TYM T4058P vs Kioti DK6020 | Side-by-side comparison | ITC Resource Center
Compare Tractors
See horsepower, lift capacity, hydraulic flow, and the numbers that matter to your work. Up to 4 machines, side by side, in graphs built to show which tractor is better at what.
Every published spec, side by side, including the details the graphs above don't chart.
Spec
TYMT4058P
KiotiDK6020
Engine Manufacturer
TYM
KIOTI (Daedong)
Engine Model
T2300T1-UTR_4
3HT-TH4C
Engine Type
4-cylinder, turbocharged diesel
3-cylinder, liquid-cooled diesel
No. of Cylinders
4
3
Displacement
139.5 in³
111.4 in³
Rated Engine Speed
2600 rpm
2600 rpm
Engine Power (Gross)
58 hp
57.7 hp
PTO Power
48 hp
44.9 hp
Engine Emissions Constraints
Tier 4
Tier 4
Cooling System Type
Not Published
Liquid-cooled
Air Cleaner
Dry element
Dry element
Fuel System
IDI (indirect injection)
Not Published
Alternator
70 A, 12 V
Not Published
Pump Type
Single gear pump
Gear
Implement Flow
11.4 gpm
9.62 gpm
Steering Flow
5.13 gpm
6.87 gpm
Total Hydraulic Flow
16.5 gpm
16.5 gpm
Overall Hydraulic Pump Flow
16.5 gpm
16.5 gpm
Hydraulic System Type
Not Published
Not Published
Rear Remote Hydraulic Flow
Not Published
Not Published
No. of Standard Remote Valves
Loader: 4; Rear: 4
2
No. of Optional Remote Valves
Not Published
Not Published
Fuel Tank Capacity
15.32 gal
12.7 gal
Coolant Capacity
6.2 qt
2.1 gal
Crankcase Capacity
4.7 qt
1.95 gal
Transmission / Hydraulic System Capacity
11.6 gal
11.4 gal
Front Axle Fluid Capacity
6.8 qt
1.48 gal
PTO Type
Independent
Independent
PTO Rear
540 rpm
540 rpm
Mid-PTO Availability
Not Published
Optional (2,000 rpm)
Category, 3-Point Hitch
Category II
Category II
Hitch Lift Capacity
4,409 lb
2,998 lb
Hitch Lift Capacity (at 24”)
3,748 lb
2,716 lb
Lift Control Type
Position and draft control (electronic)
Position
Transmission Type
Power shuttle
Hydrostatic (HST)
No. of Speeds
F12 x R12
3 ranges (hydrostatic, infinite speeds)
Max Travel Speed (Forward)
24.04 mph
18.45 mph
Max Travel Speed (Reverse)
19.39 mph
12.92 mph
Clutch
Wet, multi-disc
None (hydrostatic transmission)
Differential Lock & Limited Slip Options
Standard differential lock
Rear differential lock (standard)
Frame Type
Not Published
Not Published
Steering
Hydrostatic
Hydrostatic power steering
Brakes
Wet, multi-disc
Wet multi-disc
Seat Suspension & Adjustability
Suspension seat
Deluxe suspension seat
Front Axle Type
4WD (selectable 2WD/4WD)
Mechanical 4WD
Front Axle Rating
Not Published
Not Published
Drawbar Capacity
Not Published
1,655 lb (max. drawbar vertical load)
Overall Length with 3-Point Hitch
141.5 in
126.0 in
Overall Width
68.9 in
62.8 in
Wheelbase
78.7 in
71.3 in
Ground Clearance
18.1 in
14.5 in
Min. Turn Radius without Brakes
L: 139.7 in; R: 141.9 in
102.8 in (with brake applied)
Height to Top of ROPS
104.7 in
96.8 in
Height to Top of ROPS (folded)
Not Published
Not Published
Height to Top of Cab Model
Not Published
93.0 in
Tractor Weight (Base)
4,506.2 lb
3,523 lb (DK6020SEH); 4,043 lb (DK6020SEH CAB)
Weight with ROPS and Loader
5,806.2 lb
Not Published
Weight with Cab and Loader
Not Published
Not Published
Tire Size & Options
R1 Agricultural, R3 Turf (golf), R4 Industrial
R1 Agricultural, R3 Turf, R4 Industrial, R14
R1 Agricultural - Front
9.5-20
8-16
R1 Agricultural - Rear
14.9-28
13.6-24
R3 Turf - Front
29x12.5-15
29-12.5-15
R3 Turf - Rear
44x18.00-20
21.5L-16.1
R4 Industrial - Front
10.5/80-18
10-16.5
R4 Industrial - Rear
16.9-24
14.9-24
Quick Attach Loader System
L4058P: Quick attach mechanism
Quick attach (QA) bucket, 66 in or 72 in
Loader Model
L4058P
KL5520; KL5521 (Cab models)
Loader Lift Height
L4058P: 117.5 in
KL5520: 107.7 in; KL5521: 107.7 in
Loader Lift Capacity (Full Height)
L4058P: 3,437 lb
KL5520: 2,474 lb; KL5521: 2,474 lb
Loader Breakout Force
L4058P: 4,742 lb
KL5520: 3,895 lb; KL5521: 3,895 lb
Warranty Length & Coverage
Up to 2 years or until the 2,000 hour mark, bumper-to-bumper warranty; 3,000 hours maximum coverage period for parts and labour on drivetrains or powertrains; 12-months warranty period for implements, including loaders and backhoes
Non-commercial: 24 months, unlimited hours, parts and labor, 0% deductible; non-commercial powertrain (engine and driveline): 72 months, unlimited hours
