▶ EngineEngine Manufacturer Yanmar Yanmar Engine Model 3TNV88-CR Not Published Engine Type 3-cylinder, naturally aspirated diesel Not Published No. of Cylinders 3 Not Published Displacement 100.2 in³ Not Published Rated Engine Speed 3000 rpm 3000 rpm Engine Power (Gross) 36.9 hp 36.9 hp PTO Power 30.2 hp 28.2 hp Engine Emissions Constraints Tier 4 Not Published Cooling System Type Liquid-cooled Not Published Air Cleaner Dual dry Not Published Fuel System CRDI Not Published Alternator 50 A, 12 V Not Published ▶ HydraulicsPump Type Dual gear pump Not Published Implement Flow 6.1 gpm 6.1 gpm Steering Flow 4.4 gpm 4.4 gpm Total Hydraulic Flow 10.5 gpm 10.5 gpm Overall Hydraulic Pump Flow 10.5 gpm 10.5 gpm Hydraulic System Type Open center Not Published Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves None Not Published No. of Optional Remote Valves 1 or 2 (single or double rear remote with detent, accessory) 1 or 2 ▶ Fluid CapacityFuel Tank Capacity 9.0 gal 9.0 gal Coolant Capacity 7.4 qt Not Published Crankcase Capacity 6 qt Not Published Transmission / Hydraulic System Capacity 8.5 gal Not Published Front Axle Fluid Capacity 8.7 qt Not Published ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540 rpm 540 rpm Mid-PTO Availability Optional (Mid-PTO kit) Not Published Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 2,639 lb 2,639 lb Hitch Lift Capacity (at 24”) 1,558 lb 1,558 lb Lift Control Type Position control Not Published ▶ Transmission & DrivetrainTransmission Type Mechanical Synchro Shuttle No. of Speeds 12 forward / 12 reverse Not Published Max Travel Speed (Forward) 15.0 mph Not Published Max Travel Speed (Reverse) Not Published Not Published Clutch Dry single plate Dry Single Plate Differential Lock & Limited Slip Options Differential lock (pedal) Rear differential lock (foot pedal engagement) ▶ Chassis, Steering & ControlsFrame Type Unit frame: engine, clutch housing, transmission and front axle support bolted into one rigid assembly Not Published Steering Hydrostatic Not Published Brakes Wet disc Not Published Seat Suspension & Adjustability Fore and aft sliding seat with cushion strength adjustment Comfortable, adjustable operator seat Front Axle Type 4WD center-pivot, reverse Elliott type Selectable 2WD/4WD engagement Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 53.5 in Not Published Wheelbase 64.5 in Not Published Ground Clearance 12.8 in 12.8 in Min. Turn Radius without Brakes 116 in Not Published Height to Top of ROPS 94.5 in Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published Overall Length 126 in (with 3-point hitch) Not Published ▶ WeightTractor Weight (Base) 3,020 lb (with ROPS) 3,020 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural, R3 Turf, R4 Industrial Not Published R1 Agricultural - Front Farm Specialist 8.0-16 NHS TL 6PR Not Published R1 Agricultural - Rear Farm Specialist 12.4-24 NHS TL 6PR (standard); Farm Specialist 11.2-24 NHS TL 6PR (option) Not Published R3 Turf - Front 27x10.5-15 Not Published R3 Turf - Rear 12.5-20 Not Published R4 Industrial - Front 27x10.5-15 Not Published R4 Industrial - Rear 12.5x20 Not Published ▶ Loader & AttachmentsQuick Attach Loader System TX39H: quick attachment assembly Not Published Loader Model TX39H RL505 Loader Lift Height TX39H: 101.5 in RL505: 101.5 in (at pivot pin) Loader Lift Capacity (Full Height) TX39H: 2,116 lb (at pivot pin) RL505: 2,116 lb (at pivot pin) Loader Breakout Force TX39H: 3,435 lb (at pivot pin, ground level) RL505: 3,435 lb (at pivot pin, ground level) ▶ WarrantyWarranty Length & Coverage Basic 24 months or 2,000 hours, parts and labor; non-commercial: powertrain 72 months or 3,000 hours; rental and commercial: powertrain 36 months or 2,000 hours; loaders and backhoes 12 months Basic 24 months or 2,000 hours; powertrain 10 years or 3,000 hours ▶ ITC Company AccessoriesAccessories that fit None tagged yet
