▶ EngineEngine Manufacturer TYM TYM Engine Model T1700N6 T1100N2 Engine Type 3-cylinder, naturally aspirated diesel 3-cylinder, naturally aspirated diesel No. of Cylinders 3 3 Displacement 104.5 in³ 71.7 in³ Rated Engine Speed 2100 rpm 2850 rpm Engine Power (Gross) 24 hp 24 hp PTO Power 21 hp 18 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Not Published Liquid-cooled Air Cleaner Dry element Dry element Fuel System IDI (indirect injection) IDI Alternator 70 A, 12 V 60 A, 12 V ▶ HydraulicsPump Type Dual gear pump Dual gear pump Implement Flow 7.7 gpm 4.65 gpm Steering Flow 4.2 gpm 3.3 gpm Total Hydraulic Flow 11.9 gpm 7.9 gpm Overall Hydraulic Pump Flow 11.9 gpm 7.9 gpm Hydraulic System Type Not Published Open center Rear Remote Hydraulic Flow Not Published 3.1 gpm No. of Standard Remote Valves Loader: 4 / Rear: 0 None No. of Optional Remote Valves Up to 4 2 ▶ Fluid CapacityFuel Tank Capacity 7.1 gal 6.0 gal Coolant Capacity 5.3 qt 5.3 qt Crankcase Capacity 4.5 qt 2.9 qt Transmission / Hydraulic System Capacity 9.8 gal 3.7 gal Front Axle Fluid Capacity 6.8 qt 3.5 qt ▶ PTO & HitchPTO Type Independent Live PTO Rear 540 rpm 540/1000 rpm Mid-PTO Availability Not Published Optional (Mid-PTO kit) Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 3,306 lb 1,499 lb Hitch Lift Capacity (at 24”) 2,425 lb 974 lb Lift Control Type Position control Position control ▶ Transmission & DrivetrainTransmission Type HST HST No. of Speeds 3-Range 3-Range Max Travel Speed (Forward) 14.6 mph 17 mph Max Travel Speed (Reverse) 14.6 mph Not Published Clutch None (HST) Dry single plate Differential Lock & Limited Slip Options Differential lock (standard) Differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Hydrostatic Brakes Wet, multi-disc Wet, Multi disc Seat Suspension & Adjustability Suspension seat Comfortable suspension seat Front Axle Type Not Published 4WD Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 56.6 in 53.8 in Wheelbase 65.7 in 65.7 in Ground Clearance 13.1 in 15.1 in Min. Turn Radius without Brakes L: 105.51 in; R: 104.72 in (L) 9.6 ft; (R) 9.5 ft Height to Top of ROPS Not Published 91.5 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 89.3 in Not Published Overall Length 120.9 in (with 3-point hitch) 122.9 in (with 3-point hitch) ▶ WeightTractor Weight (Base) 3,313 lb (with cab) 2,106 lb Weight with ROPS and Loader Not Published 2,760 lb (2,106 + 654, computed) Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural 7-16 / 11.2-24; Golf (turf) tires 27x8.5-15 / 41x14.00; R4 Industrial 25x8.5-14 / 380/70-19.5 R1 ag: 7-16 front, 11.2-20 rear; R3 turf: 23x8.50-12 front, 33x12.50-16.5 rear; R4 industrial: 23x8.50-12 front, 12-16.5 rear R1 Agricultural - Front 7-16, 6PR 7-16 R1 Agricultural - Rear 11.2-24, 8PR 11.2-20 R3 Turf - Front 27x8.5-15, 6PR (golf tire) 23x8.50-12 R3 Turf - Rear 41x14.00, 4PR (golf tire) 33x12.50-16.5 R4 Industrial - Front 25x8.5-14, 6PR 23x8.50-12 R4 Industrial - Rear 380/70-19.5, 6PR 12-16.5 ▶ Loader & AttachmentsQuick Attach Loader System Not Published BL110S: Quick attach mechanism Loader Model L3035 BL110S Loader Lift Height L3035: 104.9 in BL110S: 91.1 in Loader Lift Capacity (Full Height) L3035: 2,200 lb (at pivot pin) BL110S: 1,373 lb (at pivot pin) Loader Breakout Force L3035: 3,422 lb (at pivot pin, ground level) BL110S: 2,077 lb (at pivot pin, ground level) ▶ WarrantyWarranty Length & Coverage Basic 24 months or 2,000 hours, parts and labor; non-commercial, 20 to 70 engine hp: powertrain 72 months or 3,000 hours; loaders, backhoes and mid-mount mowers 12 months Basic 2 years or 2,000 hours; powertrain 3,000 hours maximum, parts and labor; loaders and backhoes 12 months ▶ ITC Company AccessoriesAccessories that fit
