 8.7 gal 15.3 gal Coolant Capacity 5.3 qt 6.2 qt Crankcase Capacity 4.5 qt 4.8 qt Transmission / Hydraulic System Capacity T3025R: 8.9 gal; T3025H: 9.8 gal 11.62 gal Front Axle Fluid Capacity 6.8 qt 6.8 qt ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540 rpm 540 rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category I Category II Hitch Lift Capacity 3,307 lb 4,409 lb Hitch Lift Capacity (at 24”) 2,425 lb 3,748 lb Lift Control Type Position control Position and draft control (electronic) ▶ Transmission & DrivetrainTransmission Type T3025R: Synchromesh; T3025H: HST Power shuttle No. of Speeds T3025R: F12 x R12; T3025H: 3-Range F12 x R12 Max Travel Speed (Forward) T3025R: 11.7 mph; T3025H: 16.7 mph 24.04 mph Max Travel Speed (Reverse) Not Published Not Published Clutch T3025R: Dry single plate; T3025H: N/A Wet, multi-disc Differential Lock & Limited Slip Options Not Published Standard differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic Hydrostatic Brakes Wet, multi-disc Wet, multi-disc Seat Suspension & Adjustability Suspension seat Suspension seat Front Axle Type Not Published 4WD (selectable 2WD/4WD) Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 56.3 in 68.9 in Wheelbase 65.7 in 78.7 in Ground Clearance 14.4 in 18.1 in Min. Turn Radius without Brakes 105.5 in L: 139.7 in; R: 141.9 in Height to Top of ROPS 97.2 in Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published 99.2 in Overall Length 121 in (with 3-point hitch) 141.5 in (with 3-point hitch) ▶ WeightTractor Weight (Base) 2,970 lb (with ROPS) 4,952 lb (weight with cab) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published 6,252 lb (4,952 + 1,300, computed; L4058PC loader total weight) ▶ Tire OptionsTire Size & Options R1 Agricultural 8-16 / 12.4-24; R3 Turf 27x8.5-15 / 41x14.00; R4 Industrial 10-16.5 / 420/70-24 R1 Agricultural, R4 Industrial, Golf tires R1 Agricultural - Front 8-16 9.5-20 R1 Agricultural - Rear 12.4-24 14.9-28 R3 Turf - Front 27x8.5-15 29x12.5-15 (golf tire) R3 Turf - Rear 41x14.00 44x18.00-20 (golf tire) R4 Industrial - Front 10-16.5 10.5/80-18 R4 Industrial - Rear 420/70-24 16.9-24 ▶ Loader & AttachmentsQuick Attach Loader System Not Published L4058PC: Quick attach mechanism Loader Model Not Published L4058PC Loader Lift Height Not Published L4058PC: 117.5 in Loader Lift Capacity (Full Height) Not Published L4058PC: 3,437 lb (at pivot pin) Loader Breakout Force Not Published L4058PC: 4,742 lb (at pivot pin, ground level) ▶ WarrantyWarranty Length & Coverage Basic 24 months or 2,000 hours, parts and labor; non-commercial, 20 to 70 engine hp: powertrain 72 months or 3,000 hours; loaders, backhoes and mid-mount mowers 12 months Basic 2 years or 2,000 hours; powertrain 3,000 hours maximum, parts and labor; loaders and backhoes 12 months
