Pick up to 4tractors and we'll lay every spec sheet out side by side. Same data we publish on the individual model pages, stacked in columns so you can compare numbers at a glance.
No photo
—
TYMT3025C
No photo
—
SolisH24+
Comparison loaded for 2 tractors.
Spec
TYMT3025C
SolisH24+
PTO Power
21 hp (15.7 kW)
Not Published
Alternator
12 V, 70 A
Not Published
Air Cleaner
Dry element
Not Published
Engine Type
3-cylinder, naturally aspirated diesel
3‑Cylinder, Naturally Aspirated Diesel
Fuel System
IDI
Not Published
Displacement
104.5 in³ (1,714 cc)
80.42 in³ (1318 cc)
No. of Cylinders
3
3
Rated Engine Speed
2,100 rpm
2500 rpm
Cooling System Type
Not Published
Not Published
Engine Manufacturer
TYM
Mitsubishi
Engine Emissions Constraints
Tier 4
Not Published
Engine Power (Gross vs. Net HP)
Gross: 24 hp (18 kW)
24 hp (17.9 kW)
Tractor Weight with Loader
Not Published
Not Published
Weight with Cab and Loader
Not Published
Not Applicable
Weight with ROPS and Loader
Not Applicable
Not Published
Pump Type
Dual gear pump
Not Published
Steering Flow
15.8 L/min (4.2 gpm)
Not Published
Implement Flow
29.3 L/min (7.7 gpm)
Not Published
Total Hydraulic Flow
45.1 L/min (11.9 gpm)
15.1 L/min (3.98 gpm)
Hydraulic System Type
Open center
Open Center
Rear Remote Hydraulic Flow
Not Published
Not Published
Overall Hydraulic Pump Flow
45.1 L/min (11.9 gpm)
Not Published
No. of Optional Remote Valves
Not Published
Not Published
No. of Standard Remote Valves
Loader: 4; Rear: 0
1
R3 Turf - Rear
Not Applicable
33x15.5-16.5
R3 Turf - Front
Not Applicable
23x8.50-12
Tire Size & Options
R1 Agricultural, Golf Tires, R4 Industrial
R1 Agricultural, R3 Turf, R4 Industrial
R4 Industrial - Rear
380/70-19.5, 6PR
33x15.5-16.5
R4 Industrial - Front
Not Published
23x8.50-12
R1 Agricultural - Rear
11.2-24, 8PR
8.3x20
R1 Agricultural - Front
7-16, 6PR
6x12
PTO Rear
540 rpm
540 rpm @ 2451 engine rpm
PTO Type
Independent
Electro-hydraulic PTO; wet type clutch; button operated
Lift Control Type
Position control
Not Published
Hitch Lift Capacity
3,306 lb (1,500 kg)
1,323 lb (600 kg)
Mid-PTO Availability
Not Published
Yes (2100 rpm @ 2438 engine rpm)
Category, 3-Point Hitch
Category I
CAT-1N
Hitch Lift Capacity (at 24”)
2,425 lb (1,100 kg)
Not Published
Rear 3-Point Hitch Lift Capacity
3,306 lb (1,500 kg)
1,323 lb (600 kg)
Coolant Capacity
5.3 qt (5.0 L)
Not Published
Crankcase Capacity
4.5 qt (4.3 L)
Not Published
Fuel Tank Capacity
7.1 gal (27.0 L)
7 gal (26.5 L)
Front Axle Fluid Capacity
6.8 qt (6.4 L)
Not Published
Transmission / Hydraulic System Capacity
9.8 gal (37.0 L)
Not Published
Loader Lift Height
104.9 in (2,665 mm)
85 in (2159 mm)
Loader Breakout Force
3,422 lb (1,552 kg)
1,146 lb (520 kg)
Price for Backhoe Option
BH70
Not Published
Price for Mid-Mount Mower
Not Published
Not Published
Quick Attach Loader System
L3048: Quick attach mechanism
3200V: Self-leveling
Loader Lift Capacity (Full Height)
2,200 lb (998 kg)
1,411 lb (640 kg)
Clutch
Not Applicable
Not Published
No. of Speeds
3-range
2 Range
Transmission Type
Hydrostatic (HST)
HST (2 Range); Constant Mesh
Max Travel Speed (Forward)
14.6 mph (23.6 km/h)
Not Published
Max Travel Speed (Reverse)
Not Published
Not Published
Differential Lock & Limited Slip Options
Not Published
Differential lock: Standard
Brakes
Wet, multi-disc
Oil immersed brakes; mechanical foot operated
Steering
Hydrostatic
Power steering
Frame Type
Not Published
Not Published
Front Axle Type
Not Published
4WD
Drawbar Capacity
Not Published
Not Published
Front Axle Rating
Not Published
Not Published
Seat Suspension & Adjustability
Not Published
Not Published
Wheelbase
65.7 in (1,670 mm)
61.8 in (1570 mm)
Overall Width
55.6 in (1,413 mm)
47.83 in (1215 mm)
Ground Clearance
13.1 in (334 mm)
9.44 in (240 mm)
Height to Top of ROPS
Not Applicable
91.53 in (2325 mm)
Height to Top of Cab Model
89.3 in (2,267 mm)
Not Applicable
Height to Top of ROPS (folded)
Not Applicable
Not Published
Min. Turn Radius without Brakes
L: 105.51 in (2,680 mm); R: 104.72 in (2,660 mm)
Not Published
Overall Length with 3-Point Hitch
120.9 in (3,071 mm)
113.98 in (2895 mm)
Financing Options
0% financing for up to 72 months and instant cash rebates. Contact dealer for more information.
$0 down financing available for up to 84 months
Base Price with Loader
Not Published
Not Published
Warranty Length & Coverage
Up to 2 years or until the 2,000 hours mark, bumper-to-bumper warranty; 3000 hours maximum coverage period for parts and labour on drivetrains or powertrains; 12-months warranty period for implements, including loaders and backhoes.
